1990 Lamborghini LM002 USA Spec USA Stub Axle-Susp.Levers (031.00)

Maintenance Parts:

Belts

PN	Item
001726951	PUMP BELT PUMP BELT NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $114.58
001626952	Pump Belt Pump Belt	Avail to order Our Price: $157.33
001609853	Alternator Drive Belt Alternator Drive Belt	Avail to order Our Price: $90.83

Brakes

PN	Item	Diagram
003126137	Brake Pad Front LM002 - SOLD Individually (1 Pad) Pads		Current Stock: 2 Our Price: $23.82

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 20 Our Price: $86.47
002128930	NLA (No Longer Available) Spare Part Lm Clutch Cylinder see pn 002136948	Avail to order Our Price: $193.98
002124587	NLA (No Longer Available) Cp 2789 Thrust Plate	Avail to order Our Price: $3,098.98
002127409	Clutch Plate Clutch Plate	Avail to order Our Price: $1,367.44
002126615	Flywheel/Engine Assembly Flywheel/Engine Assembly	Avail to order Our Price: $5,655.38
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,306.11

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 4 Our Price: $31.73
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.16
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.49
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $760.98
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $273.87

Gaskets

PN	Item
001526497	NLA (No Longer Available) Engine Gasket Kit see pn 001526477 for seal kit	Avail to order Our Price: $1,472.91
001526477	LM002 EURO - Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $1,545.81
001526498	LM002 USA Engine Gasket Set Engine Gasket Kit see pn 001526478 for seals	Avail to order Our Price: $1,006.24
001526478	Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $292.86

Ignition

PN	Item
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement	Current Stock: 2 Our Price: $289.00
001628406	Spark Plug Wire Assembly Spark Plug Wire Assembly	Avail to order Our Price: $1,634.99
001630009	Spark Plug - 12mm Spark Plug	Avail to order Our Price: $39.29
001625386	Spark Plug Wires & Bracket Spark Plug Wires & Bracket for LM002	Avail to order Our Price: $1,856.21
0072004164	Key Blank - Door - LM002 Raw Lm Door Key	Current Stock: 13 Our Price: $152.86

Misc

PN	Item
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
001235193	Chain Tightener Tappet Bracket Chain Tightener Tappet Bracket LM002	Current Stock: 1 Our Price: $481.53
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Avail to order Our Price: $308.20
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $541.02
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.10
002424598	Lm Reversing Switch Lm Reversing Switch	Avail to order Our Price: $117.76
0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	Current Stock: 4 Our Price: $393.22

Tools and Tookits

PN	Item	Diagram
wheeltool	Wheel install tool Screws into hub for easy installation.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 031.00 - Stub Axle-Susp.Levers

1990 Lamborghini LM002 USA Spec USA Stub Axle-Susp.Levers (031.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	005121645	No Longer Available	2 req	Avail to order Our Price: $101.89
2	008201219	M12x1.75x11.8 Nut	4 req	Current Stock: 3 Our Price: $4.47
3	005124126	Ball Joint	2 req	Avail to order Our Price: $258.66
4	005124125	Roll Bar Link Bushing	2 req	Avail to order Our Price: $35.87
5	008201411	M14 Uni 5589 8g/ZNut	2 req	Avail to order Our Price: $19.64
6	005124127	Ball Joint	2 req	Avail to order Our Price: $430.87
7	005122198	Rh Upper Arm	1 req	Avail to order Our Price: $2,430.22
7	005122199	Lh Upper Arm	1 req	Avail to order Our Price: $2,430.22
8	005123927	Roll Bar	1 req	Avail to order Our Price: $655.98
9	005122598	Brackets	2 req	Current Stock: 2 Our Price: $138.86
10	005113991	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
11	N01100632	HEX.NUT	4 req	Avail to order Our Price: $4.95
12	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
13	005122597	Roll Bar Half Casing	4 req	Avail to order Our Price: $97.34
14	008100626	Screw M6x35 Uni 5737/8g	4 req	Avail to order Our Price: $2.00
15	008411206	Snap Ring A 12 Uni 1751	4 req	Avail to order Our Price: $2.92
16	008101227	Screw M12x1.25x20/8g/Zd	4 req	Avail to order Our Price: $6.90
17	005121657	Hub Control	2 req	Avail to order Our Price: $615.72
18	008700639	Screw M6x14 Uni 592512k/F	6 req	Avail to order Our Price: $37.23
19	005121654	Front Drive CouplingCam	2 req	Avail to order Our Price: $164.72
20	005121656	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
21	008850405	Reference Pin 4s6x14C40	6 req	Avail to order Our Price: $6.81
22	005121655	Front Traction Engaging Sleeve	2 req	Avail to order Our Price: $188.65
23	005121653	Front Suspension HubRetainer W	2 req	Avail to order Our Price: $5.93
24	008576601	O-Ring I 62 Uni 3654	2 req	Avail to order Our Price: $2.00
25	008503509	Bearing	2 req	Avail to order Our Price: $60.68
26	008608001	Ring 78 mm Or	2 req	Avail to order Our Price: $2.00
27	005121524	Front Hub	2 req	Avail to order Our Price: $982.51
28	008524007	Roller Bearing	2 req	Avail to order Our Price: $71.86
29	008575000	O-Ring I 50 Uni 3654	2 req	Avail to order Our Price: $2.00
30	008582701	O-Ring E 30 Uni 7435-75	2 req	Current Stock: 9 Our Price: $2.33
31	008403005	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
32	002522320	Front Drive Clutch Pinions	2 req	Avail to order Our Price: $98.12
33	005123659	Rh Hub Holder	1 req	Avail to order Our Price: $963.16
33	005123660	Lh Hub Carrier	1 req	Avail to order Our Price: $963.16
34	008619005	OIL SEAL	2 req	Avail to order Our Price: $25.38
35	008619006	OIL SEAL	2 req	Avail to order Our Price: $23.82
36	008507001	Bearing	4 req	Avail to order Our Price: $103.17
37	005121522	Front Hub Carrier Cover	2 req	Avail to order Our Price: $360.86
38	008614002	OIL SEAL	2 req	Avail to order Our Price: $26.74
39	008614001	OIL SEAL	2 req	Avail to order Our Price: $58.44
40	008202404	M24x1.5 Special Nut	4 req	Avail to order Our Price: $23.82
41	005126116	Ring Nut	2 req	Avail to order Our Price: $477.06
42	005121523	Spacer	0 req	Avail to order Our Price: $55.72
43	008609909	Or	2 req	Avail to order Our Price: $2.00
44	008700617	Screw M6x18 Uni 5931/8g/Z	16 req	Current Stock: 1 Our Price: $2.00
45	005121976	Hub Holder Joint Bushing	2 req	Avail to order Our Price: $39.77
46	WHT003355	clamping nut	8 req	Current Stock: 13 Our Price: $23.50
47	005121601	Inner Upper Ball Joint	4 req	Avail to order Our Price: $1,813.26
48	005121600	Upper/Lower Ball Joint Bracket	4 req	Avail to order Our Price: $933.44
50	008101213	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
51	005122151	Rh Front Suspension Lower Arm	1 req	Avail to order Our Price: $2,079.87
51	005122152	Lh Front Suspension Lower Arm	1 req	Avail to order Our Price: $2,079.87
52	005121458	Suspension Arm Bushing	8 req	Avail to order Our Price: $462.18
53	005126522	Suspension Lower Control Arm A	4 req	Avail to order Our Price: $92.77
54	008102001	Special Screw M20x1.5x91	8 req	Avail to order Our Price: $28.98
55	008202008	20x17.5 8g/Zp Nut	8 req	Avail to order Our Price: $14.00
56	005121626	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	0 req	*See Description
57	WHT003355	clamping nut	16 req	Current Stock: 13 Our Price: $23.50
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
