1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $521.78
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $90.02

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $28.85

Drivetrain

PN	Item
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $2,154.85
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $800.81
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $2,154.85
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $69.51
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $564.90
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 3 Our Price: $55.02

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $574.63
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $105.28
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 2 Our Price: $25.14

Gaskets

PN	Item
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,052.53
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA NLA GROMMET AND OIL SEALS SET JALPA - MIURA NO LONGER AVAILABLE TO ORDER FROM FACTORY.	Avail to order Our Price: $399.62
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $2,121.82

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $269.96
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $172.55

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 89 Our Price: $15.72

Open All

Select Group and TAV

< Previous Next >

TAV: 12 - Water Pump

1966-1972 Lamborghini Miura USA Water Pump (12)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008201005	M10 UNI 5721-65 SPECIAL NU	1 req	Avail to order Our Price: $15.57
2	WHT000768	SPRING WASHER	1 req	Current Stock: 15 Our Price: $2.18
3	001712751	COOLANT PUMP IMPELLER	1 req	Avail to order Our Price: $4,375.66
4	001700396	This item is no longer available	1 req
5	008611703	SEAL	1 req	Avail to order Our Price: $457.39
6	008401710	FLAT WASHER 17X34X1	1 req	Current Stock: 21 Our Price: $46.28
7	001701783	WASHER	1 req	Avail to order Our Price: $10.64
8	001704506	COOLANT INLET PIPE	1 req	Avail to order Our Price: $1,486.06
9	008835004	CLAMP	1 req	Avail to order Our Price: $12.42
10	001703761	COOLANT PUMP OUTLET PIPE	1 req	Avail to order Our Price: $122.16
11	001703592	COOLANT PUMP SEAL	1 req	Avail to order Our Price: $10.56
12	008602303	RING 24 MM OR	1 req	Current Stock: 18 Our Price: $0.70
13	008300608	NLA (NO LONGER AVAILABLE)	1 req	*See Description
14	N01152427	WASHER	1 req	Current Stock: 11 Our Price: $0.40
15	N01118312	HEX.HEAD CLAMPING NUT	1 req	Avail to order Our Price: $2.46
16	001703776	HEAD COOLANT OUTLET UNION	1 req	Avail to order Our Price: $2,658.39
17	001801333	OIL & COOLANT TEMPERATURE THERMOMETER	1 req	Avail to order Our Price: $172.55
18	008573202	O-RING I 30 UNI 3654	1 req	Avail to order Our Price: $6.20
19	008611704	OIL SEAL	1 req	Current Stock: 11 Our Price: $612.59
20	001700392	COOLANT PUMP COVER SEAL	1 req	Avail to order Our Price: $10.22
21	008200608	NUT	1 req	Avail to order Our Price: $6.62
22	N01152427	WASHER	1 req	Current Stock: 11 Our Price: $0.40
23	WHT003165	TAP END STUD	1 req	Current Stock: 3 Our Price: $1.80
24	001703590	COOLANT PUMP CASING	1 req	Avail to order Our Price: $1,545.52
25	008860401	TAB 4X4X12	1 req	Avail to order Our Price: $35.99
26	008300608	NLA (NO LONGER AVAILABLE)	1 req	*See Description
27	N01118312	HEX.HEAD CLAMPING NUT	1 req	Avail to order Our Price: $2.46
28	N01152427	WASHER	1 req	Current Stock: 11 Our Price: $0.40
29	008300618	STUD M6X38 UNI 5911 8G Z	1 req	Avail to order Our Price: $37.86
30	001702884	MIURA COOLANT PUMP COVER	1 req	Avail to order Our Price: $2,295.15
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
