1968-1978 Lamborghini Espada USA Engine Crank (4.0.14)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 6 Our Price: $48.16

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.37
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.64
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.29
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.11

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.33
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 4.0.14 - Engine Crank

1968-1978 Lamborghini Espada USA Engine Crank (4.0.14)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001402908	Upper Segment	12 req	Avail to order Our Price: $152.35
2	001402907	Lower Segment	12 req	Avail to order Our Price: $115.79
3	001402906	Oil Scraper	12 req	Avail to order Our Price: $80.27
4	001413189	This item is no longer available	12 req
4	001408017	Piston D.82 Fino Alla 400	12 req	Avail to order Our Price: $557.37
5	001400398	Pin 19x66x11	12 req	Avail to order Our Price: $204.26
6	008572101	O-Ring I 20 Uni 3654	24 req	Avail to order Our Price: $2.00
8	001413206	Bushing	12 req	Avail to order Our Price: $123.81
9	001405755	Connecting Rod - CapFastening	24 req	Avail to order Our Price: $196.20
9	001408017	Piston D.82 Fino Alla 400	24 req	Avail to order Our Price: $557.37
10	001405755	Connecting Rod - CapFastening	24 req	Avail to order Our Price: $196.20
10	001405756	Connecting Rod Nut	24 req	Avail to order Our Price: $75.66
11	008820201	Split Pin 1.8x15 Uni 1336a	24 req	Current Stock: 19 Our Price: $7.60
12	001419898	Bushing	24 req	Avail to order Our Price: $76.04
14	001412758	Connecting Rod/Cap	1 req	Avail to order Our Price: $720.11
15	07M109381	Snap Ring I 35 Uni 3654	1 req	Current Stock: 35 Our Price: $2.00
16	410109264	Bearing	1 req	Current Stock: 10 Our Price: $30.31
17	001407338	Espada Crankshaft	1 req	Avail to order Our Price: $33,464.21
18	008860801	Tab 8x7x20 Unim 92	1 req	Avail to order Our Price: $11.93
19	001401245	SEE PN 07M105531A AND 07M105532	1 req	Avail to order Our Price: $33.70
20	001407354	Front Crankshaft Gear	1 req	Avail to order Our Price: $271.35
21	001401245	SEE PN 07M105531A AND 07M105532	1 req	Avail to order Our Price: $33.70
22	001400248	Bushing	1 req	Avail to order Our Price: $53.90
23	001400244	Bushing	1 req	Avail to order Our Price: $53.90
24	001400236	Bushing	5 req	Current Stock: 1 Our Price: $194.57
25	001400236	Bushing	5 req	Current Stock: 1 Our Price: $194.57
26	001400243	Bushing	1 req	Avail to order Our Price: $51.14
27	001400235	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
