1968-1978 Lamborghini Espada USA Brake System (14.31.32)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 6 Our Price: $48.16

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.37
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.64
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.29
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.11

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 14.31.32 - Brake System

1968-1978 Lamborghini Espada USA Brake System (14.31.32)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N01118312	HEX.HEAD CLAMPING NUT	4 req	Avail to order Our Price: $2.17
2	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
3	003204603	Rear Three-Way Pipe/Rh Hose	1 req	Avail to order Our Price: $69.41
4	003101450	Three-Way Union	3 req	Avail to order Our Price: $105.56
5	003204602	Rear Three-Way Pipe/Lh Hose	1 req	Avail to order Our Price: $69.41
6	003201483	REAR BRAKE HOSE FLEXIBLE TUBE FR.POS.64047356	2 req	Current Stock: 1 Our Price: $152.60
7	008411004	Corrugated Washer	8 req	Avail to order Our Price: $2.91
8	003107923	Brake/Clutch Reservoir Clamp	1 req	Avail to order Our Price: $16.63
9	003103947	Brake Oil Reservoir	3 req	Avail to order Our Price: $60.91
10	N0211963	HEX.HEAD CLAMPING	3 req	Avail to order Our Price: $2.00
11	003104587	This item is no longer available	1 req
11	003107922	Brake/Clutch Reservoir Clamp	1 req	Avail to order Our Price: $21.32
12	008830204	Clamp	4 req	Avail to order Our Price: $10.06
13	003107709	NLA (No Longer Available)	1 req	*See Description
13	003107708	Safety Device Pipe/USA Lh Hose	1 req	Avail to order Our Price: $69.41
14	003112856	This item is no longer available	1 req
14	003107706	Safety Device Pipe/Rh Front Ho	1 req	Avail to order Our Price: $69.41
14	003110290	Safety Device Pipe/Front Three	1 req	Avail to order Our Price: $20.28
15	003104600	Lh Three-Way Hose	1 req	Avail to order Our Price: $22.37
16	008200903	3/8X24 Unf Special Nut	8 req	Avail to order Our Price: $6.87
17	003101453	Front Brake Hose FLEXIBLE PIPE FR.ANT.6404736	2 req	Current Stock: 1 Our Price: $112.85
18	003207707	This item is no longer available	1 req
18	003212857	This item is no longer available	1 req
18	003210281	This item is no longer available	1 req
19	008610802	Grommet 8x18x2 mm	5 req	Avail to order Our Price: $9.36
20	003105399	Clutch Cylinder LoadPipe	2 req	Avail to order Our Price: $12.68
21	003205031	This item is no longer available	2 req
22	003104539	This item is no longer available	37 req
23	008830401	Brake & Clutch Pump Pipe Clamp	2 req	Avail to order Our Price: $2.91
24	003107781	This item is no longer available	1 req
25	003107780	Connection To SafetyDevice	1 req	Avail to order Our Price: $32.81
26	003112855	This item is no longer available	1 req
26	003107704	Safety Device Pipe/Front Brake	1 req	Avail to order Our Price: $69.41
26	003110289	Safety Device Pipe/Front Brake	1 req	Avail to order Our Price: $19.46
27	003210292	Safety Device Pipe/Rear Brake	1 req	Avail to order Our Price: $69.41
27	003212858	This item is no longer available	1 req
28	003107704	Safety Device Pipe/Front Brake	1 req	Avail to order Our Price: $69.41
28	003209508	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
29	003109505	Pipe	1 req	Avail to order Our Price: $69.41
30	003201449	Brake Light Check	1 req	Avail to order Our Price: $158.04
31	N91116801	WASHER	1 req	Current Stock: 1 Our Price: $8.93
32	008830205	Clamp	6 req	Avail to order Our Price: $7.91
33	003201511	Bolt	2 req	Avail to order Our Price: $53.68
34	003101513	Copper Washer 16.2x24x1	7 req	Avail to order Our Price: $2.00
37	003108507	This item is no longer available	1 req
37	003104604	Three-Way Pipe/BrakeBooster	1 req	Avail to order Our Price: $69.41
38	003104601	Rh Three-Way Hose	1 req	Avail to order Our Price: $69.41
39	003209325	Engine Pipe/Check Valve	1 req	Avail to order Our Price: $30.94
40	003209326	NLA (No Longer Available)	1 req	*See Description
40	003101518	Check Valve	1 req	Avail to order Our Price: $202.76
41	008411005	Washer D.10.5 Uni 1751/F	6 req	Avail to order Our Price: $2.00
42	008100912	Screw 3/8x7/8 Unf 2a3f	6 req	Avail to order Our Price: $2.91
43	003209302	This item is no longer available	2 req
44	003209330	Check Valve Pipe/Vacuum	1 req	Avail to order Our Price: $69.41
45	N0211963	HEX.HEAD CLAMPING	4 req	Avail to order Our Price: $2.00
46	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	4 req	Current Stock: 8 Our Price: $2.00
47	003206117	This item is no longer available	1 req
48	003204975	Vacuum Reservoir Three-Way Uni	1 req	Avail to order Our Price: $59.64
49	003204974	VACUUM RESERVOIR	1 req	Avail to order Our Price: $521.70
50	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $2.00
51	008100622	Screw M6x12 Uni 5739/8g	2 req	Avail to order Our Price: $6.79
52	003210274	Vacuum Pipe/Three-Way	1 req	Avail to order Our Price: $69.41
53	003210275	Three-Way Pipe/Rear Brake Boos	1 req	Avail to order Our Price: $69.41
54	003210276	Three-Way Pipe/FrontBrake Boos	1 req	Avail to order Our Price: $69.41
55	003308361	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
