1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $700.10
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $1,887.62
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $60.68
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $1,887.62
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.60
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.81
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,850.49

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $236.34

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 18 - Frame Elements

1966-1972 Lamborghini Miura USA Frame Elements (18)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008521408	This item is no longer available	1 req
2	008401413	FLAT WASHER 14.3 UNI1750/Z	1 req	Current Stock: 11 Our Price: $1.10
3	008201406	NUT	1 req	Current Stock: 8 Our Price: $1.00
4	008101413	SCREW M14X1.5X135 CH22	1 req	Avail to order Our Price: $27.71
5	008004265	This item is no longer available	1 req
6	001806905	MIURA REAR ENGINE MOUNT	1 req	Avail to order Our Price: $3,048.96
7	004103741	UPPER TIEROD	1 req	Avail to order Our Price: $189.33
8	004107844	This item is no longer available	1 req
9	008201008	NUT	1 req	Current Stock: 2 Our Price: $0.90
10	004103740	LOWER TIEROD	1 req	Avail to order Our Price: $120.98
11	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
12	N90630504	HEX. BOLT WITH	1 req	Current Stock: 10 Our Price: $3.40
13	008300828	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
14	008200806	M8 UNI 5588/8G/Z NUT	1 req	Current Stock: 25 Our Price: $0.40
15	001803811	CENTRAL ENGINE MOUNT	1 req	Avail to order Our Price: $91.61
16	008101411	SCREW 14X1.5X85 UNI 5738/8	1 req	Current Stock: 1 Our Price: $7.58
17	008401415	FLAT WASHER D.14X58X3 8G	1 req	Avail to order Our Price: $19.25
18	001803744	BRACKETING STRUT	1 req	Avail to order Our Price: $511.26
19	008921408	RUBBER MOUNTS	1 req	Avail to order Our Price: $358.19
20	008401413	FLAT WASHER 14.3 UNI1750/Z	1 req	Current Stock: 11 Our Price: $1.10
21	008201406	NUT	1 req	Current Stock: 8 Our Price: $1.00
22	008100616	SCREW M6X16 UNI 5739/5S/Z	1 req	Avail to order Our Price: $0.20
23	008410603	WASHER D.6.4 UNI 1751/ZD	1 req	Avail to order Our Price: $0.10
24	006104257	This item is no longer available	1 req
25	008930801	PICKLING HOLE PLUG	1 req	Current Stock: 6 Our Price: $2.92
26	004106904	SHOCK ABSORBER CROSSMEMBER	1 req	Avail to order Our Price: $389.41
27	008101029	SCREW M10X70 UNI 5737/10K	1 req	Avail to order Our Price: $23.82
28	008101027	SCREW M10X65 UNI 5737/10K	1 req	Avail to order Our Price: $26.64
29	008411006	NLA (NO LONGER ABVAILABLE)	1 req	*See Description
30	008700809	SCREW M8X25 UNI 5933/8G/Z	1 req	Avail to order Our Price: $0.90
31	001803026	ENGINE MOUNT BLOCK	1 req	Avail to order Our Price: $95.58
32	008401009	WASHER 10.5X50X1	1 req	Avail to order Our Price: $22.59
33	008100830	SCREW M8X20 UNI 5739/8G/Z	1 req	Current Stock: 19 Our Price: $0.50
34	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
35	008921001	ENGINE MOUNT	1 req	Avail to order Our Price: $643.58
36	004103741	UPPER TIEROD	1 req	Avail to order Our Price: $189.33
37	004103740	LOWER TIEROD	1 req	Avail to order Our Price: $120.98
38	008201010	M10SELF LOCKING NUT	1 req	Avail to order Our Price: $1.50
39	008401101	WASHER 11.5X20X3	1 req	Avail to order Our Price: $0.20
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
