1990 Lamborghini LM002 USA Spec USA Camshafts and Valves (002.00)

Maintenance Parts:

Belts

PN	Item
001726951	PUMP BELT PUMP BELT NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $114.58
001626952	Pump Belt Pump Belt	Avail to order Our Price: $157.33
001609853	Alternator Drive Belt Alternator Drive Belt	Avail to order Our Price: $90.83

Brakes

PN	Item	Diagram
003126137	Brake Pad Front LM002 - SOLD Individually (1 Pad) Pads		Current Stock: 2 Our Price: $23.82

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 20 Our Price: $86.47
002128930	NLA (No Longer Available) Spare Part Lm Clutch Cylinder see pn 002136948	Avail to order Our Price: $193.98
002124587	NLA (No Longer Available) Cp 2789 Thrust Plate	Avail to order Our Price: $3,098.98
002127409	Clutch Plate Clutch Plate	Avail to order Our Price: $1,367.44
002126615	Flywheel/Engine Assembly Flywheel/Engine Assembly	Avail to order Our Price: $5,655.38
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,306.11

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 4 Our Price: $31.73
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.16
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.49
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $760.98
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $273.87

Gaskets

PN	Item
001526497	NLA (No Longer Available) Engine Gasket Kit see pn 001526477 for seal kit	Avail to order Our Price: $1,472.91
001526477	LM002 EURO - Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $1,545.81
001526498	LM002 USA Engine Gasket Set Engine Gasket Kit see pn 001526478 for seals	Avail to order Our Price: $1,006.24
001526478	Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $292.86

Ignition

PN	Item
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement	Current Stock: 2 Our Price: $289.00
001628406	Spark Plug Wire Assembly Spark Plug Wire Assembly	Avail to order Our Price: $1,634.99
001630009	Spark Plug - 12mm Spark Plug	Avail to order Our Price: $39.29
001625386	Spark Plug Wires & Bracket Spark Plug Wires & Bracket for LM002	Avail to order Our Price: $1,856.21
0072004164	Key Blank - Door - LM002 Raw Lm Door Key	Current Stock: 13 Our Price: $152.86

Misc

PN	Item
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
001235193	Chain Tightener Tappet Bracket Chain Tightener Tappet Bracket LM002	Current Stock: 1 Our Price: $481.53
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Avail to order Our Price: $308.20
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $541.02
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.10
002424598	Lm Reversing Switch Lm Reversing Switch	Avail to order Our Price: $117.76
0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	Current Stock: 4 Our Price: $393.22

Open All

Select Group and TAV

< Previous Next >

TAV: 002.00 - Camshafts and Valves

1990 Lamborghini LM002 USA Spec USA Camshafts and Valves (002.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001226785	Rh Exhaust Head Camshaft	1 req	Avail to order Our Price: $2,139.47
2	008931412	Plug	4 req	Avail to order Our Price: $110.08
3	001226784	Rh Intake Head Camshaft	1 req	Avail to order Our Price: $2,139.47
4	001226786	Lh Intake Head Camshaft	1 req	Avail to order Our Price: $2,139.47
5	001226787	Exhaust Lh Head Camshaft	1 req	Avail to order Our Price: $2,139.47
6	001231564	Upper Timing Chain	2 req	Avail to order Our Price: $717.15
7	001224809	Camshaft Drive Gear	4 req	Avail to order Our Price: $4,020.49
8	001219761	Washer	2 req	Avail to order Our Price: $108.23
9	001219762	Screw Lock Plate	3 req	Avail to order Our Price: $51.34
10	001227490	Low Pressure Oil Pump Driving	2 req	Avail to order Our Price: $181.16
10	001228421	Oil Pump Timing GearFastening	2 req	Avail to order Our Price: $176.69
11	001201964	Dowel	4 req	Avail to order Our Price: $96.75
12	008700829	Screw M8x45 Uni 5931/8g/B	4 req	Avail to order Our Price: $6.81
13	001225046	Idle Gear Shim On Pin	2 req	Avail to order Our Price: $36.95
14	008501204	Bearing	3 req	Avail to order Our Price: $7.88
15	001224991	Upper Rh Chain Idle Gear	2 req	Avail to order Our Price: $557.41
16	001228095	Upper Chain Idle Gear Pin	2 req	Avail to order Our Price: $535.21
17	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
18	008100607	Screw M6x18 Uni 5739/5s/Z	4 req	Avail to order Our Price: $6.81
19	008601103	Ring 11 mm Or	2 req	Current Stock: 19 Our Price: $12.35
20	001234659	CHAIN TENSIONER ASSEMBLY NLA	2 req	*See Description
21	008930803	Plug Reference 8	3 req	Avail to order Our Price: $2.00
22	001224810	Upper Chain Tightener Gear	2 req	Avail to order Our Price: $1,318.38
23	001225175	This item is no longer available	2 req
24	07M109675	Valve Guide Rubber Pad	48 req	Current Stock: 51 Our Price: $16.90
25	008573203	O-Ring I 32 Uni 3654	3 req	Avail to order Our Price: $7.00
26	001228571	Intake Valve Guide	24 req	Current Stock: 37 Our Price: $71.47
26	001228791	Exhaust Valve Guide	24 req	Avail to order Our Price: $75.26
27	001220818	Intake Valve	24 req	Avail to order Our Price: $435.45
28	07M109320	Valve Adjustment Shim 3.25 mm	48 req	Current Stock: 51 Our Price: $12.04
28	07M109320A	Valve Adjustment Shim 3.30 mm	48 req	Current Stock: 67 Our Price: $12.04
28	07M109320B	Valve Adjustment Shim 3.35 mm	48 req	Current Stock: 60 Our Price: $59.91
28	07M109320C	Valve Adjustment Shim 3.40 mm	48 req	Current Stock: 55 Our Price: $56.71
28	07M109320D	Valve Adjustment Shim 3.45 mm	48 req	Current Stock: 35 Our Price: $12.04
28	07M109320E	Valve Adjustment Shim 3.50 mm	48 req	Current Stock: 58 Our Price: $59.91
28	07M109320F	Valve Adjustment Shim 3.55	48 req	Current Stock: 3 Our Price: $12.04
28	07M109320G	Valve Adjustment Shim 3.60 mm	48 req	Current Stock: 1 Our Price: $59.91
28	07M109320H	Valve Adjustment Shim 3.65 mm	48 req	Current Stock: 6 Our Price: $62.24
28	07M109320J	Valve Adjustment Shim 3.70	48 req	Current Stock: 6 Our Price: $59.91
28	07M109320K	Valve Adjustment Shim 3.75 mm	48 req	Avail to order Our Price: $59.91
28	07M109320L	Valve Adjustment Shim 3.80 mm	48 req	Current Stock: 56 Our Price: $59.91
28	07M109320M	Valve Adjustment Shim 3.85	48 req	Current Stock: 24 Our Price: $12.04
28	07M109320N	Valve Adjustment Shim 3.90 mm	48 req	Current Stock: 32 Our Price: $59.91
28	07M109320P	Valve Adjustment Shim 3.95 mm	48 req	Current Stock: 29 Our Price: $59.91
28	07M109320Q	Valve Adjustment Shim 4.00 mm	48 req	Current Stock: 43 Our Price: $88.17
28	07M109320R	Valve Adjustment Shim 4.05 mm	48 req	Current Stock: 25 Our Price: $12.04
28	07M109320S	Valve Adjustment Shim 4.10 mm	48 req	Current Stock: 43 Our Price: $59.91
28	07M109320T	Valve Adjustment Shim 4.15 mm	48 req	Current Stock: 40 Our Price: $12.04
28	07M109320AA	Valve Adjustment Shim 4.20 mm	48 req	Current Stock: 59 Our Price: $12.04
28	07M109320AB	Valve Adjustment Shim 4.25 mm	48 req	Current Stock: 83 Our Price: $12.04
28	07M109320AC	Valve Adjustment Shim 4.30 mm	48 req	Current Stock: 50 Our Price: $12.04
28	07M109320AD	Valve Adjustment Shim 4.35 mm	48 req	Current Stock: 70 Our Price: $12.04
28	07M109320AE	Valve Adjustment Shim 4.40 mm	48 req	Current Stock: 73 Our Price: $59.91
28	07M109320AF	Valve Adjustment Shim 4.45 mm	48 req	Current Stock: 58 Our Price: $12.04
28	07M109320AG	Valve Adjustment Shim 4.50 mm	48 req	Current Stock: 62 Our Price: $12.04
28	07M109320AH	Valve Adjustment Shim 4.55 mm	48 req	Current Stock: 69 Our Price: $12.04
28	07M109320AJ	Valve Adjustment Shim 4.60	48 req	Current Stock: 17 Our Price: $12.04
28	07M109320AK	Valve Adjustment Shim 4.65	48 req	Current Stock: 28 Our Price: $12.04
28	002110906	This item is no longer available	48 req
29	07M109309	Valve Bowl	48 req	Avail to order Our Price: $39.42
30	001220843	Valve Seal Cotter OnPlate	96 req	Avail to order Our Price: $8.95
31	07M109641	Spring Upper Washer	48 req	Avail to order Our Price: $20.59
32	07M109633A	Inner Valve Spring	48 req	Avail to order Our Price: $6.70
33	07M109623A	Valve Spring	48 req	Avail to order Our Price: $20.59
34	07M109642	Spring Lower Washer	48 req	Avail to order Our Price: $19.03
35	N90840401	WASHER	2 req	Current Stock: 21 Our Price: $2.00
36	001231370	Upper Tightener Bracket	1 req	Avail to order Our Price: $1,344.83
36	001231727	This item is no longer available	1 req
37	001220822	Intake Valve Seat	24 req	Avail to order Our Price: $71.18
38	008601303	Ring 14 mm Or	2 req	Current Stock: 14 Our Price: $2.00
39	001230845	Upper Chain Tightener Mount Pi	2 req	Avail to order Our Price: $129.61
40	001222483	Intake/Exhaust ValveGuide Stop	48 req	Avail to order Our Price: $35.98
41	008600703	Ring 7x1.50 mm Or	24 req	Avail to order Our Price: $2.00
42	001222476	Exhaust Valve Guide - QV EFI	24 req	Avail to order Our Price: $84.99
42	001220990	SEE PN: 008701031 AND 001237892	2 req	Avail to order Our Price: $40.94
43	001220819	Exhaust Valve	24 req	Avail to order Our Price: $1,595.32
43	001227489	Distributor Gear Fastening Scr	1 req	Avail to order Our Price: $181.16
44	001220823	Exhaust Valve Seat	24 req	Current Stock: 2 Our Price: $19.64
45	001229931	Chain Link	2 req	Avail to order Our Price: $6.22
46	001220990	SEE PN: 008701031 AND 001237892	2 req	Avail to order Our Price: $40.94
47	001227489	Distributor Gear Fastening Scr	1 req	Avail to order Our Price: $181.16
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
