1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $700.10
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $1,887.62
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $60.68
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $1,887.62
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.60
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.81
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,850.49

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $236.34

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 21 - Rear Suspension

1966-1972 Lamborghini Miura USA Rear Suspension (21)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008200804	NUT	1 req	Current Stock: 7 Our Price: $1.20
2	008201801	18 X 1.5 RIGHT NUT	1 req	Avail to order Our Price: $5.64
3	008201802	18X1.5 LEFT NUT	1 req	Avail to order Our Price: $6.90
4	005206464	CV JOINT DRIVE AXLE FLANGE	1 req	Avail to order Our Price: $2,608.46
5	005201006	REAR HUB THREADED RING	1 req	Avail to order Our Price: $231.88
6	086525596	SEAL RING	1 req	Avail to order Our Price: $57.58
7	005204894	REAR SHOCK ABSORBER SPRING	1 req	Avail to order Our Price: $860.28
8	008201603	NUT	1 req	Avail to order Our Price: $3.97
9	008401611	WASHER 17X29X3 5S UNI 16592	1 req	Avail to order Our Price: $16.43
10	008101609	NLA (NO LONGER AVAILABLE)	1 req	*See Description
11	005205033	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
12	005205680	REAR SHOCK ABSORBER BULKHEAD	1 req	Avail to order Our Price: $116.23
13	005205492	REAR BALL JOINT BUSHING	1 req	Avail to order Our Price: $131.26
14	005206615	NLA (NO LONGER AVAILABLE)	1 req	*See Description
15	005206616	RH REAR ALUMINIUM HUB	1 req	Avail to order Our Price: $1,553.17
16	008570505	This item is no longer available	1 req
17	005206462	SPACER	1 req	Avail to order Our Price: $282.58
18	008523505	BEARING	1 req	Avail to order Our Price: $262.32
19	005207411	REAR LH WHEEL HUB	1 req	Avail to order Our Price: $2,616.53
20	005207412	REAR RH WHEEL HUB	1 req	Avail to order Our Price: $2,616.53
21	005100969	This item is no longer available	1 req
22	008401612	WASHER 16.5X35X4	1 req	Avail to order Our Price: $11.96
23	008401708	WASHER 17.5X26X3 AQ42	1 req	Current Stock: 1 Our Price: $2.92
24	008004284	COVER. 2AANON 25	1 req	Avail to order Our Price: $377.19
25	008201603	NUT	1 req	Avail to order Our Price: $3.97
26	008577601	O-RING I 27 UNI 3654	1 req	Current Stock: 16 Our Price: $3.89
27	008615201	OIL SEAL	1 req	Current Stock: 1 Our Price: $31.12
28	008101615	SCREW 16X1.5X252 CH27 8G	1 req	Avail to order Our Price: $164.22
29	008202401	24X1 8G NUT	1 req	Current Stock: 1 Our Price: $3.40
30	008412401	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
31	008180601	This item is no longer available	1 req
32	008613802	HUB HOLDER SEALING RING	1 req	Avail to order Our Price: $23.56
33	008603902	OR RING	1 req	Current Stock: 18 Our Price: $0.60
34	008402201	SHIM ADJUSTMENT WASHER WC 20 D	1 req	Avail to order Our Price: $14.49
35	WHT003082	CYLINDER PINS 1707 H11 3X5	1 req	Current Stock: 41 Our Price: $0.80
36	005201902	LOWER REAR ARM SHIM ADJUSTMENT	1 req	Avail to order Our Price: $478.62
37	008802002	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
38	008402004	BRONZE WASHER 22 X 20 X 2	1 req	Avail to order Our Price: $152.08
39	008201603	NUT	1 req	Avail to order Our Price: $3.97
40	008401613	WASHER 16.5X30X3	1 req	Avail to order Our Price: $2.92
41	008202401	24X1 8G NUT	1 req	Current Stock: 1 Our Price: $3.40
42	005207790	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
43	005207789	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
44	004107796	LOWER ARM ADJUSTMENTSHIM	1 req	Avail to order Our Price: $28.02
45	004104694	REAR SUSPENSION FRONT LOWER CO	1 req	Avail to order Our Price: $444.29
46	008101705	SPECIAL SCREW M16X140	1 req	Avail to order Our Price: $62.14
47	008101610	SCREW	1 req	Current Stock: 1 Our Price: $56.81
48	008921702	SILBLOC RIV.89801584	1 req	Avail to order Our Price: $27.53
49	005100969	This item is no longer available	1 req
50	008401612	WASHER 16.5X35X4	1 req	Avail to order Our Price: $11.96
51	008401708	WASHER 17.5X26X3 AQ42	1 req	Current Stock: 1 Our Price: $2.92
52	008004284	COVER. 2AANON 25	1 req	Avail to order Our Price: $377.19
53	008201603	NUT	1 req	Avail to order Our Price: $3.97
54	008101610	SCREW	1 req	Current Stock: 1 Our Price: $56.81
55	008921702	SILBLOC RIV.89801584	1 req	Avail to order Our Price: $27.53
56	008201603	NUT	1 req	Avail to order Our Price: $3.97
57	008401303	WASHER	1 req	Avail to order Our Price: $20.13
58	008400803	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
59	008401707	WASHER 17.5X44X1.5	1 req	Avail to order Our Price: $17.89
60	008403501	ERTALON WASHER 30X45	1 req	Avail to order Our Price: $30.83
61	008403502	WASHER 32X44X1.5	1 req	Avail to order Our Price: $30.83
62	008101610	SCREW	1 req	Current Stock: 1 Our Price: $56.81
63	008401705	WASHER	1 req	Current Stock: 2 Our Price: $1.10
64	008401702	ELECTRICAL COUPLING WASHER	1 req	Avail to order Our Price: $11.96
65	005204764	NLA (NO LONGER AVAILABLE)	1 req	*See Description
66	005204766	NLA (NO LONGER AVAILABLE)	1 req	*See Description
67	008401705	WASHER	1 req	Current Stock: 2 Our Price: $1.10
68	008401706	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
69	008201603	NUT	1 req	Avail to order Our Price: $3.97
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
