TAV: 7.1.17 - Water System

1968-1978 Lamborghini Espada USA Water System (7.1.17)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	001709968	This item is no longer available	1 req
1	003101941	Banjo Bolt Fitting	1 req	Avail to order Our Price: $4.42
2	008401610	Annealed Copper Washer 16x22x0	1 req	Current Stock: 25 Our Price: $10.58
3	001708903	Heating Coolant Delivery Conne	1 req	Avail to order Our Price: $351.86
4	001701646	NLA (No Longer Available)	1 req	*See Description
5	008401610	Annealed Copper Washer 16x22x0	4 req	Current Stock: 25 Our Price: $10.58
6	001710431	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
7	001709894	This item is no longer available	1 req
7	001702817	Thermostat Valve	6 req	Avail to order Our Price: $514.04
8	008835004	Clamp	6 req	Avail to order Our Price: $10.28
9	001710100	Radiator/Thermostat Pipe	1 req	Avail to order Our Price: $26.79
9	001704585	Radiator Inlet Sleeve	1 req	Avail to order Our Price: $42.89
10	001710466	This item is no longer available	1 req
10	001704483	This item is no longer available	1 req
11	008100617	Screw M6x18 Uni 57395s	6 req	Avail to order Our Price: $6.29
12	N01152427	WASHER	6 req	Avail to order Our Price: $2.00
13	N01118312	HEX.HEAD CLAMPING NUT	6 req	Current Stock: 4 Our Price: $2.01
14	008100831	Screw M8x30 Uni 5737/8g/Z	4 req	Avail to order Our Price: $2.00
15	WHT001942	WASHER	8 req	Current Stock: 13 Our Price: $3.30
16	WHT001189	RUBBER WASHER MOUNT	4 req	Avail to order Our Price: $3.95
17	001705796	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
18	001701592	Radiator Shim	4 req	Avail to order Our Price: $19.62
19	001701495	Supplementary Reservoir Bracket	4 req	Current Stock: 1 Our Price: $55.25
20	008200804	Nut	2 req	Current Stock: 7 Our Price: $2.00
21	008602303	Ring 24 mm Or	2 req	Current Stock: 18 Our Price: $2.00
22	N01118312	HEX.HEAD CLAMPING NUT	4 req	Current Stock: 4 Our Price: $2.01
23	N01152427	WASHER	4 req	Avail to order Our Price: $2.00
24	008300608	NLA (No Longer Available)	4 req	*See Description
25	008200402	M4 Brass Special Nut	3 req	Current Stock: 2 Our Price: $2.65
26	008410402	Washer D.4.3 Uni 1751 /Zd	3 req	Current Stock: 17 Our Price: $2.00
27	001701645	SEE PN: 1724565 AND 1724564	1 req	Avail to order Our Price: $48.00
28	001705504	Engine Thermal Contact Seal	1 req	Avail to order Our Price: $28.31
29	001704590	Espada Radiator Plug	1 req	Avail to order Our Price: $97.50
30	001801333	NLA (No longer Available to order)	1 req	*See Description
31	001704296	Coolant Cap	1 req	Avail to order Our Price: $146.25
32	008830204	Clamp	3 req	Avail to order Our Price: $9.37
33	001710432	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
33	001704587	Auxiliary Reservoir Radiator P	1 req	Avail to order Our Price: $24.09
34	008610601	Grommet 6x10x1.5 mm	3 req	Avail to order Our Price: $5.29
35	WHT002961	WASHER	3 req	Current Stock: 39 Our Price: $2.00
36	N01118312	HEX.HEAD CLAMPING NUT	3 req	Current Stock: 4 Our Price: $2.01
37	001709974	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
38	001708139	This item is no longer available	1 req
39	001701906	Tap Washer	1 req	Avail to order Our Price: $2.00
40	001701905	Radiator Tap	1 req	Avail to order Our Price: $109.76
41	001705153	Fan Plug	6 req	Avail to order Our Price: $3.51
42	001704947	NLA (No Longer Available)	2 req	*See Description
43	410801988	Grommet mm 12x20x1.5mm	1 req	Avail to order Our Price: $16.22
44	008830108	Clamp Din 7 2571	1 req	Avail to order Our Price: $6.37
45	001701803	FAN GASKET	2 req	Avail to order Our Price: $115.56
46	001701631	Radiator Fan Rear Washer	2 req	Avail to order Our Price: $17.59
47	001709981	This item is no longer available	1 req
48	001705649	Radiator Fan Motor Mount	1 req	Avail to order Our Price: $1,138.12
49	001701405	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
50	001705166	NLA	2 req	*See Description
51	008105650	This item is no longer available	8 req
52	001701531	Radiator Fan Front Washer	2 req	Avail to order Our Price: $39.67
53	001709979	Supplementary Reservoir Side B	4 req	Avail to order Our Price: $16.88
54	001710007	This item is no longer available	1 req
55	001710433	Head/Thermostat Union Pipe	1 req	Avail to order Our Price: $92.21
56	001709991	NLA (No Longer Available)	1 req	*See Description
57	001710465	This item is no longer available	1 req
58	001710464	Radiator/Supplementary Reservo	1 req	Avail to order Our Price: $6.65
59	N91116801	WASHER	2 req	Current Stock: 1 Our Price: $8.40
60	008830206	Clamp	2 req	Current Stock: 1 Our Price: $21.66
61	008700406	Screw 3/16x15	1 req	Avail to order Our Price: $2.00
62	008830204	Clamp	2 req	Avail to order Our Price: $9.37
63	N01020717	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $2.00
64	008400501	Washer 5.8x18x2	4 req	Avail to order Our Price: $2.00
65	008610701	Grommet 7x13x2 mm	4 req	Avail to order Our Price: $32.10
66	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
67	008100620	Screw M6x12 Uni 5739/5s/Z	4 req	Avail to order Our Price: $6.29
68	008200403	Nut	8 req	Avail to order Our Price: $2.65
69	008400501	Washer 5.8x18x2	16 req	Avail to order Our Price: $2.00
70	008610501	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
71	008200608	Nut	2 req	Avail to order Our Price: $6.37
72	008410502	Washer D.5.3 Uni 1751/Zd	4 req	Current Stock: 33 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
