TAV: 019.00 - Transfer (Oil Pump)

1990 Lamborghini LM002 USA Spec USA Transfer (Oil Pump) (019.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002721727	Gear	2 req	Avail to order Our Price: $1,228.01
2	002723131	Gear	1 req	Avail to order Our Price: $1,593.98
3	008300833	SEE PN WHT003030	3 req	Avail to order Our Price: $6.58
4	002722581	Oil Pump Shim	1 req	Avail to order Our Price: $243.03
5	008300834	Stud M8x80 Uni 5911 8g Z	2 req	Avail to order Our Price: $19.09
6	008611204	Oil Seal mm 12x22x7 mm	2 req	Avail to order Our Price: $15.23
7	002721737	Oil Pump Adjustment Shim	1 req	Avail to order Our Price: $58.94
8	002721740	Gear	1 req	Avail to order Our Price: $1,059.32
9	008910301	Ball Rivrb-3.969/1205	1 req	Current Stock: 3 Our Price: $2.65
10	002723128	Gearbox Oil Pump Casing	1 req	Avail to order Our Price: $716.22
11	002723132	Seal	1 req	Avail to order Our Price: $30.74
12	002726719	Electrical Odometer Bracket	1 req	Avail to order Our Price: $343.18
13	WHT001514	SPRING WASHER	5 req	Current Stock: 9 Our Price: $25.05
14	008200806	M8 Uni 5588/8g/Z Nut	5 req	Current Stock: 25 Our Price: $2.00
15	008700606	Screw Ei M6x1x10 12kd	1 req	Current Stock: 37 Our Price: $2.00
16	002723134	Plug	1 req	Avail to order Our Price: $31.06
17	008601801	Ring 19 mm Or	1 req	Avail to order Our Price: $11.73
18	002726721	Electrical Odometer Bracket Co	1 req	Avail to order Our Price: $122.81
19	002726720	Electrical Odometer Drive	1 req	Avail to order Our Price: $187.28
20	0R1320001	NLA (No Longer Available)	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
