1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $85.59
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $496.09

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $28.84

Drivetrain

PN	Item
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $2,154.80
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $761.39
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $2,048.78
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 3 Our Price: $43.87
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $564.90
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $66.09

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $546.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $105.28
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 2 Our Price: $23.90

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA NLA GROMMET AND OIL SEALS SET JALPA - MIURA NO LONGER AVAILABLE TO ORDER FROM FACTORY.	Avail to order Our Price: $379.94
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $987.05
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $2,017.37

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $164.05
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $256.67

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 88 Our Price: $15.72

Open All

Select Group and TAV

< Previous Next >

TAV: 24 - Handbrake

1966-1972 Lamborghini Miura USA Handbrake (24)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008820103	This item is no longer available	1 req
2	003303847	RH BRAKE CALIPER U-BOLT	1 req	Avail to order Our Price: $121.55
3	003301305	FORK	1 req	Avail to order Our Price: $118.02
4	410609789	PIN	1 req	Avail to order Our Price: $34.92
5	008820103	This item is no longer available	1 req
6	003303840	HANDBRAKE WIRING ASSEMBLY	1 req	Avail to order Our Price: $631.08
7	003301857	SHEATH TERMINAL	1 req	Avail to order Our Price: $4.56
8	003303843	HANDBRAKE BRACKET SEAL	1 req	Avail to order Our Price: $37.22
9	003303849	HANDBRAKE ADJUSTMENTBRACKET	1 req	Avail to order Our Price: $166.40
10	008580901	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
11	003303841	HANDBRAKE WIRE PULLEY	1 req	Avail to order Our Price: $131.24
12	003303846	HANDBRAKE PULLEY FORK	1 req	Avail to order Our Price: $56.92
13	003303842	BUSHING	1 req	Avail to order Our Price: $156.08
14	008100839	SCREW M8X10 UNI 5739/8G Z	1 req	Current Stock: 17 Our Price: $0.60
15	WHT001514	SPRING WASHER	1 req	Current Stock: 9 Our Price: $28.16
16	003203844	This item is no longer available	1 req
17	008410603	WASHER D.6.4 UNI 1751/ZD	1 req	Avail to order Our Price: $0.10
18	008100625	SCREW M6X16 UNI 5739/8G/Z	1 req	Avail to order Our Price: $125.72
19	008200806	NUT	1 req	Current Stock: 25 Our Price: $0.40
20	004201651	ACCELERATOR WIRE ADJUSTMENT SC	1 req	Avail to order Our Price: $1,045.53
21	003303845	NLA (NO LONGER AVAILABLE)	1 req	*See Description
22	N0122094	WASHER	1 req	Current Stock: 5 Our Price: $1.92
23	003303848	LH BRAKE CALIPER U-BOLT	1 req	Avail to order Our Price: $121.55
24	003301305	FORK	1 req	Avail to order Our Price: $118.02
25	410609789	PIN	1 req	Avail to order Our Price: $34.92
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
