1990 Lamborghini LM002 USA Spec USA Wijndscreen and Wash/Wire (107.00)

Maintenance Parts:

Belts

PN	Item	Diagram
001626952	Pump Belt Pump Belt		Avail to order Our Price: $145.82
001726951	NLA (No Longer Available) Pump Belt		Avail to order Our Price: $108.45
001609853	Alternator Drive Belt - NLA Alternator Drive Belt		Avail to order Our Price: $85.87

Brakes

PN	Item	Diagram
003126137	Brake Pad Front LM002 - SOLD Individually (1 Pad) Pads		Current Stock: 2 Our Price: $22.16

Drivetrain

PN	Item	Diagram
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.		Avail to order Our Price: $81.81
002128930	NLA (No Longer Available) Spare Part Lm Clutch Cylinder see pn 002136948		Avail to order Our Price: $183.18
0017002473	Water Pump (2WD w/o Power Stearing) (1991-1994) Coolant Pump 2WD W/o		Avail to order Our Price: $5,017.25
002124587	Cp 2789 Thrust Plate Cp 2789 Thrust Plate		Avail to order Our Price: $2,924.92
002126615	Flywheel/Engine Assembly Flywheel/Engine Assembly		Avail to order Our Price: $5,343.04
002127409	Clutch Plate Clutch Plate		Avail to order Our Price: $1,293.04

Fuel-Air

PN	Item	Diagram
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A		Current Stock: 1 Our Price: $29.72
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER		Avail to order Our Price: $274.81
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector		Avail to order Our Price: $377.42
002024398	Fuel Pump Fuel Pump		Current Stock: 1 Our Price: $719.65
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve		Avail to order Our Price: $264.00

Gaskets

PN	Item	Diagram
001526477	LM002 EURO - Grommet & Oil Seals Set Grommet & Oil Seals Set		Avail to order Our Price: $1,455.22
001526478	Grommet & Oil Seals Set Grommet & Oil Seals Set		Avail to order Our Price: $276.57
001526497	NLA (No Longer Available) Engine Gasket Kit see pn 001526477 for seal kit		Avail to order Our Price: $1,392.96
001526498	LM002 USA Engine Gasket Set Engine Gasket Kit see pn 001526478 for seals		Avail to order Our Price: $951.32

Ignition

PN	Item	Diagram
001627730	NLA (No Longer Available) Rotor		Avail to order Our Price: $1,853.41
001628406	Spark Plug Wire Assembly Spark Plug Wire Assembly		Avail to order Our Price: $1,549.34
001630009	Spark Plug - 12mm Spark Plug		Avail to order Our Price: $36.53
001625386	Spark Plug Wires & Bracket Spark Plug Wires & Bracket for LM002		Avail to order Our Price: $1,729.80
001627730R	Rotor Brush 1991 - 1994 Diablos OE Spec - Rotating Brush		Avail to order Our Price: $307.89
0072004164	Key Blank - Door - LM002 Raw Lm Door Key		Current Stock: 13 Our Price: $142.11

Misc

PN	Item	Diagram
001235193	Chain Tightener Tappet Bracket Chain Tightener Tappet Bracket LM002		Current Stock: 1 Our Price: $448.89
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut		Avail to order Our Price: $1.87
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.		Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement		Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor		Current Stock: 1 Our Price: $287.75
0017006576	NLA (No Longer Available) WATER THERMOSTAT		Avail to order Our Price: $511.14
002424598	Lm Reversing Switch Lm Reversing Switch		Avail to order Our Price: $109.65
07M905381	Phase Sensor Phase Sensor		Avail to order Our Price: $658.83
004429307	SEE PN 0R1470226 Lambda Sensor		Avail to order Our Price: $409.78

Open All

Select Group and TAV

< Previous Next >

TAV: 107.00 - Wijndscreen and Wash/Wire

1990 Lamborghini LM002 USA Spec USA Wijndscreen and Wash/Wire (107.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	009220003	NLA (No Longer Available)	2 req	*See Description
2	009220004	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
3	009220002	NLA (No Longer Available)	2 req	*See Description
4	009220008	Outs.Bowden Guide Pipe	1 req	Avail to order Our Price: $156.54
5	009220007	Centr.Bowden GuidePipe	1 req	Avail to order Our Price: $156.54
6	009220006	Engine Side BowdenGuide Pipe	1 req	Avail to order Our Price: $156.54
7	009220009	Cable Cover Pipe 1p.Union	1 req	Avail to order Our Price: $16.80
8	009220020	This item is no longer available	1 req
9	009220016	No Longer Available	1 req	Avail to order Our Price: $171.25
10	009220019	This item is no longer available	1 req
11	009220018	This item is no longer available	1 req
12	006120166	Nozzle	2 req	Avail to order Our Price: $50.11
13	009220028	N.R.Valve	2 req	Avail to order Our Price: $75.63
14	007014168	Y Union Y S4 77000	1 req	Avail to order Our Price: $26.67
15	009220026	This item is no longer available	0 req
16	0071010737	TANK	1 req	Avail to order Our Price: $70.69
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
