1968-1978 Lamborghini Espada USA Transmission Automatic (13.0.26)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $113.58
004504532	Belt Belt	Current Stock: 1 Our Price: $55.72
001604645	Belt Belt	Current Stock: 3 Our Price: $24.80
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.81

Brakes

PN	Item	Diagram
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $76.00
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03

Drivetrain

PN	Item	Diagram
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $28.39
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $502.34
001306247	Fuel Filter Fuel Filter	Current Stock: 3 Our Price: $115.65
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	Relay Relay	Current Stock: 1 Our Price: $44.63
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.18

Gaskets

PN	Item
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama	Avail to order Our Price: $1,153.39
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama	Avail to order Our Price: $99.27
0011001010	Front Head Gasket Front Head Gasket	Current Stock: 4 Our Price: $52.22

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,295.63

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002409171	DISCONTINUED - NLA Reverse Light Switch	Avail to order Our Price: $236.34
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 13.0.26 - Transmission Automatic

1968-1978 Lamborghini Espada USA Transmission Automatic (13.0.26)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002609944	This item is no longer available	1 req
2	002609945	This item is no longer available	1 req
3	002609946	This item is no longer available	1 req
4	002609948	This item is no longer available	1 req
5	002609949	This item is no longer available	1 req
6	002609950	This item is no longer available	1 req
7	002609951	This item is no longer available	1 req
8	002610119	This item is no longer available	1 req
9	002609951	This item is no longer available	1 req
10	002609953	This item is no longer available	4 req
11	002610155	This item is no longer available	1 req
12	002610157	This item is no longer available	1 req
13	002610181	This item is no longer available	1 req
14	002610182	This item is no longer available	1 req
15	002610214	This item is no longer available	1 req
16	002611385	This item is no longer available	1 req
17	002610270	This item is no longer available	1 req
18	002610635	This item is no longer available	2 req
19	002610624	This item is no longer available	1 req
20	008851201	Dowel 12.65 8g	2 req	Avail to order Our Price: $15.17
21	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $47.00
22	008300820	Stud M8x25 Uni 5911 8g Zd	7 req	Avail to order Our Price: $2.42
23	N90179103	WASHER	9 req	Current Stock: 5 Our Price: $2.00
24	008200804	Nut	9 req	Current Stock: 7 Our Price: $2.00
25	008301011	Stud M10x1.25x30 Uni5910 -8g	3 req	Avail to order Our Price: $20.13
26	008301012	Stud M10x1.25x35 Uni5910 -8g	1 req	Avail to order Our Price: $20.13
27	008301013	Special Stud 7/16X14Unc 2b	3 req	Avail to order Our Price: $20.13
28	008300848	Special Stud 1/4X20Unc 2b	2 req	Avail to order Our Price: $23.92
29	008401007	Washer 21.5x10.4x2 Uni 6592/5s	7 req	Avail to order Our Price: $2.00
30	008201006	M10Self Locking Nut	7 req	Avail to order Our Price: $8.85
31	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
32	008200811	M8 Uni 5589/8g/ZdNut	2 req	Avail to order Our Price: $6.81
33	008100854	SCREW	8 req	Avail to order Our Price: $2.00
34	008850810	Reference Pin 8h7x428g	1 req	Avail to order Our Price: $8.85
35	410141179	RETAINING PART	4 req	Avail to order Our Price: $68.16
36	002610204	This item is no longer available	1 req
37	002610206	This item is no longer available	1 req
38	002610208	This item is no longer available	1 req
39	008700513	Screw M5x6 Uni5923-248g/Zd	1 req	Avail to order Our Price: $2.00
40	002610607	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
