1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $700.10
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $1,887.62
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $60.68
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $1,887.62
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.60
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.81
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,850.49

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $236.34

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 2 - Cylinder Heads

1966-1972 Lamborghini Miura USA Cylinder Heads (2)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008300612	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
2	001104250	HEAD SPLIT PIN STUD SHIM	1 req	Avail to order Our Price: $20.71
3	001100904	This item is no longer available	1 req
4	001102070	This item is no longer available	1 req
5	008850501	REFERENCE PIN 5H7X7.5 C40	1 req	Avail to order Our Price: $32.86
6	001100269	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
7	N01100845	HEX.NUT	1 req	Current Stock: 17 Our Price: $2.14
8	WHT001514	SPRING WASHER	1 req	Current Stock: 9 Our Price: $26.80
9	008300819	SPECIAL STUD M 8	1 req	Avail to order Our Price: $58.44
10	008300821	SPECIAL STUD M 8	1 req	Avail to order Our Price: $132.73
11	008850608	REFERENCE PIN 6X10 UNI 1707	1 req	Avail to order Our Price: $1.10
12	008300825	STUD M8X22 UNI 5911 10K Z	1 req	Avail to order Our Price: $15.24
13	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $1.80
14	008200804	NUT	1 req	Current Stock: 7 Our Price: $1.20
15	008300608	NLA (NO LONGER AVAILABLE)	1 req	*See Description
16	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
17	008200806	M8 UNI 5588/8G/Z NUT	1 req	Current Stock: 25 Our Price: $0.40
18	001102886	RH CYLINDER HEAD	1 req	Avail to order Our Price: $29,793.05
19	001100286	This item is no longer available	1 req
20	WHT001514	SPRING WASHER	1 req	Current Stock: 9 Our Price: $26.80
21	008300820	STUD M8X25 UNI 5911 8G ZD	1 req	Avail to order Our Price: $2.42
22	001100267	CYLINDER HEAD COVER	1 req	Avail to order Our Price: $521.73
23	001101034	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
24	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $1.80
25	008300818	STUD M8X30 UNI 5911 8G ZD	1 req	Avail to order Our Price: $5.04
26	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $1.80
27	001100265	This item is no longer available	1 req
28	008200804	NUT	1 req	Current Stock: 7 Our Price: $1.20
29	001100266	This item is no longer available	1 req
30	008300825	STUD M8X22 UNI 5911 10K Z	1 req	Avail to order Our Price: $15.24
31	001104872	LH CYLINDER HEAD	1 req	Avail to order Our Price: $29,793.05
32	008300812	STUD M8X75 UNI 5914 8G F	1 req	Avail to order Our Price: $35.77
33	008300820	STUD M8X25 UNI 5911 8G ZD	1 req	Avail to order Our Price: $2.42
34	008410808	BRAKE LOCK PLATE	1 req	Avail to order Our Price: $19.97
35	008200807	M8 OT.58 UNI 2012SELF-LOCKI	1 req	Avail to order Our Price: $26.74
36	N91116801	WASHER	1 req	Current Stock: 1 Our Price: $8.93
37	001100903	This item is no longer available	1 req
38	008101028	SCREW 10MAX17 5S	1 req	Avail to order Our Price: $6.90
39	001600906	DISTRIBUTOR BRACKET SEAL	1 req	Current Stock: 1 Our Price: $11.54
40	008200605	SIMMON NUT FOR URAMA	1 req	Current Stock: 50 Our Price: $3.10
41	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
42	001103002	FRONT HEAD COVER	1 req	Avail to order Our Price: $408.51
43	008200605	SIMMON NUT FOR URAMA	1 req	Current Stock: 50 Our Price: $3.10
44	008300613	STUD M6X14 UNI 5911 8G/Z	1 req	Avail to order Our Price: $5.74
45	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
46	008835004	CLAMP	1 req	Avail to order Our Price: $10.86
47	WHT003165	TAP END STUD	1 req	Current Stock: 3 Our Price: $1.60
48	001100271	This item is no longer available	1 req
49	001101031	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
50	001104202	This item is no longer available	1 req
51	001104929	HEAD OIL DRAIN UNION	1 req	Avail to order Our Price: $135.94
52	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
53	001102071	This item is no longer available	1 req
54	001104515	BREATH PIPE	1 req	Avail to order Our Price: $52.12
55	008402005	FIBER WASHER 20.5X27X05	1 req	Current Stock: 1 Our Price: $6.61
56	008200605	SIMMON NUT FOR URAMA	1 req	Current Stock: 50 Our Price: $3.10
57	001101634	OIL BREATHER GASKET	1 req	Current Stock: 1 Our Price: $14.49
58	001101634	OIL BREATHER GASKET	1 req	Current Stock: 1 Our Price: $14.49
59	008402403	FIBER WASHER 24.5X32X05	1 req	Current Stock: 4 Our Price: $3.50
60	008851002	REFERENCE PIN 10H7X8.25 C40	1 req	Avail to order Our Price: $6.90
61	008300819	SPECIAL STUD M 8	1 req	Avail to order Our Price: $58.44
62	008830206	CLAMP	1 req	Current Stock: 1 Our Price: $23.24
63	001101035	This item is no longer available	1 req
64	001104930	BREATHER OIL DRAIN PIPE	1 req	Avail to order Our Price: $39.09
65	008300612	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
66	001102055	HEAD COVER HOLDER PLATE	1 req	Avail to order Our Price: $298.77
67	001102235	OIL FILLER PIPE	1 req	Avail to order Our Price: $1,627.53
68	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
69	001101401	OIL FILLER PLUG GASKET	1 req	Avail to order Our Price: $3.97
70	008200605	SIMMON NUT FOR URAMA	1 req	Current Stock: 50 Our Price: $3.10
71	001102613	NLA (NO LONGER AVAILABLE)	1 req	*See Description
72	008300612	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
