1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $521.78
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $90.02

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $28.85

Drivetrain

PN	Item
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $2,154.85
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $800.81
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $2,154.85
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $69.51
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $564.90
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 3 Our Price: $55.02

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $574.63
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $105.28
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 2 Our Price: $25.14

Gaskets

PN	Item
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,052.53
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA NLA GROMMET AND OIL SEALS SET JALPA - MIURA NO LONGER AVAILABLE TO ORDER FROM FACTORY.	Avail to order Our Price: $399.62
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $2,121.82

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $269.96
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $172.55

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 89 Our Price: $15.72

Open All

Select Group and TAV

< Previous Next >

TAV: 20 - Front Hub and Wheel

1966-1972 Lamborghini Miura USA Front Hub and Wheel (20)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	0084118001	This item is no longer available	1 req
2	008201809	M18X1.5 UNI 5594/8G NUT	1 req	Avail to order Our Price: $20.78
3	008614001	OIL SEAL	1 req	Current Stock: 1 Our Price: $55.92
4	008700505	SCREW ESLOK 5X10 8G 2384	1 req	Avail to order Our Price: $6.62
5	005108078	FRONT WHEEL RIM MUIRA	1 req	Avail to order Our Price: $2,608.89
6	005100965	LH FRONT HUB RING	1 req	Avail to order Our Price: $207.25
7	005100964	RH FRONT HUB RING	1 req	Avail to order Our Price: $207.25
8	008503201	BEARING	1 req	Avail to order Our Price: $2,014.45
9	005207918	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	008820302	SPLIT PIN 3.7X30 UNI 1336A	1 req	Avail to order Our Price: $2.85
11	005103779	NLA (NO LONGER AVAILABLE)	1 req	*See Description
12	005100702	NLA (NO LONGER AVAILABLE)	1 req	*See Description
13	005103258	NLA (NO LONGER AVAILABLE)	1 req	*See Description
14	008201810	18X1.5 LEFT NUT	1 req	Avail to order Our Price: $24.31
15	008411802	LH WHEEL RETAINING WASHER	1 req	Current Stock: 4 Our Price: $39.04
16	008411801	SNAP RING 18.5X30X2.5	1 req	Avail to order Our Price: $6.62
17	008401807	WASHER 18.5X30X2.5	1 req	Avail to order Our Price: $22.88
18	008502010	BEARING	1 req	Avail to order Our Price: $283.21
19	005100966	SPACER	1 req	Avail to order Our Price: $105.70
20	005103033	WHEEL WING NUT	1 req	Avail to order Our Price: $965.96
21	005201355	This item is no longer available	1 req
22	005207808	TYRE TUBE	1 req	Avail to order Our Price: $220.13
24	005207807	WHEEL TYRE	1 req	Avail to order Our Price: $6,918.49
25	005205208	WHEEL TYRE	1 req	Avail to order Our Price: $4,268.29
26	005103781	ODOMETER RETURN BUSHING	1 req	Current Stock: 3 Our Price: $8.55
29	005103259	ODOMETER CENTRING BUSHING	1 req	Avail to order Our Price: $104.81
30	008101022	SCREW M10X1.5X35 UNI5737/	1 req	Avail to order Our Price: $4.69
31	008411003	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
32	005103782	ODOMETER RETURN SEAL	1 req	Avail to order Our Price: $13.49
33	008410601	WASHER 12X6.1X0.6 C72	1 req	Avail to order Our Price: $0.00
34	008700617	SCREW M6X18 UNI 5931/8G/Z	1 req	Current Stock: 1 Our Price: $0.30
35	005106107	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
36	008101019	SCREW M10X1.5X45 UNI5737/	1 req	Avail to order Our Price: $5.03
37	008411003	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
38	005104351	NLA (NO LONGER AVAILABLE)	1 req	*See Description
39	008830112	PIPE CLAMP	1 req	Avail to order Our Price: $148.23
40	008700506	SCREW KNIP 4.8X16DIN7971 BLACK	1 req	Current Stock: 4 Our Price: $0.20
41	005100548	RH WHEEL STUB AXLE	1 req	Avail to order Our Price: $721.53
42	005103780	LH WHEEL STUB AXLE	1 req	Avail to order Our Price: $747.86
43	005102960	LH WHEEL STEERING ARM	1 req	Avail to order Our Price: $4,747.17
44	005102961	RH WHEEL STEERING ARM	1 req	Avail to order Our Price: $10,237.38
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
