1968-1978 Lamborghini Espada USA Rear Suspension (26.1.52)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.37
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.64
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.29
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.11

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 26.1.52 - Rear Suspension

1968-1978 Lamborghini Espada USA Rear Suspension (26.1.52)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008201603	Nut	4 req	Avail to order Our Price: $3.95
2	008401611	Washer 17x29x3 5s Uni 16592	4 req	Avail to order Our Price: $16.40
3	008401612	Washer 16.5x35x4	8 req	Avail to order Our Price: $11.93
4	008921601	Silbloc Riv X220 52470	4 req	Avail to order Our Price: $85.13
5	005208257	Rear Shock Absorber	2 req	Avail to order Our Price: $794.66
6	005206251	This item is no longer available	2 req
7	005208252	This item is no longer available	2 req
8	008101809	This item is no longer available	4 req
9	005208249	Rear Suspension Spring	2 req	Avail to order Our Price: $836.80
10	008201406	Nut	8 req	Current Stock: 8 Our Price: $2.00
11	008401413	Flat Washer 14.3 Uni1750/Z	8 req	Current Stock: 11 Our Price: $2.00
12	008401411	Washer 14x35x1-1.5-2	1 req	Avail to order Our Price: $11.59
13	008921411	Suspension Flanbloc	8 req	Avail to order Our Price: $183.57
14	008101408	Special Screw M14x80	8 req	Avail to order Our Price: $62.62
15	008202502	M25x1.5 Uni 4535-64 Nut	2 req	Avail to order Our Price: $92.31
16	008402502	Washer 25x39x4 Uni 1750 5s	2 req	Avail to order Our Price: $2.46
17	005208929	This item is no longer available	2 req
18	008578201	O-Ring I 82 Uni 3654	2 req	Current Stock: 12 Our Price: $3.65
19	008407502	Washer 75x82.5x0.05	1 req	Avail to order Our Price: $20.13
20	008407501	Washer 75x82.5x0.5	2 req	Avail to order Our Price: $6.87
21	008504502	NLA (No Longer Available)	2 req	*See Description
22	005207597	Rh Rear Hub Holder	1 req	Avail to order Our Price: $788.69
22	005205232	This item is no longer available	1 req
23	005207536	Drive Shaft Flange	2 req	Avail to order Our Price: $402.55
24	008200804	Nut	8 req	Current Stock: 7 Our Price: $2.00
25	N90179103	WASHER	8 req	Current Stock: 5 Our Price: $2.00
26	005109253	This item is no longer available	2 req
27	005100961	Upper Ball Joint	2 req	Avail to order Our Price: $240.79
28	008401306	Washer D.13x24x3 8g	2 req	Avail to order Our Price: $2.68
29	005209253	This item is no longer available	1 req
29	005209256	Lh Rear Upper Arm	1 req	Avail to order Our Price: $407.25
30	008850402	Reference Pin 4m6x8 C40	4 req	Avail to order Our Price: $6.87
31	005207636	NLA (No Longer Available)	1 req	*See Description
31	005207631	This item is no longer available	1 req
32	008921801	Roll Bar Mount 18	2 req	Current Stock: 2 Our Price: $42.30
33	008201006	M10Self Locking Nut	2 req	Avail to order Our Price: $8.80
34	005204568	This item is no longer available	1 req
35	005204572	Bar Mount Bracket	2 req	Avail to order Our Price: $152.35
36	008411005	Washer D.10.5 Uni 1751/F	2 req	Avail to order Our Price: $2.00
37	008101014	Screw M10x20 Uni 5739/8g	2 req	Avail to order Our Price: $13.46
38	008201007	M10x1Self-LockingNut	4 req	Avail to order Our Price: $8.80
39	005101047	Torsion Bar U-Bolt	2 req	Avail to order Our Price: $126.73
40	005204575	Bar Mount Plate	2 req	Avail to order Our Price: $108.51
41	008921802	U BOLT	2 req	Avail to order Our Price: $40.51
42	008201004	M10x1.25x6 Uni 5589 Nut	2 req	Avail to order Our Price: $2.00
43	008401003	This item is no longer available	2 req
44	005210752	Coolant Ring Housing	2 req	Avail to order Our Price: $141.06
44	005208353	This item is no longer available	4 req
45	008604802	This item is no longer available	4 req
46	008402801	Washer Wc 25 Du	4 req	Avail to order Our Price: $23.34
47	008802401	Bushing 24x27x30 mm	8 req	Avail to order Our Price: $10.03
48	005208155	Suspension Spring Bushing Shim	2 req	Avail to order Our Price: $124.94
49	008101801	Special Screw M18x1.5x195	2 req	Avail to order Our Price: $78.13
50	005112242	Wheel Outer Cover	2 req	Avail to order Our Price: $257.88
51	008880601	Hydraulic 273 A Grease Dispens	2 req	Current Stock: 8 Our Price: $2.00
52	005210753	Blade Set	4 req	Avail to order Our Price: $20.96
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
