1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $700.10
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $1,887.62
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $60.68
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $1,887.62
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.60
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.81
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,850.49

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $236.34

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 13 - Water System

1966-1972 Lamborghini Miura USA Water System (13)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001703773	COOLANT AUXILIARY RESERVOIR	1 req	Avail to order Our Price: $503.18
2	001703771	PIPE	1 req	Avail to order Our Price: $453.24
3	001704296	COOLANT CAP	1 req	Avail to order Our Price: $155.30
4	001705421	This item is no longer available	1 req
5	001703774	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
6	008830116	CLAMP	1 req	Avail to order Our Price: $28.49
7	001703768	COOLANT PUMP INTAKE SLEEVE	1 req	Avail to order Our Price: $79.78
8	001705166	NLA	1 req	*See Description
9	008610501	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	008400503	WASHER D.5X19X1.5	1 req	Avail to order Our Price: $1.00
11	008200804	NUT	1 req	Current Stock: 7 Our Price: $1.20
12	WHT001942	WASHER	1 req	Current Stock: 13 Our Price: $3.50
13	WHT001189	RUBBER WASHER MOUNT	1 req	Current Stock: 6 Our Price: $6.80
14	001701592	RADIATOR SHIM	1 req	Current Stock: 8 Our Price: $20.75
15	001701495	SUPPLEMENTARY RESERVOIR BRACKET	1 req	Current Stock: 9 Our Price: $58.45
16	008830112	PIPE CLAMP	1 req	Avail to order Our Price: $126.12
17	008700506	SCREW KNIP 4.8X16DIN7971 BLACK	1 req	Current Stock: 4 Our Price: $0.10
18	008610802	GROMMET 8X18X2 MM	1 req	Avail to order Our Price: $9.40
19	008200403	NUT	1 req	Avail to order Our Price: $2.92
20	008200402	M4 BRASS SPECIAL NUT	1 req	Current Stock: 2 Our Price: $2.92
21	008410403	WASHER D.4.3 UNI 1751/Z	1 req	Avail to order Our Price: $7.58
22	001703768	COOLANT PUMP INTAKE SLEEVE	1 req	Avail to order Our Price: $79.78
23	001705422	This item is no longer available	1 req
24	410721493	BRAKE PIPE PROTECTION RUBBER W	1 req	Avail to order Our Price: $58.16
25	006105650	This item is no longer available	1 req
26	001705649	RADIATOR FAN MOTOR MOUNT	1 req	Avail to order Our Price: $1,203.90
27	001703766	FAN REAR WASHER	1 req	Current Stock: 1 Our Price: $63.40
28	001701405	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
29	001705504	ENGINE THERMAL CONTACT SEAL	1 req	Avail to order Our Price: $30.44
30	001701645	SEE PN: 1724565 AND 1724564	1 req	Avail to order Our Price: $49.79
31	001701646	COOLANT WARNING LIGHT THERMAL	1 req	Avail to order Our Price: $104.76
32	008401610	ANNEALED COPPER WASHER 16X22X0	1 req	Current Stock: 25 Our Price: $11.25
33	008830117	RADIATOR PUMP PIPE CLAMP	1 req	Avail to order Our Price: $14.78
34	001704298	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
35	008410803	WASHER 8.4X17X0.8 DIN 137/B	1 req	Avail to order Our Price: $0.10
36	008100622	SCREW M6X12 UNI 5739/8G	1 req	Avail to order Our Price: $6.81
37	001706534	VALVE	1 req	Avail to order Our Price: $496.43
38	008835004	CLAMP	1 req	Avail to order Our Price: $10.86
39	001703762	RADIATOR OUTLET SLEEVE	1 req	Avail to order Our Price: $111.48
40	001701906	TAP WASHER	1 req	Avail to order Our Price: $0.20
41	001701905	RADIATOR TAP	1 req	Avail to order Our Price: $115.94
42	008100831	SCREW M8X30 UNI 5737/8G/Z	1 req	Avail to order Our Price: $0.30
43	WHT001942	WASHER	1 req	Current Stock: 13 Our Price: $3.50
44	001701495	SUPPLEMENTARY RESERVOIR BRACKET	1 req	Current Stock: 9 Our Price: $58.45
45	001701592	RADIATOR SHIM	1 req	Current Stock: 8 Our Price: $20.75
46	001701495	SUPPLEMENTARY RESERVOIR BRACKET	1 req	Current Stock: 9 Our Price: $58.45
47	001703597	MIURA COOLANT RADIATOR	1 req	Avail to order Our Price: $14,320.15
48	001703768	COOLANT PUMP INTAKE SLEEVE	1 req	Avail to order Our Price: $79.78
49	001701803	FAN GASKET	1 req	Avail to order Our Price: $122.14
50	008200806	M8 UNI 5588/8G/Z NUT	1 req	Current Stock: 25 Our Price: $0.40
51	001703770	This item is no longer available	1 req
52	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
53	008100826	SCREW M8X16 UNI 5739/8G/Z	1 req	Avail to order Our Price: $0.50
54	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
55	008100826	SCREW M8X16 UNI 5739/8G/Z	1 req	Avail to order Our Price: $0.50
56	008830206	CLAMP	1 req	Current Stock: 1 Our Price: $23.24
57	001704297	MIURA CLAMP PIPE D.26	1 req	Avail to order Our Price: $13.18
58	001703772	RESERVOIR PIPE SLEEVE	1 req	Avail to order Our Price: $39.09
59	N01020717	HEXAGON HEAD BOLT	1 req	Current Stock: 4 Our Price: $0.80
60	008410502	WASHER D.5.3 UNI 1751/ZD	1 req	Current Stock: 33 Our Price: $0.10
61	N0211963	HEX.HEAD CLAMPING	1 req	Avail to order Our Price: $0.80
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
