1966-1972 Miura - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA		Avail to order Our Price: $456.30
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD		Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002103598	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $700.10
002105449	CLUTCH PLATE CLUTCH PLATE COMPLETE	Avail to order Our Price: $1,887.62
002126614	ENGINE FLYWHEEL MUIRA ENGINE FLYWHEEL DISCONTINUED - NLA - CONTACT US	Current Stock: 1 Our Price: $697.64
008502505	SEE PN 086311430A BEARING	Avail to order Our Price: $60.68
290400000	MIURA PRE-ASSEMBLED CLUTCH CYL MIURA PRE-ASSEMBLED CLUTCH CYL	Avail to order Our Price: $1,887.62
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.60
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.81
001526483	MIURA ENGINE GASKET KIT ENGINE GASKET KIT SEE PN 001526463 FOR SEALS	Avail to order Our Price: $1,850.49

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
002409171	DISCONTINUED - NLA REVERSE LIGHT SWITCH		Avail to order Our Price: $236.34

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 19 - Front Suspension

1966-1972 Lamborghini Miura USA Front Suspension (19)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Miura Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	005205680	REAR SHOCK ABSORBER BULKHEAD	1 req	Avail to order Our Price: $116.23
2	008201603	NUT	1 req	Avail to order Our Price: $3.97
3	008401708	WASHER 17.5X26X3 AQ42	1 req	Current Stock: 1 Our Price: $2.92
4	008401709	NLA (NO LONGER AVAILABLE)	1 req	*See Description
5	008401705	WASHER	1 req	Current Stock: 2 Our Price: $1.10
6	008401702	ELECTRICAL COUPLING WASHER	1 req	Avail to order Our Price: $11.96
7	008401705	WASHER	1 req	Current Stock: 2 Our Price: $1.10
8	008101617	SCREW 16X1.5X79 CH2410K	1 req	Avail to order Our Price: $131.95
9	005105416	FRONT SUSPENSION UPPER ARM	1 req	Avail to order Our Price: $1,157.85
10	008200804	NUT	1 req	Current Stock: 7 Our Price: $1.20
11	008400803	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
12	005100961	UPPER BALL JOINT	1 req	Avail to order Our Price: $240.80
13	008911702	This item is no longer available	1 req
14	008401705	WASHER	1 req	Current Stock: 2 Our Price: $1.10
15	008101617	SCREW 16X1.5X79 CH2410K	1 req	Avail to order Our Price: $131.95
16	005100708	LH FRONT LOWER ARM	1 req	Avail to order Our Price: $2,378.13
17	005100928	RH FRONT LOWER ARM	1 req	Avail to order Our Price: $2,378.13
18	008101016	SPECIAL SCREW	1 req	Avail to order Our Price: $27.71
19	008820301	SPLIT PIN 3.7X35 UNI 1336B	1 req	Avail to order Our Price: $2.92
20	005100555	LOWER BALL JOINT	1 req	Avail to order Our Price: $790.17
21	008401614	ALLEN SCREW WASHER RPR 16	1 req	Avail to order Our Price: $23.92
22	005100527	UPPER JOINT ATTACHMENT SHEET	1 req	Avail to order Our Price: $1,664.65
23	008401705	WASHER	1 req	Current Stock: 2 Our Price: $1.10
24	008401709	NLA (NO LONGER AVAILABLE)	1 req	*See Description
25	008401708	WASHER 17.5X26X3 AQ42	1 req	Current Stock: 1 Our Price: $2.92
26	008201603	NUT	1 req	Avail to order Our Price: $3.97
27	008201212	NUT	1 req	Current Stock: 1 Our Price: $2.04
28	008401304	WASHER 13X24X3 UNI 1734	1 req	Avail to order Our Price: $2.92
29	005100555	LOWER BALL JOINT	1 req	Avail to order Our Price: $790.17
30	008101217	NLA (NO LONGER AVAILABLE)	1 req	*See Description
31	008401006	WASHER 22X10.5X2.5 UNI 1734/5S	1 req	Current Stock: 1 Our Price: $0.60
32	008201010	M10SELF LOCKING NUT	1 req	Avail to order Our Price: $1.50
33	008201007	M10X1SELF-LOCKINGNUT	1 req	Avail to order Our Price: $8.85
34	008701003	SCREW 10X1X21 8G	1 req	Avail to order Our Price: $109.40
35	005101056	TORSION BAR U-BOLT	1 req	Avail to order Our Price: $125.63
36	008922002	BAR MOUNT 20	1 req	Avail to order Our Price: $63.79
37	008922002	BAR MOUNT 20	1 req	Avail to order Our Price: $63.79
38	005105207	NLA (NO LONGER AVAILABLE)	1 req	*See Description
39	005101047	TORSION BAR U-BOLT	1 req	Avail to order Our Price: $126.70
40	008411005	WASHER D.10.5 UNI 1751/F	1 req	Avail to order Our Price: $0.10
41	008101014	SCREW M10X20 UNI 5739/8G	1 req	Avail to order Our Price: $13.47
42	008401612	WASHER 16.5X35X4	1 req	Avail to order Our Price: $11.96
43	008401611	WASHER 17X29X3 5S UNI 16592	1 req	Avail to order Our Price: $16.43
44	008201603	NUT	1 req	Avail to order Our Price: $3.97
45	005105032	FRONT SHOCK ABSORBER	1 req	Avail to order Our Price: $1,028.53
46	008101616	SCREW 16X1.5X72 38NCD4	1 req	Avail to order Our Price: $45.41
47	008101615	SCREW 16X1.5X252 CH27 8G	1 req	Avail to order Our Price: $164.22
48	008401611	WASHER 17X29X3 5S UNI 16592	1 req	Avail to order Our Price: $16.43
49	005103721	FRONT SHOCK ABSORBERSPRING	1 req	Avail to order Our Price: $1,857.86
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
