1968-1978 Lamborghini Espada USA Transmission Controls (12.2.24)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $113.58
004504532	Belt Belt	Current Stock: 1 Our Price: $55.72
001604645	Belt Belt	Current Stock: 3 Our Price: $24.80
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.81

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $76.00
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.39
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.34
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.65
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	Relay Relay	Current Stock: 1 Our Price: $44.63
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.18

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.39
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.27
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.22

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.63

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.34
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 12.2.24 - Transmission Controls

1968-1978 Lamborghini Espada USA Transmission Controls (12.2.24)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002410134	SEE PN: 2410654 AND 2420826	1 req	Avail to order Our Price: $38.73
2	002401723	Gear Lever Knob RingNut	1 req	Avail to order Our Price: $367.89
3	002403010	Gear Lever Assembly	1 req	Avail to order Our Price: $3,864.42
4	002401782	Gearbox & Clutch Box	2 req	Avail to order Our Price: $3,503.65
5	002405883	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
6	008838402	This item is no longer available	1 req
7	002402556	GEAR LEVER BOOT	1 req	Avail to order Our Price: $55.84
8	008830403	Band Clamp	1 req	Avail to order Our Price: $2.63
9	008108827	This item is no longer available	3 req
10	008410808	Brake Lock Plate	3 req	Avail to order Our Price: $19.97
11	002401755	3rd Speed/Reverse Control Fork	1 req	Avail to order Our Price: $797.66
12	008180816	This item is no longer available	1 req
13	008410603	Washer D.6.4 Uni 1751/Zd	1 req	Avail to order Our Price: $2.00
14	002402353	Gear Lever RetainingLever	1 req	Avail to order Our Price: $84.99
15	002401781	This item is no longer available	2 req
16	008401416	Washer 14.25x22 (variable thic	1 req	Current Stock: 3 Our Price: $2.92
17	008288804	This item is no longer available	1 req
18	008410804	This item is no longer available	1 req
19	002402358	This item is no longer available	1 req
20	002401763	Gear Lever Screw	1 req	Avail to order Our Price: $13.91
21	002401718	3rd-4th Speed Control Rod	1 req	Avail to order Our Price: $474.14
22	002401718	3rd-4th Speed Control Rod	1 req	Avail to order Our Price: $474.14
23	002401720	5th Speed-Rev Control Rod	1 req	Avail to order Our Price: $517.32
24	002401745	1/2/3/4th speed Control Fork	2 req	Avail to order Our Price: $1,257.41
25	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
26	008410882	This item is no longer available	1 req
27	008180622	This item is no longer available	1 req
28	008571602	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
29	002402354	Gear Lever Strut Plug	2 req	Avail to order Our Price: $4.38
30	002402351	Gear Lever Return Spring	2 req	Avail to order Our Price: $10.70
31	002402352	Gear Lever Return Rod	2 req	Avail to order Our Price: $28.69
32	002402349	Gear Lever Stop Rod	1 req	Avail to order Our Price: $28.69
33	002402358	This item is no longer available	1 req
34	008580601	O-Ring E 6 Uni 7435-75	1 req	Avail to order Our Price: $2.92
35	N10439201	Ball Rb 7.938/11 RivSkf	3 req	Current Stock: 19 Our Price: $2.00
36	86311249	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	3 req	*See Description
37	002401763	Gear Lever Screw	3 req	Avail to order Our Price: $13.91
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
