1968-1978 Lamborghini Espada USA Engine Block (8.0.18)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.37
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.64
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.29
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.11

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 8.0.18 - Engine Block

1968-1978 Lamborghini Espada USA Engine Block (8.0.18)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008201101	NLA (No Longer Available)	28 req	*See Description
2	008411101	Snap Ring 11.5x21x1.2	28 req	Avail to order Our Price: $9.02
3	008301212	Head Fastening Stud M11x100	28 req	Current Stock: 1 Our Price: $12.22
4	001101816	Cylinder Head Gasket	1 req	Avail to order Our Price: $466.71
5	001801880	Cylinder Liner	12 req	Avail to order Our Price: $1,238.10
6	008932202	Plug 22mb	1 req	Avail to order Our Price: $92.29
7	008802002	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
8	008932401	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
9	001101815	Cylinder Head Gasket Right Side	1 req	Avail to order Our Price: $466.71
10	008208404	This item is no longer available	7 req
11	001410402	This item is no longer available	7 req
12	008300608	NLA (No Longer Available)	3 req	*See Description
13	001829009	GROMMET	1 req	Current Stock: 2 Our Price: $71.65
14	001802054	Rear Crankshaft Cover	1 req	Avail to order Our Price: $1,001.89
15	001800294	CRANKCASE REAR COVERSEAL	1 req	Avail to order Our Price: $27.66
16	008851101	Bushing 8.5x11x14 Mm	2 req	Avail to order Our Price: $41.40
17	001808546	This item is no longer available	1 req
18	008850804	Reference Pin 8x14 C40	2 req	Avail to order Our Price: $20.58
19	008200884	This item is no longer available	2 req
20	008300415	This item is no longer available	2 req
21	008300608	NLA (No Longer Available)	2 req	*See Description
22	008300814	Stud M8x18 Uni 5914 8g Zd	2 req	Current Stock: 5 Our Price: $7.68
23	008300411	This item is no longer available	2 req
24	008650805	This item is no longer available	2 req
25	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
26	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $2.00
27	WHT003165	TAP END STUD	2 req	Current Stock: 3 Our Price: $2.00
28	001804836	This item is no longer available	1 req
29	008800701	This item is no longer available	1 req
30	008300818	Stud M8x30 Uni 5911 8g Zd	2 req	Avail to order Our Price: $5.06
31	008301213	Special Stud M12x98	2 req	Avail to order Our Price: $69.25
32	001800311	Oil Sump Seal	1 req	Avail to order Our Price: $85.88
33	008301214	Special Stud M12x94	12 req	Avail to order Our Price: $40.41
34	008300817	Stud M8x1x60 Uni 5919 10k	12 req	Avail to order Our Price: $19.54
35	001800297	This item is no longer available	1 req
36	008401502	Copper Washer 15x28x2	2 req	Avail to order Our Price: $19.31
37	008931403	Bronze Plug	2 req	Avail to order Our Price: $58.45
38	001800296	This item is no longer available	5 req
39	001800295	This item is no longer available	1 req
40	008410605	Corrugated Washer D 6	14 req	Avail to order Our Price: $2.91
41	008200805	M8x1x8 8g/B Nut	14 req	Avail to order Our Price: $2.00
42	07L301155	BUSH	14 req	Avail to order Our Price: $62.01
43	001804497	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
44	008802901	This item is no longer available	1 req
45	001804650	Espada Oil Sump Bulkhead	1 req	Avail to order Our Price: $345.89
46	WHT003055	Washer 13x24x1.2 Din137/B C72	14 req	Current Stock: 10 Our Price: $2.00
47	001201210	This item is no longer available	14 req
48	001805141	Gearbox/Sump Bracket	1 req	Avail to order Our Price: $75.59
49	008410808	Brake Lock Plate	3 req	Avail to order Our Price: $20.00
50	008100828	Screw M8x45 Uni 5739/5s/Z	3 req	Avail to order Our Price: $2.00
51	001801333	OIL & COOLANT TEMPERATURE THERMOMETER	1 req	Avail to order Our Price: $150.37
52	008300608	NLA (No Longer Available)	16 req	*See Description
53	N01152427	WASHER	18 req	Current Stock: 16 Our Price: $2.00
54	008200605	Simmon Nut for urama	18 req	Current Stock: 50 Our Price: $3.06
55	001813126	Espada Oil Sump	1 req	Avail to order Our Price: $1,707.10
56	086301141A	Magnetic Plug 22x1.5	1 req	Avail to order Our Price: $39.91
57	N01118312	HEX.HEAD CLAMPING NUT	3 req	Avail to order Our Price: $2.17
58	N01152427	WASHER	3 req	Current Stock: 16 Our Price: $2.00
59	WHT003165	TAP END STUD	3 req	Current Stock: 3 Our Price: $2.00
60	001804885	Oil Dipstick Pipe	1 req	Avail to order Our Price: $35.34
61	008200401	M4 Uni 5587/5s/Z	12 req	Avail to order Our Price: $2.00
62	008410402	Washer D.4.3 Uni 1751 /Zd	12 req	Current Stock: 15 Our Price: $2.00
63	008300401	Special Stud M4x7	12 req	Avail to order Our Price: $2.00
64	001883094	This item is no longer available	1 req
65	001113125	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
66	008402607	This item is no longer available	1 req
67	008202601	M26x1.5 Special Nut	1 req	Avail to order Our Price: $20.13
68	008401610	Annealed Copper Washer 16x22x0	1 req	Current Stock: 25 Our Price: $11.23
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
