1968-1978 Lamborghini Espada USA Differential (11.0.23)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $113.58
004504532	Belt Belt	Current Stock: 1 Our Price: $55.72
001604645	Belt Belt	Current Stock: 3 Our Price: $24.80
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.81

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $76.00
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.39
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.34
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.65
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	Relay Relay	Current Stock: 1 Our Price: $44.63
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.18

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.39
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.27
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.22

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.63

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.34
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 11.0.23 - Differential

1968-1978 Lamborghini Espada USA Differential (11.0.23)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008101409	Special Screw M14x75	1 req	Avail to order Our Price: $33.45
2	002305138	Differential Strut Adjustment	1 req	Avail to order Our Price: $65.05
3	0B9501144	SILENTBLOC	4 req	Avail to order Our Price: $262.07
4	008401413	Flat Washer 14.3 Uni1750/Z	5 req	Current Stock: 11 Our Price: $2.00
5	008201406	Nut	4 req	Current Stock: 8 Our Price: $2.00
6	008201407	Nut	1 req	Avail to order Our Price: $2.72
7	008921406	NLA (No Longer Available)	1 req	*See Description
8	002305137	Differential Strut Adjustment	1 req	Avail to order Our Price: $59.61
9	008201807	18x1 Right Nut	1 req	Avail to order Our Price: $27.71
10	008101418	Special Screw M14x78.5	1 req	Avail to order Our Price: $46.77
11	008101815	This item is no longer available	3 req
12	008411005	Washer D.10.5 Uni 1751/F	4 req	Avail to order Our Price: $2.00
13	002302182	Differential Oil Breather Pipe	1 req	Avail to order Our Price: $254.18
14	002305118	Differential Breather Pipe	1 req	Avail to order Our Price: $16.14
15	008401414	Copper Washer 14x24x0,04513888	1 req	Current Stock: 27 Our Price: $2.62
16	N10689901	HEX.NUT	3 req	Current Stock: 5 Our Price: $2.00
17	008400501	Washer 5.8x18x2	2 req	Avail to order Our Price: $2.00
18	008406502	This item is no longer available	1 req
19	N10430103	HEXALOBULAR SOCKET	3 req	Current Stock: 21 Our Price: $2.00
20	002305145	Differential Strut Mounting	1 req	Avail to order Our Price: $68.26
21	008101814	This item is no longer available	1 req
22	002304834	Differential Adjustment Shim 1	1 req	Avail to order Our Price: $27.14
23	008418807	This item is no longer available	15 req
24	008100827	Screw M8x25 Uni 5739/8g/Zg	15 req	Current Stock: 14 Our Price: $2.00
25	008934201	Plug C 1019 D 42x2	1 req	Avail to order Our Price: $2.00
26	WHT000768	SPRING WASHER	7 req	Current Stock: 17 Our Price: $2.14
27	008101022	Screw M10x1.5x35 Uni5737/	7 req	Avail to order Our Price: $4.96
28	008932205	Plug 16x1.5	1 req	Avail to order Our Price: $8.85
29	002304883	Rear Differential Cover	1 req	Avail to order Our Price: $682.82
30	002305809	Differential Breather Cage	1 req	Avail to order Our Price: $63.21
31	002304877	Differential Outer Box	1 req	Avail to order Our Price: $1,953.07
32	008101411	Screw 14x1.5x85 Uni 5738/8	3 req	Current Stock: 1 Our Price: $7.58
33	008401413	Flat Washer 14.3 Uni1750/Z	8 req	Current Stock: 11 Our Price: $2.00
34	086301141A	Magnetic Plug 22x1.5	1 req	Avail to order Our Price: $39.91
35	008931001	This item is no longer available	1 req
36	002303926	Differential Adjustment Shim	1 req	Avail to order Our Price: $10.70
37	002309199	Differential Front Mount	1 req	Avail to order Our Price: $471.13
38	008291008	This item is no longer available	2 req
39	N91116801	WASHER	2 req	Current Stock: 1 Our Price: $8.93
40	008181016	This item is no longer available	2 req
41	008921413	NLA (No Longer Available)	2 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
