1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $506.32
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $87.35

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $27.99

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $777.08
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $2,091.00
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $548.16
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $67.45
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $2,091.00
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 3 Our Price: $53.39

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $557.60
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $102.16
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 2 Our Price: $24.39

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA NLA GROMMET AND OIL SEALS SET JALPA - MIURA NO LONGER AVAILABLE TO ORDER FROM FACTORY.	Avail to order Our Price: $387.78
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,021.35
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $2,058.95

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $167.43
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $261.96

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 89 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 8 - Shifter

1966-1972 Lamborghini Miura USA Shifter (8)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008801804	BUSHING 18X25X20 MM	1 req	Avail to order Our Price: $48.89
2	002409171	DISCONTINUED - NLA	1 req	*See Description
3	002402829	INTERMEDIATE LEVER ASSEMBLY	1 req	Avail to order Our Price: $632.90
4	008921406	NLA (NO LONGER AVAILABLE)	1 req	*See Description
5	008101414	SPECIAL SCREW	1 req	Avail to order Our Price: $38.07
6	N0111849	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 5 Our Price: $2.39
7	002404197	GEARBOX SILENTBLOC BUSHING	1 req	Avail to order Our Price: $2,365.27
8	008201409	14X1X8 SINGLE THREADNUT	1 req	Avail to order Our Price: $23.59
9	002403381	NLA (NO LONGER AVAILABLE)	1 req	*See Description
10	004301424	JOINT	1 req	Avail to order Our Price: $5,832.22
11	002402875	NLA (NO LONGER AVAILABLE)	1 req	*See Description
12	002402876	LEVER SPRING BRACKETPIPE	1 req	Avail to order Our Price: $130.47
13	002402934	GEAR LEVER SCREW	1 req	Avail to order Our Price: $31.32
14	002403208	GEAR LEVER LH RETURNSPRING	1 req	Avail to order Our Price: $237.89
15	002403702	GEAR LEVER GUIDE BUSHING	1 req	Avail to order Our Price: $70.70
16	N01118312	HEX.HEAD CLAMPING NUT	1 req	Avail to order Our Price: $2.12
17	008400608	FLAT WASHER D.6.4X3.5X11	1 req	Avail to order Our Price: $19.93
18	N90638803	HEXAGON HEAD BOLT	1 req	Avail to order Our Price: $1.10
19	002402819	GEAR LEVER GUIDING SLEEVE	1 req	Avail to order Our Price: $334.87
20	002403207	GEAR LEVER RH RETURNSPRING	1 req	Avail to order Our Price: $210.31
21	008200806	NUT	1 req	Current Stock: 25 Our Price: $0.40
22	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
23	002402876	LEVER SPRING BRACKETPIPE	1 req	Avail to order Our Price: $130.47
24	002402820	PIN & CONTROL FORK	1 req	Avail to order Our Price: $227.15
25	008801804	BUSHING 18X25X20 MM	1 req	Avail to order Our Price: $48.89
26	N01118312	HEX.HEAD CLAMPING NUT	1 req	Avail to order Our Price: $2.12
27	002403702	GEAR LEVER GUIDE BUSHING	1 req	Avail to order Our Price: $70.70
28	002402818	GEAR LEVER	1 req	Avail to order Our Price: $4,643.16
29	WHT001197A	WASHER	1 req	Current Stock: 22 Our Price: $0.40
30	002404209	LEVER STOPP	1 req	Avail to order Our Price: $235.85
31	002403369	REVERSE LEVER LOCK SPRING	1 req	Avail to order Our Price: $35.71
32	002404994	GEAR LEVER BOOT	1 req	Avail to order Our Price: $115.44
33	008700616	CHROME-PLATED SCREW 6X1X22	1 req	Avail to order Our Price: $48.89
34	002404201	GEAR SELECTOR LEVER	1 req	Avail to order Our Price: $432.73
35	002401723	GEAR LEVER KNOB RINGNUT	1 req	Avail to order Our Price: $408.63
36	002405011	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
