1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $506.32
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $87.35

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $27.99

Drivetrain

PN	Item
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $548.16
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 4 Our Price: $53.39
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $2,034.84
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $777.08
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $2,090.68
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $67.45

Fuel-Air

PN	Item
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 2 Our Price: $24.39
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $102.16
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $557.60

Gaskets

PN	Item
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,994.85
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA NLA GROMMET AND OIL SEALS SET JALPA - MIURA NO LONGER AVAILABLE TO ORDER FROM FACTORY.	Avail to order Our Price: $387.78
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $990.43

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $167.43
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $261.96

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 89 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 4 - Timing

1966-1972 Lamborghini Miura USA Timing (4)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008860401	TAB 4X4X12	1 req	Avail to order Our Price: $34.92
2	008860501	This item is no longer available	1 req
3	001203728	This item is no longer available	1 req
4	001202917	VALVE BOWL	1 req	Avail to order Our Price: $319.16
5	001202840	This item is no longer available	1 req
6	001207349	ALTERNATOR GUIDE GEAR	1 req	Current Stock: 1 Our Price: $348.04
7	001207348	ALTERNATOR GUIDE GEAR SHAFT	1 req	Avail to order Our Price: $413.94
8	001201072	VALVE CLEARANCE SHIM	1 req	Avail to order Our Price: $42.38
9	001200233	VALVE RETAINER COTTERS	1 req	Avail to order Our Price: $31.80
10	001200228	VALVE PLATE	1 req	Avail to order Our Price: $473.09
11	001200233	VALVE RETAINER COTTERS	1 req	Avail to order Our Price: $31.80
12	001201020	This item is no longer available	1 req
13	001200878	LH EXHAUST CAMSHAFT	1 req	Avail to order Our Price: $2,082.96
14	001202844	This item is no longer available	1 req
15	001203789	DISTRIBUTOR DRIVE SCREW	1 req	Avail to order Our Price: $229.14
16	001201020	This item is no longer available	1 req
17	001205257	VALVE OUTER SPRING	1 req	Avail to order Our Price: $139.77
18	001200388	This item is no longer available	1 req
19	001200388	This item is no longer available	1 req
20	001204414	VALVE GUIDE	1 req	Current Stock: 17 Our Price: $81.23
21	001200231	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
22	001201773	This item is no longer available	1 req
23	001207415	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
24	008523004	NLA (NO LONGER AVAILABLE)	1 req	*See Description
25	001204878	CHAIN TIGHTENER GEAR	1 req	Avail to order Our Price: $290.28
26	001200340	STOPPER PIN	1 req	Avail to order Our Price: $16.87
27	001202691	CHAIN GUIDE	1 req	Avail to order Our Price: $378.96
28	001200232	VALVE RETAINER	1 req	Avail to order Our Price: $72.81
29	001201774	EXHAUST VALVE	1 req	Avail to order Our Price: $346.06
30	001202471	SEE PN: 8401813 AND 1219425	1 req	Avail to order Our Price: $428.67
31	008522202	NLA (NO LONGER AVAILABLE)	1 req	*See Description
32	001207415	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
33	008603701	OR RING	1 req	Current Stock: 14 Our Price: $0.40
34	001200342	TIGHTENER ADJUSTMENTFLANGE	1 req	Avail to order Our Price: $419.31
35	008603701	OR RING	1 req	Current Stock: 14 Our Price: $0.40
36	008604201	RING 43 MM OR	1 req	Current Stock: 9 Our Price: $1.50
37	001200342	TIGHTENER ADJUSTMENTFLANGE	1 req	Avail to order Our Price: $419.31
38	001200343	DISTRIBUTION ADJUSTMENT DOWEL	1 req	Avail to order Our Price: $28.88
39	001200336	COVER	1 req	Avail to order Our Price: $392.46
40	008601702	RING 18 MM OR	1 req	Current Stock: 7 Our Price: $3.42
41	008501704	BEARING	1 req	Avail to order Our Price: $63.62
42	001207360	NLA (NO LONGER AVAILABLE)	1 req	*See Description
43	001205400	SPACER	1 req	Avail to order Our Price: $262.70
44	001202447	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
45	008601801	RING 19 MM OR	1 req	Avail to order Our Price: $13.77
46	001200333	This item is no longer available	1 req
47	008410803	WASHER 8.4X17X0.8 DIN 137/B	1 req	Avail to order Our Price: $0.10
48	008100616	SCREW M6X16 UNI 5739/5S/Z	1 req	Avail to order Our Price: $0.20
49	001200345	TIGHTENER DOWEL CHECK WASHER	1 req	Avail to order Our Price: $81.99
50	008411303	SNAP RING 21X13X2.5 UNI 175 1	1 req	Current Stock: 6 Our Price: $3.09
51	008201213	12 UNI 210 8G NUT	1 req	Avail to order Our Price: $5.85
52	008300616	STUD M6X50 UNI 5911 8G/Z	1 req	Avail to order Our Price: $41.18
53	008200060	This item is no longer available	1 req
54	N01152427	WASHER	1 req	Current Stock: 11 Our Price: $0.40
55	008101608	SCREW M16X35 UNI 5740/8G	1 req	Avail to order Our Price: $20.09
56	008411701	SNAP RING	1 req	Current Stock: 2 Our Price: $2.76
57	001200348	DOWEL CHECK WASHER	1 req	Avail to order Our Price: $17.57
58	001201964	DOWEL	1 req	Avail to order Our Price: $89.74
59	001202694	CAMSHAFT PINION	1 req	Avail to order Our Price: $1,515.70
60	001205195	NLA (NO LONGER AVAILABLE)	1 req	*See Description
61	001205195	NLA (NO LONGER AVAILABLE)	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
