1968-1978 Lamborghini Espada USA Front Suspension (25.0.51)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.01
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $112.42
004504532	Belt Belt	Current Stock: 1 Our Price: $54.12
004608478	Belt Belt	Avail to order Our Price: $110.33

Brakes

PN	Item	Diagram
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $76.40
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95

Drivetrain

PN	Item	Diagram
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Avail to order Our Price: $46.75
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $27.59

Fuel-Air

PN	Item
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $55.44
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $487.51
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
001605819	Relay Relay	Current Stock: 1 Our Price: $43.32
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $13.10
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.60
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.71
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $6.92
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.09

Gaskets

PN	Item
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $96.32
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,119.19
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $50.62

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,258.33

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $66.73
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $145.52
002409171	DISCONTINUED - NLA Reverse Light Switch		Avail to order Our Price: $228.89

Open All

Select Group and TAV

< Previous Next >

TAV: 25.0.51 - Front Suspension

1968-1978 Lamborghini Espada USA Front Suspension (25.0.51)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	005106981	Odometer Flexible Gear	1 req	Avail to order Our Price: $20.35
2	005106968	Front Wheel Hub	2 req	Avail to order Our Price: $1,391.02
3	008578201	O-Ring I 82 Uni 3654	2 req	Current Stock: 12 Our Price: $3.57
4	008407502	Washer 75x82.5x0.05	1 req	Avail to order Our Price: $19.54
5	008407501	Washer 75x82.5x0.5	2 req	Avail to order Our Price: $6.64
6	008504502	NLA (No Longer Available)	2 req	*See Description
7	005110299	Rh Front Stub Axle	1 req	Avail to order Our Price: $647.05
7	005107598	Rh Front Stub Axle	1 req	Avail to order Our Price: $688.80
7	005110303	Lh Front Stub Axle	1 req	Avail to order Our Price: $647.05
8	008700607	Screw Eslok M6x16 Uni 5927	2 req	Avail to order Our Price: $2.24
9	008610801	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	008204501	M45x1.5 Uni 4535-64 Nut	2 req	Avail to order Our Price: $141.19
11	005108216	Odometer Flange	1 req	Avail to order Our Price: $44.22
11	005107574	Cover	1 req	Avail to order Our Price: $39.81
12	005108215	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
13	005106107	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
14	WHT001197A	WASHER	2 req	Current Stock: 2 Our Price: $0.29
15	N10546402	HEXALOBULAR SOCKET	2 req	Current Stock: 5 Our Price: $0.77
16	005201355	This item is no longer available	4 req
17	005107925	This item is no longer available	4 req
17	005201354	This item is no longer available	4 req
17	005205208	WHEEL TYRE	4 req	Avail to order Our Price: $3,611.73
18	008101207	Special Screw	20 req	Avail to order Our Price: $20.58
19	005109106	This item is no longer available	4 req
19	005107642	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
20	005820101	This item is no longer available	1 req
21	008830111	NLA (No Longer Available)	1 req	*See Description
22	005109581	Odometer Wire RHD	1 req	Current Stock: 1 Our Price: $375.72
23	005112242	Wheel Outer Cover	2 req	Avail to order Our Price: $249.71
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
