1990 Lamborghini LM002 USA Spec USA Steering Controls (027.00)

Maintenance Parts:

Belts

PN	Item
001726951	PUMP BELT PUMP BELT NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $114.58
001626952	Pump Belt Pump Belt	Avail to order Our Price: $157.33
001609853	Alternator Drive Belt Alternator Drive Belt	Avail to order Our Price: $90.83

Brakes

PN	Item	Diagram
003126137	Brake Pad Front LM002 - SOLD Individually (1 Pad) Pads		Current Stock: 2 Our Price: $23.82

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 20 Our Price: $86.47
002128930	NLA (No Longer Available) Spare Part Lm Clutch Cylinder see pn 002136948	Avail to order Our Price: $193.98
002124587	NLA (No Longer Available) Cp 2789 Thrust Plate	Avail to order Our Price: $3,098.98
002127409	Clutch Plate Clutch Plate	Avail to order Our Price: $1,367.44
002126615	Flywheel/Engine Assembly Flywheel/Engine Assembly	Avail to order Our Price: $5,655.38
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,306.11

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 4 Our Price: $31.73
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.16
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.49
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $760.98
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $273.87

Gaskets

PN	Item
001526497	NLA (No Longer Available) Engine Gasket Kit see pn 001526477 for seal kit	Avail to order Our Price: $1,472.91
001526477	LM002 EURO - Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $1,545.81
001526498	LM002 USA Engine Gasket Set Engine Gasket Kit see pn 001526478 for seals	Avail to order Our Price: $1,006.24
001526478	Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $292.86

Ignition

PN	Item
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement	Current Stock: 2 Our Price: $289.00
001628406	Spark Plug Wire Assembly Spark Plug Wire Assembly	Avail to order Our Price: $1,634.99
001630009	Spark Plug - 12mm Spark Plug	Avail to order Our Price: $39.29
001625386	Spark Plug Wires & Bracket Spark Plug Wires & Bracket for LM002	Avail to order Our Price: $1,856.21
0072004164	Key Blank - Door - LM002 Raw Lm Door Key	Current Stock: 13 Our Price: $152.86

Misc

PN	Item
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
001235193	Chain Tightener Tappet Bracket Chain Tightener Tappet Bracket LM002	Current Stock: 1 Our Price: $481.53
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Avail to order Our Price: $308.20
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $541.02
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.10
002424598	Lm Reversing Switch Lm Reversing Switch	Avail to order Our Price: $117.76
0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	Current Stock: 4 Our Price: $393.22

Tools and Tookits

PN	Item	Diagram
wheeltool	Wheel install tool Screws into hub for easy installation.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 027.00 - Steering Controls

1990 Lamborghini LM002 USA Spec USA Steering Controls (027.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.43
2	008581801	O-Ring E 20 Uni 7435-75	4 req	Current Stock: 18 Our Price: $2.00
3	008582007	This item is no longer available	2 req
4	004301397	Indicator Return Lever Pin	1 req	Avail to order Our Price: $27.71
5	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $2.00
6	008574501	O-Ring I 42 Uni 3654	1 req	Current Stock: 7 Our Price: $2.04
7	004309646	Steering Wheel LowerBracket	1 req	Avail to order Our Price: $736.50
8	004309665	Shim	4 req	Avail to order Our Price: $14.29
9	WHT003079	Reference Pin 8h7x6.25x10	2 req	Avail to order Our Price: $35.69
10	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	4 req	Current Stock: 5 Our Price: $2.00
11	N01024230	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $2.00
12	004309680	Steering Wheel Plate	1 req	Avail to order Our Price: $12.74
13	004308364	Discontinued - NLA	1 req	*See Description
14	008700408	Screw M4x10 Uni 5931/8g/Z	1 req	Avail to order Our Price: $2.00
15	008700308	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
16	008401417	Washer 15x25x2 Uni 1736/Zd Aq4	1 req	Current Stock: 1 Our Price: $3.40
17	004325868	This item is no longer available	1 req
18	004325872	This item is no longer available	1 req
19	004325871	This item is no longer available	1 req
20	004325873	Horn Button	1 req	Avail to order Our Price: $83.24
21	N01033520	HEXAGON HEAD BOLT	2 req	Current Stock: 6 Our Price: $2.00
22	004309787	Steering Column Joint	1 req	Avail to order Our Price: $468.11
23	004309661	Upper Steering Column	1 req	Avail to order Our Price: $383.13
24	008700601	Screw M6x30 Uni 59318g/Z	4 req	Avail to order Our Price: $6.81
25	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
26	004326386	This item is no longer available	1 req
27	004309647	Steering Wheel UpperBracket	1 req	Avail to order Our Price: $651.51
28	004325870	Bellows	1 req	Avail to order Our Price: $14.29
29	008700613	Screw M6x14 Uni 5933/8g/Zb	4 req	Avail to order Our Price: $2.00
30	004321591	This item is no longer available	1 req
31	WHT003099	NUT	1 req	Avail to order Our Price: $17.87
32	008700501	Screw M5x10 Uni 5933/12k/F	6 req	Current Stock: 3 Our Price: $3.11
33	004325869	This item is no longer available	1 req
34	004329714	This item is no longer available	1 req
35	008602401	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
36	008612508	Oil Seal	1 req	Avail to order Our Price: $30.53
37	004322401	Column Play Take-Up Shaft	1 req	Avail to order Our Price: $468.11
38	008100603	Screw M6x25 Uni 5739-8g Zg	1 req	Avail to order Our Price: $2.00
39	008100620	Screw M6x12 Uni 5739/5s/Z	2 req	Avail to order Our Price: $6.81
40	004323090	Steering Column Bellows	1 req	Avail to order Our Price: $33.65
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
