TAV: 014.00 - Clutch

1990 Lamborghini LM002 USA Spec USA Clutch (014.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002128930	NLA (No Longer Available)	1 req	*See Description
2	002129425	LM002 CLUTCH PIN / PIECE	1 req	Avail to order Our Price: $70.37
3	008201011	M10 Uni 5589-65/8g Nut	1 req	Avail to order Our Price: $21.40
4	002128996	This item is no longer available	1 req
5	002121773	Rod Fork Fastening Pin	1 req	Avail to order Our Price: $20.28
6	004207085	Brake Cylinder Pin Stopper	2 req	Avail to order Our Price: $85.47
7	008100854	SCREW	4 req	Avail to order Our Price: $2.00
8	WHT001514	SPRING WASHER	4 req	Current Stock: 9 Our Price: $26.80
9	002121785	Clutch Cylinder Bracket	1 req	Avail to order Our Price: $264.64
10	008583701	O-Ring E 37 Uni 7435-75	1 req	Current Stock: 8 Our Price: $2.00
11	002121777	Clutch Lever & Pin Assembly	1 req	Avail to order Our Price: $201.28
12	008522506	Bearing	3 req	Avail to order Our Price: $53.31
13	002124765	Pipe From Clutch Cylinder To C	1 req	Avail to order Our Price: $474.11
14	002126635	This item is no longer available	1 req
15	002121778	Clutch Control Fork	1 req	Avail to order Our Price: $344.40
16	008801210	Bushing 12x14x15 mm	2 req	Avail to order Our Price: $42.05
17	002121770	Clutch Control Fork Pin	2 req	Avail to order Our Price: $86.33
18	008900802	Pin Din 1481 8x36x1.5	2 req	Current Stock: 1 Our Price: $8.80
19	008900503	Elastic Pin 5x36 Din1481	2 req	Current Stock: 18 Our Price: $2.00
20	WHT003055	Washer 13x24x1.2 Din137/B C72	6 req	Current Stock: 10 Our Price: $2.00
21	008201210	M12x1.5x12 Uni 5587/8g/Z N	6 req	Avail to order Our Price: $16.40
22	002121775	Fork Thrust Sleeve	1 req	Avail to order Our Price: $318.82
23	N0152785	WASHER	3 req	Current Stock: 71 Our Price: $2.00
24	008100830	Screw M8x20 Uni 5739/8g/Z	3 req	Current Stock: 19 Our Price: $2.00
25	002128042	Clutch Thrust Sleeve	1 req	Avail to order Our Price: $1,268.43
26	008505002	Bearing	1 req	Current Stock: 3 Our Price: $123.42
27	N0123501	RETAINER RING	1 req	Current Stock: 7 Our Price: $8.04
28	002121780	Flange	1 req	Avail to order Our Price: $1,244.04
29	002124587	NLA (No Longer Available)	1 req	*See Description
30	002121786	Reference Pin for Engine & Clu	3 req	Avail to order Our Price: $34.44
31	002127409	Clutch Plate	1 req	Avail to order Our Price: $1,367.41
32	002126615	Flywheel/Engine Assembly	1 req	Avail to order Our Price: $5,655.40
33	008101014	Screw M10x20 Uni 5739/8g	6 req	Avail to order Our Price: $13.46
34	008411005	Washer D.10.5 Uni 1751/F	6 req	Avail to order Our Price: $2.00
35	008100838	Special Screw M8x25	8 req	Avail to order Our Price: $16.13
36	410141179	RETAINING PART	4 req	Avail to order Our Price: $68.12
37	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $46.98
38	008614205	Oil Scraper	1 req	Avail to order Our Price: $22.14
39	008521300	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
