1968-1978 Lamborghini Espada USA Dashboard Instruments (27.0.60)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.37
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.64
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.29
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.11

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 27.0.60 - Dashboard Instruments

1968-1978 Lamborghini Espada USA Dashboard Instruments (27.0.60)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	006714162	This item is no longer available	1 req
2	006005338	NLA (No Longer Available)	1 req	*See Description
3	006007488	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
4	006009166	This item is no longer available	1 req
5	006007517	NLA (No Longer Available)	1 req	*See Description
6	006004393	ELECTRICAL TACHOMETER D 120	1 req	Current Stock: 1 Our Price: $551.15
7	006714074	This item is no longer available	1 req
8	006714075	This item is no longer available	8 req
9	006714073	This item is no longer available	1 req
10	006611030	Resistor As 532 12v 503000	1 req	Avail to order Our Price: $184.87
11	006714064	This item is no longer available	1 req
12	006714070	Panel Rheosteering	1 req	Avail to order Our Price: $150.59
13	006004395	This item is no longer available	1 req
14	006007490	This item is no longer available	1 req
15	006514093	This item is no longer available	3 req
16	006514091	This item is no longer available	2 req
17	006514111	This item is no longer available	2 req
18	006514090	This item is no longer available	2 req
19	006007491	This item is no longer available	1 req
20	006714091	Union	2 req	Avail to order Our Price: $126.20
21	006107276	This item is no longer available	2 req
22	006107499	This item is no longer available	1 req
23	006514092	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
24	006514094	This item is no longer available	2 req
25	004505249	NLA (No Longer Available)	1 req	*See Description
26	004506694	Lh Switch Knob Panel	2 req	Avail to order Our Price: $16.33
27	004506916	NLA (No longer available)	1 req	*See Description
28	006610061	NLA (No Longer Available)	1 req	*See Description
29	004505251	This item is no longer available	1 req
30	004506917	Switch Control Knob	1 req	Avail to order Our Price: $271.26
31	006610060	Heat.Switch	1 req	Avail to order Our Price: $51.14
32	006610059	Inn. Light Switch	1 req	Avail to order Our Price: $20.06
33	006610062	Defros Switch	1 req	Avail to order Our Price: $51.14
34	006714043	Rh Window Switch	1 req	Avail to order Our Price: $78.28
35	006714072	Button	1 req	Avail to order Our Price: $52.93
36	006610025	NLA (No Longer Available)	1 req	*See Description
37	006714044	Lh Window Switch	1 req	Avail to order Our Price: $87.70
38	006790120	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
39	003107782	NLA (No Longer Available)	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
