1968-1978 Lamborghini Espada USA Wiper and Horn (31.0.15)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.37
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.64
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.29
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.11

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 31.0.15 - Wiper and Horn

1968-1978 Lamborghini Espada USA Wiper and Horn (31.0.15)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	WHT002961	WASHER	8 req	Current Stock: 38 Our Price: $2.00
2	008100618	Screw M6x20 Uni 5739/8g/Zd	4 req	Current Stock: 44 Our Price: $2.00
2	N90638803	HEXAGON HEAD BOLT	4 req	Avail to order Our Price: $2.00
3	006106692	Wiper Assembly	1 req	Avail to order Our Price: $1,367.17
3	008107879	This item is no longer available	1 req
4	006715004	This item is no longer available	2 req
5	006715234	This item is no longer available	1 req
5	006112701	This item is no longer available	1 req
6	006112700	This item is no longer available	2 req
6	006715235	Windsc.Wip.Blade	2 req	Avail to order Our Price: $68.74
7	006715008	This item is no longer available	2 req
8	006715007	This item is no longer available	2 req
9	006715006	This item is no longer available	2 req
10	006715237	Lh Windshield Wiper Arm	1 req	Avail to order Our Price: $310.64
10	006112702	This item is no longer available	1 req
11	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
12	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $2.00
13	008615011	This item is no longer available	2 req
14	008611812	This item is no longer available	2 req
15	008611829	This item is no longer available	1 req
16	008100133	This item is no longer available	1 req
17	006515243	This item is no longer available	1 req
18	008410502	Washer D.5.3 Uni 1751/Zd	3 req	Current Stock: 33 Our Price: $2.00
19	008108504	This item is no longer available	3 req
20	008112220	This item is no longer available	1 req
21	008815010	This item is no longer available	1 req
22	006715238	This item is no longer available	1 req
23	006106703	Wiper Assembly	1 req	Avail to order Our Price: $1,367.17
23	008106623	This item is no longer available	1 req
24	008106481	This item is no longer available	1 req
25	006617028	This item is no longer available	1 req
26	006617029	This item is no longer available	1 req
27	006108382	This item is no longer available	1 req
28	008109929	This item is no longer available	1 req
29	008103931	This item is no longer available	2 req
30	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.39
31	N90612002	PAN HEAD BOLT	2 req	Current Stock: 37 Our Price: $2.00
32	006107786	Horn	1 req	Avail to order Our Price: $263.15
33	006107787	This item is no longer available	1 req
34	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.39
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
