1968-1978 Lamborghini Espada USA Air Conditioner (21.0.45)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.37
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.64
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.29
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.11

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 21.0.45 - Air Conditioner

1968-1978 Lamborghini Espada USA Air Conditioner (21.0.45)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004504637	Compressor Shim Plate	20 req	Avail to order Our Price: $9.25
2	004505585	Isobar Valve/Compressor Pipe	1 req	Avail to order Our Price: $69.41
3	004510015	Isobar Valve	1 req	Avail to order Our Price: $354.84
4	008201008	Nut	4 req	Current Stock: 2 Our Price: $2.00
5	008401006	Washer 22x10.5x2.5 Uni 1734/5s	4 req	Current Stock: 1 Our Price: $2.00
6	004504533	Compressor Bracket Stud Bolts	4 req	Avail to order Our Price: $99.45
7	008101001	Screw M10x120uni 5737/65 8	1 req	Avail to order Our Price: $15.14
8	004505677	Compressor Strut Mount	1 req	Avail to order Our Price: $50.02
9	004505681	Compressor Strut Stud Bolt	1 req	Avail to order Our Price: $32.71
10	004505446	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
11	004504532	Belt	2 req	Current Stock: 1 Our Price: $55.61
12	008200401	M4 Uni 5587/5s/Z	1 req	Avail to order Our Price: $2.00
13	008410403	Washer D.4.3 Uni 1751/Z	1 req	Avail to order Our Price: $7.60
14	008201011	M10 Uni 5589-65/8g Nut	2 req	Avail to order Our Price: $21.40
15	004511440	This item is no longer available	1 req
16	004508753	Isobar Valve/Condenser Battery	1 req	Avail to order Our Price: $133.00
16	004506865	This item is no longer available	1 req
17	004507577	This item is no longer available	1 req
18	004507529	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
19	008611002	NLA	2 req	*See Description
20	004505977	NLA	2 req	*See Description
21	N0211963	HEX.HEAD CLAMPING	2 req	Avail to order Our Price: $2.00
22	004508754	Filter/Condenser Battery Pipe	1 req	Avail to order Our Price: $105.12
22	004507578	Evaporator Filter Pipe	1 req	Avail to order Our Price: $232.59
22	004508981	Filter/Evaporator Pipe	1 req	Avail to order Our Price: $213.21
23	004505322	SEE PN: 4535411 AND 37126-27	1 req	Avail to order Our Price: $120.28
24	004505600	Cleaner Bracket	1 req	Avail to order Our Price: $12.12
25	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $2.00
26	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.17
27	004507579	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
27	004506034	Condenser/Filter Pipe	1 req	Avail to order Our Price: $114.96
28	004505247	NLA (No Longer Available)	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
