1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $700.10
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $1,887.62
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $60.68
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $1,887.62
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.60
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.81
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,850.49

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $236.34

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 28 - Pedels

1966-1972 Lamborghini Miura USA Pedels (28)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004205015	This item is no longer available	1 req
2	004203128	ACCELERATOR PEDAL COVER COUNTACH	1 req	Avail to order Our Price: $93.35
3	008700405	LOCK SCREW 4.8X9.5DIN7981/N	1 req	Avail to order Our Price: $0.10
4	004204190	CARBURETTOR BOWDEN WIRE	1 req	Current Stock: 2 Our Price: $286.85
5	008100503	SCREW M5X8 UNI 5739/8G	1 req	Avail to order Our Price: $0.10
6	001300188	ACCELERATOR WIRE LOCK FORK	1 req	Current Stock: 1 Our Price: $236.29
7	006102854	COCK SHEATH STOP	1 req	Avail to order Our Price: $11.25
8	008820201	SPLIT PIN	1 req	Current Stock: 19 Our Price: $7.58
9	001300372	ACCELERATOR WIRE PIN	1 req	Avail to order Our Price: $24.31
10	004201212	BRAKE PEDAL COVER	1 req	Avail to order Our Price: $61.07
11	004203920	This item is no longer available	1 req
12	004203922	NLA (NO LONGER AVAILABLE)	1 req	*See Description
13	004202911	BRAKE PEDAL	1 req	Avail to order Our Price: $570.78
14	008401806	PEDAL WASHER VULKOLLAN 4556084	1 req	Avail to order Our Price: $41.59
15	004202676	This item is no longer available	1 req
16	008100622	SCREW M6X12 UNI 5739/8G	1 req	Avail to order Our Price: $6.81
17	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
18	003104236	HOSE MOUNTING PLATE	1 req	Avail to order Our Price: $153.54
19	008200701	This item is no longer available	1 req
20	004202677	NLA (NO LONGER AVAILABLE)	1 req	*See Description
21	004203923	BRAKE CYLINDER ROD	1 req	Avail to order Our Price: $170.91
22	008581601	O-RING E 18 UNI 7435-75	1 req	Avail to order Our Price: $2.92
23	004205452	CLUTCH PEDAL BUSHING	1 req	Avail to order Our Price: $9.82
24	008200608	NUT	1 req	Avail to order Our Price: $6.90
25	WHT002961	WASHER	1 req	Current Stock: 38 Our Price: $0.40
26	004206126	NLA (NO LONGER AVAILABLE)	1 req	*See Description
27	004203921	This item is no longer available	1 req
28	008401806	PEDAL WASHER VULKOLLAN 4556084	1 req	Avail to order Our Price: $41.59
29	008801802	BUSHING 18X20X15 MM	1 req	Avail to order Our Price: $317.59
30	008820201	SPLIT PIN	1 req	Current Stock: 19 Our Price: $7.58
31	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $1.80
32	004204185	CLUTCH CYLINDER CONTROL PIN	1 req	Avail to order Our Price: $91.61
33	004203866	CLUTCH CYLINDER	1 req	Avail to order Our Price: $423.38
34	008200811	M8 UNI 5589/8G/ZDNUT	1 req	Avail to order Our Price: $6.81
35	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
36	008100827	SCREW M8X25 UNI 5739/8G/ZG	1 req	Current Stock: 14 Our Price: $0.40
37	008200811	M8 UNI 5589/8G/ZDNUT	1 req	Avail to order Our Price: $6.81
38	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
39	008100827	SCREW M8X25 UNI 5739/8G/ZG	1 req	Current Stock: 14 Our Price: $0.40
40	004204200	BRAKE CYLINDER	1 req	Avail to order Our Price: $2,051.15
41	008401414	COPPER WASHER 14X24X0,04513888	1 req	Current Stock: 27 Our Price: $2.62
42	004204182	BRAKE CYLINDER OIL UNION	1 req	Avail to order Our Price: $139.30
43	004204767	BRAKE CYLINDER PLUG	1 req	Avail to order Our Price: $17.11
44	004204768	BRAKE CYLINDER	1 req	Avail to order Our Price: $78.28
45	004104167	This item is no longer available	1 req
46	004204169	BRAKE CYLINDER ROD	1 req	Avail to order Our Price: $241.57
47	008200701	This item is no longer available	1 req
48	004201161	BRAKE CYLINDER FORK	1 req	Avail to order Our Price: $42.98
49	004203415	PIN	1 req	Avail to order Our Price: $15.07
50	004202683	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
51	008801802	BUSHING 18X20X15 MM	1 req	Avail to order Our Price: $317.59
52	004202675	PEDAL MOUNT PIN	1 req	Avail to order Our Price: $114.06
53	008401806	PEDAL WASHER VULKOLLAN 4556084	1 req	Avail to order Our Price: $41.59
54	008401809	ACCELERATOR PEDAL SHIM ADJUSTM	1 req	Avail to order Our Price: $27.24
55	008581601	O-RING E 18 UNI 7435-75	1 req	Avail to order Our Price: $2.92
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
