1968-1978 Lamborghini Espada USA Exhaust (20.0.44)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $113.58
004504532	Belt Belt	Current Stock: 1 Our Price: $55.72
001604645	Belt Belt	Current Stock: 3 Our Price: $24.80
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.81

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $76.00
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.39
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.34
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.65
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	Relay Relay	Current Stock: 1 Our Price: $44.63
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.18

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.39
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.27
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.22

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.63

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.34
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 20.0.44 - Exhaust

1968-1978 Lamborghini Espada USA Exhaust (20.0.44)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004405052	Rh Rear Muffler	1 req	Avail to order Our Price: $2,690.18
2	004405053	Lh Rear Muffler	1 req	Avail to order Our Price: $2,690.18
3	008200804	Nut	2 req	Current Stock: 7 Our Price: $2.00
4	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
5	008100827	Screw M8x25 Uni 5739/8g/Zg	2 req	Current Stock: 14 Our Price: $2.00
6	008200907	This item is no longer available	12 req
7	008410906	This item is no longer available	12 req
8	004404026	Exhaust Manifold Seal	2 req	Avail to order Our Price: $36.64
9	N01033520	HEXAGON HEAD BOLT	12 req	Current Stock: 6 Our Price: $2.00
10	001101178	Exhaust Pipe Seal	8 req	Avail to order Our Price: $31.02
11	004401530	Muffler Manifold Seal	4 req	Avail to order Our Price: $37.23
12	004610690	This item is no longer available	1 req
12	004409463	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
13	004410394	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
13	004405048	Lh Rear Exhaust Manifold	1 req	Avail to order Our Price: $17,910.05
13	004405046	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
14	004403046	This item is no longer available	1 req
15	004409462	Rh Central Muffler	1 req	Avail to order Our Price: $4,622.39
16	004405047	Rh Rear Exhaust Manifold	1 req	Avail to order Our Price: $17,910.05
16	004410393	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
17	004405045	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
18	004405143	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
19	N10430103	HEXALOBULAR SOCKET	4 req	Current Stock: 21 Our Price: $2.00
20	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	12 req	Current Stock: 8 Our Price: $2.00
21	N0211963	HEX.HEAD CLAMPING	12 req	Avail to order Our Price: $2.00
22	008481007	This item is no longer available	3 req
23	008201006	M10Self Locking Nut	3 req	Avail to order Our Price: $8.85
24	004405854	This item is no longer available	1 req
25	004405855	This item is no longer available	1 req
26	008100835	Screw M8x65 Uni 5737/8g	2 req	Current Stock: 20 Our Price: $3.39
27	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $2.00
28	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.43
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
