TAV: 11.1.23 - Differential

1968-1978 Lamborghini Espada USA Differential (11.1.23)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002304837	Flange	2 req	Avail to order Our Price: $682.84
2	008546801	Bearing	2 req	Avail to order Our Price: $254.20
3	002304785	Planetary Shim Adjustment	2 req	Avail to order Our Price: $105.26
4	002304808	Differential Crown Wheel	2 req	Avail to order Our Price: $288.49
5	002308925	Differential Pinion 11/49 Rati	1 req	Avail to order Our Price: $3,477.96
5	002310073	Differential Pinion 12/43 Rati	1 req	Avail to order Our Price: $881.13
6	002310074	Differential Crown Gear 12/43	1 req	Avail to order Our Price: $881.13
6	002308826	This item is no longer available	1 req
7	002304826	Differential Inner Box	1 req	Avail to order Our Price: $1,092.84
7	002310072	Differential Inner Box	1 req	Avail to order Our Price: $1,148.01
8	008411007	Differential Crown Washer	12 req	Avail to order Our Price: $2.91
8	WHT000768	SPRING WASHER	12 req	Current Stock: 17 Our Price: $2.09
9	008101017	Special Screw 10x1x22	12 req	Avail to order Our Price: $17.89
10	008253506	M35x1.5x52 Ring Nut	2 req	Avail to order Our Price: $33.40
11	008413502	Washer Skf Mb7	2 req	Avail to order Our Price: $6.64
12	008503502	Bearing	2 req	Avail to order Our Price: $51.73
13	008614501	LH Ring 45x60x7 mm	1 req	Avail to order Our Price: $68.66
14	008606901	Ring 70 mm Or	2 req	Current Stock: 16 Our Price: $2.00
15	002304836	Flange	2 req	Avail to order Our Price: $168.48
16	002306465	CV Drive Shaft Flange	2 req	Avail to order Our Price: $402.55
17	008931601	Plug D.Cher 1006	2 req	Avail to order Our Price: $2.91
18	008614502	RH Ring 45x60x7 mm	1 req	Avail to order Our Price: $68.66
19	008700610	Screw 6x22 Uni 5933/8g/Zd	16 req	Current Stock: 36 Our Price: $2.00
20	008410604	Washer 6x11 Rds6	16 req	Avail to order Our Price: $2.91
21	002313876	SATELLITE RADIUS RING	2 req	Avail to order Our Price: $56.06
22	002302132	SATELLITE BUSHING	2 req	Avail to order Our Price: $63.23
23	002302026	Differential Satellite Gear	2 req	Avail to order Our Price: $2,214.60
24	002302130	Satellite Gear Pin	1 req	Avail to order Our Price: $600.84
25	WHT003590	Elastic Pin 4x40	1 req	Avail to order Our Price: $13.70
26	002304835	Differential Adjustment Shim 6	1 req	Avail to order Our Price: $35.08
27	008544101	Bearing	1 req	Avail to order Our Price: $292.81
28	002304842	Spacer	1 req	Avail to order Our Price: $738.70
29	002304870	Differential Adjustment Shim 3	1 req	Avail to order Our Price: $35.08
30	008543401	Bearing	1 req	Avail to order Our Price: $221.47
31	01S409739A	BEARING SUPPORTING	1 req	Avail to order Our Price: $209.92
32	01S409561	Bearing	1 req	Avail to order Our Price: $60.67
33	002304830	Spacer	1 req	Avail to order Our Price: $16.33
34	008616001	RH RING	1 req	Avail to order Our Price: $128.72
35	002305075	DIFFERENTIAL DUST BOOT RING	1 req	Avail to order Our Price: $17.06
36	002307159	Differential Inlet Flange	1 req	Avail to order Our Price: $672.40
37	002302136	Differential Pinion Shim	1 req	Avail to order Our Price: $36.39
38	008613301	Felt Ring 33x48x10 mm	1 req	Avail to order Our Price: $17.15
39	002302137	Joint Centring Snap Ring	1 req	Avail to order Our Price: $253.46
40	008252502	M25x1.5 Special RingNut	1 req	Avail to order Our Price: $185.62
41	002310071	This item is no longer available	1 req
42	008402502	Washer 25x39x4 Uni 1750 5s	1 req	Avail to order Our Price: $2.46
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
