1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $700.10
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $1,887.62
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $60.68
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $1,887.62
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.60
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.81
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,850.49

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $236.34

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 33 - Air Conditioner

1966-1972 Lamborghini Miura USA Air Conditioner (33)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008700507	SCREW M5X16 UNI 61075S/Z	1 req	Avail to order Our Price: $2.92
2	004506790	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
3	004506720	SPARK DISTRIBUTOR BULKHEAD	1 req	Avail to order Our Price: $453.29
4	001806625	This item is no longer available	1 req
5	001806609	MIURA AIR CONDITIONER OIL DIPS	1 req	Avail to order Our Price: $472.68
6	004506510	CONDENSER/COMPRESSORPIPE	1 req	Avail to order Our Price: $117.17
7	004506642	LH EVAPORATOR BRACKET	1 req	Avail to order Our Price: $54.65
8	008410603	WASHER D.6.4 UNI 1751/ZD	1 req	Avail to order Our Price: $0.10
9	008100620	SCREW M6X12 UNI 5739/5S/Z	1 req	Avail to order Our Price: $6.81
10	004506650	This item is no longer available	1 req
11	004506698	EVAPORATOR LOWER BRACKET	1 req	Avail to order Our Price: $54.65
12	004506653	This item is no longer available	1 req
13	008200804	NUT	1 req	Current Stock: 7 Our Price: $1.20
14	004507583	EVAPORATOR BRACKET	1 req	Avail to order Our Price: $46.48
15	001806625	This item is no longer available	1 req
16	001806609	MIURA AIR CONDITIONER OIL DIPS	1 req	Avail to order Our Price: $472.68
17	004506510	CONDENSER/COMPRESSORPIPE	1 req	Avail to order Our Price: $117.17
18	004506520	This item is no longer available	1 req
19	008100506	SCREW M5X14 UNI 5739	1 req	Avail to order Our Price: $11.96
20	004508088	CONDITIONER MOTOR PLATE	1 req	Avail to order Our Price: $30.53
21	N0211963	HEX.HEAD CLAMPING	1 req	Avail to order Our Price: $0.80
22	004506519	EVAPORATOR DRAIN UNION	1 req	Avail to order Our Price: $36.76
23	004506521	This item is no longer available	1 req
24	004506516	This item is no longer available	1 req
25	004506515	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
26	004506172	ELECTROMAGNETIC CLUTCH	1 req	Avail to order Our Price: $675.43
27	004506578	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
28	004506513	This item is no longer available	1 req
29	N0211963	HEX.HEAD CLAMPING	1 req	Avail to order Our Price: $0.80
30	004506712	OIL DIPSTICK PIPE CLAMP	1 req	Avail to order Our Price: $36.76
31	001806608	AIR CONDITIONER OIL DIPSTICK P	1 req	Avail to order Our Price: $68.26
32	001601564	6 HOLE SPARK PLUG GROMMET	1 req	Avail to order Our Price: $52.80
33	004506631	CONDITIONER FAIRLEADHOOK	1 req	Avail to order Our Price: $9.24
34	001604243	NLA DISCONTINUED	1 req	*See Description
35	004505585	ISOBAR VALVE/COMPRESSOR PIPE	1 req	Avail to order Our Price: $69.43
36	004505250	ISOBAR VALVE	1 req	Avail to order Our Price: $337.71
37	004506633	CONDENSER/COMPRESSORPIPE	1 req	Avail to order Our Price: $390.61
38	004506538	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
39	004506636	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
40	004506634	MUDGUARD CONDENSER BRACKET	1 req	Avail to order Our Price: $27.81
41	008410502	WASHER D.5.3 UNI 1751/ZD	1 req	Current Stock: 33 Our Price: $0.10
42	N10689901	HEX.NUT	1 req	Current Stock: 5 Our Price: $0.10
43	004508071	NLA (NO LONGER AVAILABLE)	1 req	*See Description
44	004505322	SEE PN: 4535411 AND 37126-27	1 req	Avail to order Our Price: $120.28
45	004504908	CONDIT FAN	1 req	Avail to order Our Price: $856.08
46	004504909	FAN NUT	1 req	Avail to order Our Price: $13.13
47	008700810	SCREW M8X30 UNI 5931/8G/ZD	1 req	Avail to order Our Price: $0.70
48	001600371	DISTRIBUTOR MOUNT SHIM	1 req	Avail to order Our Price: $93.06
49	001606090	This item is no longer available	1 req
50	001403578	CRANKSHAFT STARTER GEAR	1 req	Avail to order Our Price: $6,984.94
51	004506511	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
52	004505600	CLEANER BRACKET	1 req	Avail to order Our Price: $12.12
53	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $0.40
54	008410603	WASHER D.6.4 UNI 1751/ZD	1 req	Avail to order Our Price: $0.10
55	004506638	This item is no longer available	1 req
56	008410502	WASHER D.5.3 UNI 1751/ZD	1 req	Current Stock: 33 Our Price: $0.10
57	004506635	CONDENSER BODY BRACKET	1 req	Avail to order Our Price: $24.70
58	008830102	MIURA CONDITIONER PIPE CLAMP	1 req	Avail to order Our Price: $27.71
59	004506647	CASING STIFFENER FORAIR CONDIT	1 req	Avail to order Our Price: $87.71
60	004506639	This item is no longer available	1 req
61	004506637	CONDITIONER PIPE CLAMP	1 req	Avail to order Our Price: $32.77
62	N10689901	HEX.NUT	1 req	Current Stock: 5 Our Price: $0.10
63	004506514	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
64	004506178	COMPRESSOR PULLEY UPPER SHAFT	1 req	Avail to order Our Price: $860.28
65	001607225	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
66	004506693	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
67	004506517	FILTER/EVAPORATOR PIPE	1 req	Avail to order Our Price: $276.55
68	001603573	STARTER MOTOR INTERMEDIATE GEA	1 req	Avail to order Our Price: $1,939.67
69	008100624	SCREW M6X25 UNI 5737/8G	1 req	Avail to order Our Price: $0.20
70	001806175	GEAR COVER	1 req	Avail to order Our Price: $4,704.21
71	008403601	WASHER	1 req	Avail to order Our Price: $23.82
72	008612801	OIL SEAL	1 req	Avail to order Our Price: $16.34
73	008574501	O-RING I 42 UNI 3654	1 req	Current Stock: 7 Our Price: $2.04
74	004506179	SPACER	1 req	Avail to order Our Price: $27.81
75	004506177	COMPRESSOR PULLEY	1 req	Avail to order Our Price: $717.15
76	008401010	WASHER 10.5X28X2.5 5S	1 req	Avail to order Our Price: $11.96
77	008411005	WASHER D.10.5 UNI 1751/F	1 req	Avail to order Our Price: $0.10
78	008500826	This item is no longer available	1 req
79	008401031	This item is no longer available	1 req
80	004506789	COMPRESSOR BELT	1 req	Avail to order Our Price: $45.51
81	008100911	SCREW 3/8X16 UNC FONTANA	1 req	Current Stock: 3 Our Price: $6.90
82	WHT000768	SPRING WASHER	1 req	Current Stock: 17 Our Price: $2.14
83	004506431	COMPRESSOR MOUNT	1 req	Avail to order Our Price: $413.16
84	004506705	COMPRESSOR ADJUSTMENT SHIM PLA	1 req	Avail to order Our Price: $16.34
85	004506512	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
86	008100910	SCREW 3/8X16NC FONTANA	1 req	Avail to order Our Price: $20.13
87	004506705	COMPRESSOR ADJUSTMENT SHIM PLA	1 req	Avail to order Our Price: $16.34
88	004506509	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
89	008401007	WASHER 21.5X10.4X2 UNI 6592/5S	1 req	Avail to order Our Price: $0.10
90	004511439	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
