TAV: 23.0.47 - Air Conditioning

1968-1978 Lamborghini Espada USA Air Conditioning (23.0.47)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004708794	Defroster Flap	2 req	Avail to order Our Price: $54.70
2	004708793	Defroster Flap Pin	1 req	Avail to order Our Price: $54.70
3	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $2.00
4	008820101	Split Pin 1.8x12 Uni 1336a	1 req	Avail to order Our Price: $2.91
5	004708773	Air Vent Retainer	4 req	Avail to order Our Price: $243.77
6	004710260	This item is no longer available	2 req
7	004708779	This item is no longer available	1 req
7	004708781	This item is no longer available	1 req
8	N10430103	HEXALOBULAR SOCKET	3 req	Current Stock: 21 Our Price: $2.00
9	008410503	Washer Din 137a 5.3x10 Zgd.	3 req	Avail to order Our Price: $2.00
10	N01020717	HEXAGON HEAD BOLT	2 req	Current Stock: 4 Our Price: $2.00
11	008410503	Washer Din 137a 5.3x10 Zgd.	2 req	Avail to order Our Price: $2.00
12	N10689901	HEX.NUT	2 req	Current Stock: 5 Our Price: $2.00
13	004708776	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
14	004508459	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
15	004708787	Windscreen Air Delivery Corrug	2 req	Avail to order Our Price: $104.96
16	008630206	This item is no longer available	4 req
17	008931405	Scroll Hole Plug	2 req	Avail to order Our Price: $2.91
18	004506860	Expansion Valve	1 req	Avail to order Our Price: $105.24
19	004710824	Heater Coolant InletUnion	1 req	Avail to order Our Price: $81.46
20	004710091	Battery/Cock Pipe Seal	2 req	Avail to order Our Price: $15.54
21	006753080	Sheath Clamp	7 req	Avail to order Our Price: $2.62
22	004710876	This item is no longer available	1 req
23	008700310	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
24	004708760	Air Choke	2 req	Avail to order Our Price: $511.29
25	004508754	Filter/Condenser Battery Pipe	1 req	Avail to order Our Price: $105.12
26	004708791	This item is no longer available	1 req
27	004508753	Isobar Valve/Condenser Battery	1 req	Avail to order Our Price: $133.00
28	004708771	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
29	008410503	Washer Din 137a 5.3x10 Zgd.	4 req	Avail to order Our Price: $2.00
30	N10689901	HEX.NUT	4 req	Current Stock: 5 Our Price: $2.00
31	008300506	Special Stud M5x80	1 req	Avail to order Our Price: $94.67
32	008400501	Washer 5.8x18x2	2 req	Avail to order Our Price: $2.00
33	008410503	Washer Din 137a 5.3x10 Zgd.	2 req	Avail to order Our Price: $2.00
34	N10689901	HEX.NUT	2 req	Current Stock: 5 Our Price: $2.00
35	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
36	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
37	008100630	Screw M6x14 Uni 5739/8g/Z	4 req	Avail to order Our Price: $2.00
38	004708785	Air Vent Bracket	2 req	Avail to order Our Price: $82.05
38	004708784	This item is no longer available	2 req
39	004708770	Rh Impeller	1 req	Avail to order Our Price: $273.49
40	008200401	M4 Uni 5587/5s/Z	8 req	Avail to order Our Price: $2.00
41	008410402	Washer D.4.3 Uni 1751 /Zd	8 req	Current Stock: 15 Our Price: $2.00
42	008921201	Mount Rocam F.81011/D.2001	4 req	Avail to order Our Price: $26.69
43	004708774	Heater Motor Bracket	2 req	Avail to order Our Price: $82.05
44	N01020717	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $2.00
45	006107032	Heater Motor BracketClamp	2 req	Avail to order Our Price: $22.74
46	008410502	Washer D.5.3 Uni 1751/Zd	4 req	Current Stock: 33 Our Price: $2.00
47	N10689901	HEX.NUT	4 req	Current Stock: 5 Our Price: $2.00
48	006107031	NLA (No Longer Available)	1 req	*See Description
49	004708916	Lh Impeller	1 req	Avail to order Our Price: $273.49
50	004708775	Heating Scroll Seal	2 req	Avail to order Our Price: $40.64
51	004708772	This item is no longer available	1 req
52	008410502	Washer D.5.3 Uni 1751/Zd	8 req	Current Stock: 33 Our Price: $2.00
53	N01020717	HEXAGON HEAD BOLT	8 req	Current Stock: 4 Our Price: $2.00
54	008100508	Screw M5x10 Uni 5739/5s/Z	5 req	Avail to order Our Price: $6.79
55	008410502	Washer D.5.3 Uni 1751/Zd	5 req	Current Stock: 33 Our Price: $2.00
56	N10689901	HEX.NUT	5 req	Current Stock: 5 Our Price: $2.00
57	004708782	Condenser Battery Seal	1 req	Avail to order Our Price: $51.14
58	004708783	Heater/Tunnel Seal	1 req	Avail to order Our Price: $51.14
59	004708777	Scroll Air Manifold	1 req	Avail to order Our Price: $1,297.55
60	004710820	This item is no longer available	1 req
61	004710823	Union/Heater Cock Pipe	1 req	Avail to order Our Price: $34.74
62	004708604	Flap Lever Bracket	2 req	Avail to order Our Price: $432.52
63	004708792	This item is no longer available	1 req
64	004710055	NLA (No Longer Available)	1 req	*See Description
65	006107228	Lever Pin To Mount	4 req	Avail to order Our Price: $13.98
66	006107235	Heater Friction Washer	8 req	Avail to order Our Price: $11.18
67	006110075	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
68	004710825	Heater Cock Lever Bracket	1 req	Current Stock: 2 Our Price: $729.78
69	004710822	Heater Cock Lever Assembly	1 req	Avail to order Our Price: $135.71
70	008700503	Screw M5x8 Uni 6107 5s/Z	8 req	Avail to order Our Price: $2.00
71	008100508	Screw M5x10 Uni 5739/5s/Z	2 req	Avail to order Our Price: $6.79
72	008410503	Washer Din 137a 5.3x10 Zgd.	2 req	Avail to order Our Price: $2.00
73	N10689901	HEX.NUT	2 req	Current Stock: 5 Our Price: $2.00
74	004708780	Sheath Clamp Plate	1 req	Avail to order Our Price: $27.36
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
