1968-1978 Lamborghini Espada USA Intake and Air Filter (3.0.13)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.37
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.64
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.29
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.11

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 3.0.13 - Intake and Air Filter

1968-1978 Lamborghini Espada USA Intake and Air Filter (3.0.13)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	001309250	This item is no longer available	1 req
1	001301885	Carburettor Control Shaft	2 req	Avail to order Our Price: $32.28
2	001310583	Carburettor Long Tierod Assemb	2 req	Avail to order Our Price: $162.75
2	001302895	Carburettor Long Tierod	2 req	Avail to order Our Price: $86.81
3	001301093	Carburettor Rod Lever	1 req	Avail to order Our Price: $253.42
4	008410603	Washer D.6.4 Uni 1751/Zd	8 req	Avail to order Our Price: $2.00
5	008100618	Screw M6x20 Uni 5739/8g/Zd	8 req	Current Stock: 44 Our Price: $2.00
6	001301095	Carburettor Lever	6 req	Avail to order Our Price: $579.66
7	001301374	Lh Fuel Lever Spring	1 req	Avail to order Our Price: $28.71
8	001313192	Lh Air Cleaner Unit	1 req	Avail to order Our Price: $726.07
9	001309421	Handwheel Vh 153/35pm8x25	6 req	Avail to order Our Price: $15.46
10	001301913	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
11	001310582	Short Link Assembly	6 req	Current Stock: 2 Our Price: $581.16
11	001302898	Carburettor Short Tierod	6 req	Avail to order Our Price: $32.95
12	001304771	Lh Intake Manifold	1 req	Avail to order Our Price: $1,231.50
13	001310651	Espada Lh Carburettor	3 req	Avail to order Our Price: $678.37
13	001305611	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	3 req	*See Description
14	001301910	Lh Fuel Lever Spring	1 req	Avail to order Our Price: $28.71
15	001303816	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
16	001305396	Carburettor Rod Control Lever	1 req	Avail to order Our Price: $107.35
17	008801204	Bushing 7x16x18 mm	1 req	Current Stock: 1 Our Price: $10.89
18	001320172	Air Filter - Carbureted	2 req	Avail to order 1 Used Available Our Price: $502.37
19	001313191	Rh Air Cleaner Unit	1 req	Avail to order Our Price: $726.07
19	001309191	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
20	003204610	Vacuum Union	1 req	Avail to order Our Price: $159.04
21	N01100845	HEX.NUT	48 req	Current Stock: 17 Our Price: $2.09
22	WHT001514	SPRING WASHER	48 req	Current Stock: 9 Our Price: $26.80
23	008300822	Stud M8x18 Uni 5911 8g Z	24 req	Avail to order Our Price: $26.35
24	008604202	Ring 43 mm Or	12 req	Current Stock: 3 Our Price: $14.25
25	003101941	Banjo Bolt Fitting	1 req	Avail to order Our Price: $4.68
26	008401610	Annealed Copper Washer 16x22x0	4 req	Current Stock: 25 Our Price: $11.23
27	008931602	Plug	2 req	Avail to order Our Price: $5.67
28	001304770	NLA (No Longer Available)	1 req	*See Description
29	008801205	Bushing 12x16x12 mm	2 req	Avail to order Our Price: $25.35
30	001301221	AIR CLEANER SEAL	6 req	Avail to order Our Price: $20.51
31	008581101	O-Ring E 12 Uni 7435-75	1 req	Avail to order Our Price: $6.79
32	008401215	Washer 12.5x20x1.5	1 req	Avail to order Our Price: $13.50
33	001301222	Air Cleaner Seal	6 req	Avail to order Our Price: $7.29
34	001300804	Head Unit	8 req	Avail to order Our Price: $13.72
35	N10689901	HEX.NUT	8 req	Current Stock: 5 Our Price: $2.00
36	008300508	PRIG.SPEC.M5X28	6 req	Avail to order Our Price: $107.50
36	008300502	Stud 5x28 Uni 5917 8g/Zd	6 req	Avail to order Our Price: $8.80
37	001300805	This item is no longer available	16 req
38	001304706	Accelerator Control U-Bolt	1 req	Avail to order Our Price: $107.95
39	001310650	Espada Rh Carburettor	3 req	Avail to order Our Price: $678.37
40	001300290	Carburettor Seal	12 req	Avail to order Our Price: $3.87
41	001300289	Carburettor Shim	12 req	Avail to order Our Price: $69.71
42	001300291	Carburettor ManifoldSeal	12 req	Current Stock: 9 Our Price: $20.55
43	008300823	Stud M8x28 Uni 5909/8g Z	24 req	Avail to order Our Price: $7.74
44	400721214E	BALL JOINT HEAD (LEFT HAND THREAD)	8 req	Avail to order Our Price: $68.19
45	001113127	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
46	008830206	Clamp	4 req	Current Stock: 1 Our Price: $23.26
47	001313202	Pipe	1 req	Avail to order Our Price: $20.28
48	001313201	Pipe	1 req	Avail to order Our Price: $22.37
49	001313203	This item is no longer available	1 req
50	008830204	Clamp	2 req	Avail to order Our Price: $10.06
51	001309058	Intake Manifold Valve Union	1 req	Avail to order Our Price: $32.81
52	008200504	M5 Lh. Special Nut	8 req	Avail to order Our Price: $18.56
53	008300509	This item is no longer available	2 req
54	008604001	Or Ring	12 req	Current Stock: 12 Our Price: $11.93
56	004609315	This item is no longer available	3 req
56	001306139	This item is no longer available	3 req
57	004609314	This item is no longer available	3 req
57	001308138	This item is no longer available	3 req
58	001313271	Lh Air Cleaner Assembly	1 req	Avail to order Our Price: $1,036.19
59	001313270	Rh Air Cleaner Assembly	1 req	Avail to order Our Price: $1,036.19
59	001313272	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
