1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $700.10
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $1,887.62
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $60.68
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $1,887.62
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.60
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.81
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,850.49

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $236.34

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 7 - Transmission Controls

1966-1972 Lamborghini Miura USA Transmission Controls (7)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002403143	NLA (NO LONGER AVAILABLE)	1 req	*See Description
2	002403142	CENTRAL PIN ROD	1 req	Avail to order Our Price: $60.98
3	002403143	NLA (NO LONGER AVAILABLE)	1 req	*See Description
4	002402851	5TH-REVERSE CONTROL ROD	1 req	Avail to order Our Price: $2,318.61
5	002402944	NLA (NO LONGER AVAILABLE)	1 req	*See Description
6	002402852	3RD-4TH GEAR CONTROLROD	1 req	Avail to order Our Price: $511.39
7	008100827	SCREW M8X25 UNI 5739/8G/ZG	1 req	Current Stock: 14 Our Price: $0.40
8	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
9	WHT002950	BOLT	1 req	Avail to order Our Price: $116.33
10	008410603	WASHER D.6.4 UNI 1751/ZD	1 req	Avail to order Our Price: $0.10
11	002402935	REAR ROD BUSHING	1 req	Avail to order Our Price: $272.08
12	002401765	GEAR LEVER BALL BUSHING	1 req	Avail to order Our Price: $20.32
13	008602101	RING 22 MM OR	1 req	Current Stock: 2 Our Price: $2.92
14	002402943	3RD/4TH SPEED CONTROL ROD FORK	1 req	Avail to order Our Price: $331.01
15	002402848	ROD CONTROL LEVER	1 req	Avail to order Our Price: $323.52
16	002402942	1ST/2ND SPEED CONTROL ROD FORK	1 req	Avail to order Our Price: $332.46
17	002402845	GEARBOX VERTICAL SHAFT	1 req	Avail to order Our Price: $112.70
18	002403246	GEARBOX SHAFT BALL SPRING	1 req	Avail to order Our Price: $6.71
19	N10439201	BALL RB 7.938/11 RIVSKF	1 req	Current Stock: 19 Our Price: $1.20
20	002403245	GEARBOX SHAFT BALL BUSHING	1 req	Avail to order Our Price: $62.53
21	002402836	This item is no longer available	1 req
22	008521602	BEARING	1 req	Avail to order Our Price: $31.21
23	002402940	VERTICAL SHAFT BUSHING	1 req	Avail to order Our Price: $184.85
24	008521602	BEARING	1 req	Avail to order Our Price: $31.21
25	002402846	GEAR SHAFT LOWER LEVER	1 req	Avail to order Our Price: $1,206.90
26	008100827	SCREW M8X25 UNI 5739/8G/ZG	1 req	Current Stock: 14 Our Price: $0.40
27	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $0.50
28	N10439201	BALL RB 7.938/11 RIVSKF	1 req	Current Stock: 19 Our Price: $1.20
29	86311249	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
30	002402838	This item is no longer available	1 req
31	002403293	INTERMEDIATE ROD PROTECTION PIPE	1 req	Avail to order Our Price: $426.54
32	002403292	REAR ROD BUSHING	1 req	Avail to order Our Price: $281.02
33	008602101	RING 22 MM OR	1 req	Current Stock: 2 Our Price: $2.92
34	008201808	18X1X8 NUT	1 req	Avail to order Our Price: $26.94
35	002403367	RODS FORK	1 req	Avail to order Our Price: $344.42
36	008611801	RING 18X26X4 DSD	1 req	Avail to order Our Price: $60.78
37	008801805	NLA	1 req	*See Description
38	002402850	1ST-2ND GEAR CONTROLROD	1 req	Avail to order Our Price: $344.42
39	002402932	1ST/2ND SPEED CONTROL FORK	1 req	Avail to order Our Price: $3,091.51
40	002402931	3RD/4TH SPEED CONTROL FORK	1 req	Avail to order Our Price: $1,278.25
41	008410603	WASHER D.6.4 UNI 1751/ZD	1 req	Avail to order Our Price: $0.10
42	WHT002950	BOLT	1 req	Avail to order Our Price: $116.33
43	002402930	5TH SPEED/REVERSE CONTROL FORK	1 req	Avail to order Our Price: $1,278.25
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
