1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $494.83
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $85.26

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $25.41

Drivetrain

PN	Item
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $2,182.79
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $759.18
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $2,047.05
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $65.85
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $548.16
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $52.14

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $544.80
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $102.16
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $23.86

Gaskets

PN	Item
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $974.68
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $377.98
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $2,006.76

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $256.29
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $162.79

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 93 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 27 - Steering Rack

1966-1972 Lamborghini Miura USA Steering Rack (27)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008101015	SCREW M10X40 UNI 5737/8G	1 req	Avail to order Our Price: $13.43
2	WHT000768	SPRING WASHER	1 req	Current Stock: 17 Our Price: $2.43
3	004303912	RH JOINT GUARD	1 req	Avail to order Our Price: $73.58
4	008101030	SCREW M10X50 UNI 5737 8G	1 req	Avail to order Our Price: $7.81
5	008401007	WASHER 21.5X10.4X2 UNI 6592/5S	1 req	Avail to order Our Price: $0.14
6	008101029	SCREW M10X70 UNI 5737/10K	1 req	Avail to order Our Price: $21.10
7	WHT000768	SPRING WASHER	1 req	Current Stock: 17 Our Price: $2.43
8	004308739	STEERING DAMPER	1 req	Avail to order Our Price: $399.40
9	N01118312	HEX.HEAD CLAMPING NUT	1 req	Avail to order Our Price: $2.43
10	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.40
11	008300614	STUD M6X18 UNI 5911 8G/ZD	1 req	Avail to order Our Price: $9.42
12	008830119	NLA (NO LONGER AVAILABLE)	1 req	*See Description
13	004303910	STEERING RACK COVER	1 req	Avail to order Our Price: $150.77
14	008401007	WASHER 21.5X10.4X2 UNI 6592/5S	1 req	Avail to order Our Price: $0.14
15	004303839	NLA (NO LONGER AVAILABLE)	1 req	*See Description
16	008411202	GEARBOX ARM RETAINING WASHER	1 req	Current Stock: 3 Our Price: $3.04
17	008201008	NUT	1 req	Current Stock: 2 Our Price: $1.06
18	004305186	RACK CASE ADJUSTMENTSHIM	1 req	Avail to order Our Price: $31.84
19	004305177	This item is no longer available	1 req
20	008411202	GEARBOX ARM RETAINING WASHER	1 req	Current Stock: 3 Our Price: $3.04
21	004303839	NLA (NO LONGER AVAILABLE)	1 req	*See Description
22	008201008	NUT	1 req	Current Stock: 2 Our Price: $1.06
23	WHT000768	SPRING WASHER	1 req	Current Stock: 17 Our Price: $2.43
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
