TAV: 5.0.15 - Oil Pump

1968-1978 Lamborghini Espada USA Oil Pump (5.0.15)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001507368	Engine Output Shaft	1 req	Avail to order Our Price: $1,263.75
2	008860502	Tab 5x5x18	1 req	Current Stock: 9 Our Price: $2.00
3	008860602	Tab 6x6x30 Unim 92	1 req	Current Stock: 6 Our Price: $44.45
4	008300615	Stud 6x22 Uni 5911/8g/Z	2 req	Avail to order Our Price: $21.87
5	001504903	Oil Pump Cover	1 req	Avail to order Our Price: $208.01
6	008522203	Bearing	1 req	Avail to order Our Price: $43.18
7	001504487	Idle Gear Pin	1 req	Avail to order Our Price: $77.03
8	001504499	Idle Gear	1 req	Avail to order Our Price: $3,127.64
9	008602304	O-RING	2 req	Avail to order Our Price: $9.56
10	008300610	SEE PN WHT003165	2 req	Avail to order Our Price: $26.67
10	008300612	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
11	N01152427	WASHER	2 req	Avail to order Our Price: $2.00
12	008200605	NLA (No Longer Available)	2 req	*See Description
13	WHT001197A	WASHER	21 req	Current Stock: 2 Our Price: $2.00
14	008100615	Screw M6x50 Uni 5737/8g	1 req	Avail to order Our Price: $6.29
15	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
15	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
16	008100607	Screw M6x18 Uni 5739/5s/Z	4 req	Avail to order Our Price: $6.29
16	008100625	Screw M6x16 Uni 5739/8g/Z	4 req	Avail to order Our Price: $130.24
17	001508485	Pump/Engine Oil Pipe	1 req	Avail to order Our Price: $445.98
18	N01100637	HEX.NUT	6 req	Current Stock: 18 Our Price: $2.00
19	008300610	SEE PN WHT003165	4 req	Avail to order Our Price: $26.67
20	WHT003079	Reference Pin 8h7x6.25x10	4 req	Avail to order Our Price: $33.17
21	001504500	Drive Gear	1 req	Avail to order Our Price: $133.96
22	001500898	Pump Seal	1 req	Avail to order Our Price: $30.60
23	001508489	Oil Pump Casing	1 req	Avail to order Our Price: $723.37
24	008700618	Screw M6x50 Uni 5931/8g/B	1 req	Avail to order Our Price: $2.00
25	008700619	Screw M6x80 Uni 5931/8g/Z	1 req	Avail to order Our Price: $6.37
26	001508565	NLA (No Longer Available)	1 req	*See Description
27	008402003	Washer	1 req	Avail to order Our Price: $14.52
28	008502001	Bearing	1 req	Avail to order Our Price: $40.39
29	008613002	Oil Seal 30x40x7 mm	1 req	Avail to order Our Price: $3.79
30	004504287	Oil Pump Flange Seal	1 req	Avail to order Our Price: $9.44
31	001506541	Bushing	1 req	Avail to order Our Price: $68.12
32	001507602	Oil Delivery Pipe Set	1 req	Avail to order Our Price: $47.82
33	008402401	Copper Washer D.24.5x35x1	1 req	Avail to order Our Price: $15.94
34	001507462	This item is no longer available	1 req
35	001504811	This item is no longer available	1 req
36	001503755	Oil Pressure Valve Plug	1 req	Avail to order Our Price: $25.88
37	008401804	Annealed Copper Washer 18.2x30	1 req	Current Stock: 1 Our Price: $4.36
38	001500927	Oil Pressure Valve Spring	1 req	Avail to order Our Price: $14.66
39	001500914	Oil Pressure Valve Piston	1 req	Avail to order Our Price: $85.78
40	001501128	Oil Filter Seal	1 req	Avail to order Our Price: $20.79
41	008700608	Screw 6x40 Uni 5931/8g/Z	4 req	Avail to order Our Price: $2.00
42	008700609	Screw 6x45 Uni 5931/8g/Zd	2 req	Avail to order Our Price: $2.00
43	008100616	Screw M6x16 Uni 5739/5s/Z	6 req	Avail to order Our Price: $2.00
44	001509899	Alternator & Compressor Drive	1 req	Avail to order Our Price: $949.25
44	001507909	Alternator & Compressor Drive	1 req	Avail to order Our Price: $185.85
45	001509899	Alternator & Compressor Drive	1 req	Avail to order Our Price: $949.25
46	008251801	M18x1.5x28 Self-Locking Ring N	1 req	Avail to order Our Price: $39.10
47	001501189	Over Pressure Valve Seat	1 req	Avail to order Our Price: $434.40
48	008911101	Valve Ball	1 req	Avail to order Our Price: $6.37
49	001501190	Oil Safety Valve Spring	1 req	Current Stock: 3 Our Price: $10.01
50	001501188	Oil Filter - Miura Countach Espada Jarama	1 req	Avail to order Our Price: $45.47
51	001509960	Oil Radiator	1 req	Avail to order Our Price: $2,087.19
52	001509992	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
53	001509993	Oil Radiator/Crankcase Pipe	1 req	Avail to order Our Price: $190.85
54	008100830	Screw M8x20 Uni 5739/8g/Z	4 req	Current Stock: 19 Our Price: $2.00
55	008200804	Nut	4 req	Current Stock: 7 Our Price: $2.00
56	008400901	Washer 9.5x18x2	4 req	Current Stock: 18 Our Price: $2.00
57	001510212	This item is no longer available	1 req
58	001508485	Pump/Engine Oil Pipe	1 req	Avail to order Our Price: $445.98
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
