TAV: 2.0.12 - Timing and Cams

1968-1978 Lamborghini Espada USA Timing and Cams (2.0.12)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001212772	Lh Exhaust Camshaft	1 req	Avail to order Our Price: $2,914.73
1	001200878	Lh Exhaust Camshaft	1 req	Avail to order Our Price: $1,932.21
2	001205195	NLA (No Longer Available)	2 req	*See Description
3	001202694	Camshaft Pinion	4 req	Avail to order Our Price: $1,406.05
4	001200348	Dowel Check Washer	2 req	Avail to order Our Price: $18.86
5	008411701	Snap Ring 17x30x1.5 Din137/B	3 req	Current Stock: 2 Our Price: $2.91
6	008101608	Screw M16x35 Uni 5740/8g	1 req	Avail to order Our Price: $18.06
7	001201964	Dowel	2 req	Avail to order Our Price: $53.31
8	001212771	Lh Intake Camshaft	1 req	Avail to order Our Price: $2,914.73
8	001200882	Lh Intake Camshaft	1 req	Avail to order Our Price: $3,936.00
9	008522202	NLA (No Longer Available)	2 req	*See Description
10	001207300	Coolant Pump Guide Gear	1 req	Avail to order Our Price: $375.72
11	001212769	Rh Intake Camshaft	1 req	Avail to order Our Price: $2,914.73
11	001200880	Rh Intake Camshaft	1 req	Avail to order Our Price: $3,936.00
12	001212770	Rh Exhaust Camshaft	1 req	Avail to order Our Price: $2,914.73
13	001201965	Cam Gear Dowel	2 req	Avail to order Our Price: $89.33
14	001605339	Distributor P.T.O.	2 req	Avail to order Our Price: $216.93
15	001605340	Distributor PTO Retainer Washe	2 req	Avail to order Our Price: $37.28
16	008801502	Bushing 15x17x12 mm	2 req	Avail to order Our Price: $17.89
17	N10738501	Elastic Pin 3x32 Din1481	2 req	Current Stock: 9 Our Price: $2.00
18	008701601	Screw 16x1.5x23	2 req	Avail to order Our Price: $27.73
19	001202917	Valve Bowl	24 req	Avail to order Our Price: $343.16
20	001201072	Valve Clearance Shim	24 req	Avail to order Our Price: $45.63
21	001200233	Valve Retainer Cotters	48 req	Avail to order Our Price: $34.17
22	001200228	Valve Plate	24 req	Avail to order Our Price: $441.31
23	001213132	Valve Inner Spring	24 req	Avail to order Our Price: $38.73
24	001213133	Valve Outer Spring	24 req	Avail to order Our Price: $48.31
24	001202083	Valve Outer Spring	24 req	Avail to order Our Price: $43.39
25	001202903	Valve Spring Washer	24 req	Avail to order Our Price: $50.47
26	001204414	Valve Guide	12 req	Current Stock: 17 Our Price: $73.05
27	001210285	Intake Valve Seat	12 req	Current Stock: 12 Our Price: $30.92
27	001200231	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	12 req	*See Description
28	001201773	This item is no longer available	12 req
29	001201774	Exhaust Valve	12 req	Avail to order Our Price: $311.39
30	001210286	Exhaust Valve Seat	12 req	Current Stock: 12 Our Price: $30.03
31	008200605	Simmon Nut for urama	2 req	Current Stock: 50 Our Price: $3.06
32	008300613	Stud M6x14 Uni 5911 8g/Z	2 req	Avail to order Our Price: $5.75
33	001200336	Cover	1 req	Avail to order Our Price: $421.93
34	008604201	Ring 43 mm Or	1 req	Current Stock: 9 Our Price: $2.00
35	008522202	NLA (No Longer Available)	2 req	*See Description
36	001202691	Chain Guide	1 req	Avail to order Our Price: $408.52
37	001207415	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
38	008523004	NLA (No Longer Available)	2 req	*See Description
39	001212825	Tightener Gear	2 req	Avail to order Our Price: $282.53
39	001204878	Chain Tightener Gear	2 req	Avail to order Our Price: $313.09
40	001202471	SEE PN: 8401813 AND 1219425	2 req	Avail to order Our Price: $460.69
41	001200340	Stopper Pin	2 req	Avail to order Our Price: $21.47
42	001207415	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
43	008603701	Or Ring	2 req	Current Stock: 14 Our Price: $2.00
44	001200342	Tightener AdjustmentFlange	2 req	Avail to order Our Price: $451.75
45	008601702	Ring 18 mm Or	2 req	Current Stock: 7 Our Price: $2.00
46	001202447	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
47	001200345	Tightener Dowel Check Washer	2 req	Avail to order Our Price: $88.42
48	008411303	Snap Ring 21x13x2.5 Uni 175 1	2 req	Current Stock: 6 Our Price: $3.29
49	008201213	12 Uni 210 8g Nut	2 req	Avail to order Our Price: $6.26
50	008300613	Stud M6x14 Uni 5911 8g/Z	4 req	Avail to order Our Price: $5.75
51	008300613	Stud M6x14 Uni 5911 8g/Z	4 req	Avail to order Our Price: $5.75
52	001200343	Distribution Adjustment Dowel	2 req	Avail to order Our Price: $31.09
53	008501704	Bearing	4 req	Avail to order Our Price: $57.22
54	001205400	Spacer	2 req	Avail to order Our Price: $283.28
55	001207360	NLA (No Longer Available)	2 req	*See Description
56	008601801	Ring 19 mm Or	2 req	Avail to order Our Price: $12.42
57	001200333	This item is no longer available	2 req
58	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
58	008300613	Stud M6x14 Uni 5911 8g/Z	4 req	Avail to order Our Price: $5.75
59	008100625	Screw M6x16 Uni 5739/8g/Z	4 req	Avail to order Our Price: $140.00
59	008200605	Simmon Nut for urama	4 req	Current Stock: 50 Our Price: $3.06
60	008101622	Special Screw M16x1.5x35	1 req	Avail to order Our Price: $11.93
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
