1990 Lamborghini LM002 USA Spec USA Exhaust System (037.00)

Maintenance Parts:

Belts

PN	Item
001726951	PUMP BELT PUMP BELT NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $114.60
001626952	Pump Belt Pump Belt	Avail to order Our Price: $157.30
001609853	Alternator Drive Belt Alternator Drive Belt	Avail to order Our Price: $90.81

Brakes

PN	Item	Diagram
003126137	Brake Pad Front LM002 - SOLD Individually (1 Pad) Pads		Current Stock: 2 Our Price: $23.86

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
002128930	NLA (No Longer Available) Spare Part Lm Clutch Cylinder see pn 002136948	Avail to order Our Price: $193.97
002124587	NLA (No Longer Available) Cp 2789 Thrust Plate	Avail to order Our Price: $3,098.96
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,306.12
002126615	Flywheel/Engine Assembly Flywheel/Engine Assembly	Avail to order Our Price: $5,655.40
002127409	Clutch Plate Clutch Plate	Avail to order Our Price: $1,367.41

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Avail to order Our Price: $31.69
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.29
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.53
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $762.25
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $273.87

Gaskets

PN	Item
001526477	LM002 EURO - Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $1,545.77
001526478	Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $292.81
001526497	NLA (No Longer Available) Engine Gasket Kit see pn 001526477 for seal kit	Avail to order Our Price: $1,472.94
001526498	LM002 USA Engine Gasket Set Engine Gasket Kit see pn 001526478 for seals	Avail to order Our Price: $1,006.24

Ignition

PN	Item
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement	Current Stock: 2 Our Price: $289.00
001628406	Spark Plug Wire Assembly Spark Plug Wire Assembly	Avail to order Our Price: $1,634.94
001630009	Spark Plug - 12mm Spark Plug	Avail to order Our Price: $39.29
001625386	Spark Plug Wires & Bracket Spark Plug Wires & Bracket for LM002	Avail to order Our Price: $1,856.19
0072004164	Key Blank - Door - LM002 Raw Lm Door Key	Current Stock: 13 Our Price: $152.82

Misc

PN	Item
001235193	Chain Tightener Tappet Bracket Chain Tightener Tappet Bracket LM002	Current Stock: 1 Our Price: $481.57
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Avail to order Our Price: $308.18
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $295.00
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.09
002424598	Lm Reversing Switch Lm Reversing Switch	Avail to order Our Price: $117.79
0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	Current Stock: 4 Our Price: $393.04

Open All

Select Group and TAV

< Previous Next >

TAV: 037.00 - Exhaust System

1990 Lamborghini LM002 USA Spec USA Exhaust System (037.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008700441	This item is no longer available	6 req
2	07M253039	Exhaust Manifold Gasket	12 req	Current Stock: 1 Our Price: $42.81
3	N0152785	WASHER	40 req	Current Stock: 71 Our Price: $2.00
4	008100866	Special Screw M8x28	16 req	Avail to order Our Price: $48.68
5	004427720	Exhaust Manifold	1 req	Current Stock: 1 Our Price: $1,371.64
6	004427724	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
7	004427719	Exhaust Manifold	1 req	Avail to order Our Price: $1,371.64
8	008140828	Screw 45x8x1.25 Uni 5739 I	16 req	Avail to order Our Price: $19.61
9	008450806	Stainless Steel Washer 14.4x8.	16 req	Avail to order Our Price: $2.00
10	004425083	Manifold To Front Silencer Att	4 req	Avail to order Our Price: $237.81
11	004424104	Exhaust Pipe Mounting Double T	4 req	Avail to order Our Price: $82.75
12	004425084	EXHAUST CLAMP MANIFOLD TO REAR	4 req	Avail to order Our Price: $503.20
13	004424070	EXHAUST DOUGHNUT MUFFLER	4 req	Avail to order Our Price: $166.75
14	004427118	Side Muffler Connection Pipe	1 req	Avail to order Our Price: $2,422.72
15	004423560	Lh Tailpipe	1 req	Avail to order Our Price: $1,321.33
16	004425040	Mounting Assembly	4 req	Avail to order Our Price: $436.84
17	004427112	Muffler	1 req	Avail to order Our Price: $9,236.18
18	004425002	Silencer & Exhaust Pipe Outlet	2 req	Avail to order Our Price: $7.09
19	004423559	Rh Tailpipe	1 req	Avail to order Our Price: $1,634.94
20	008451005	Washer	4 req	Current Stock: 12 Our Price: $2.00
21	008141022	In H.-H.Screw 10x35 Uni 5737	4 req	Avail to order Our Price: $8.80
22	400251393A	Support	2 req	Current Stock: 6 Our Price: $488.32
23	008200804	Nut	4 req	Current Stock: 7 Our Price: $2.00
24	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	4 req	Current Stock: 5 Our Price: $2.00
25	008100830	Screw M8x20 Uni 5739/8g/Z	8 req	Current Stock: 19 Our Price: $2.00
26	004427117	Side Muffler Connection Pipe	1 req	Avail to order Our Price: $2,422.72
27	004425983	Exhaust Pipe Clamp	2 req	Avail to order Our Price: $98.39
28	004429255	Rh Complete Catalyser	1 req	Avail to order Our Price: $3,250.18
29	N01033520	HEXAGON HEAD BOLT	20 req	Current Stock: 6 Our Price: $2.00
30	004426021	Engine Lifting Hook	4 req	Avail to order Our Price: $107.50
31	004427722	Rear Exhaust Manifold	1 req	Avail to order Our Price: $1,371.64
32	004427721	NLA (No Longer Available)	1 req	*See Description
33	008201031	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	12 req	*See Description
34	004429256	Lh Complete Catalyser	1 req	Avail to order Our Price: $3,250.18
35	004422340	During Seal On Flange	4 req	Avail to order Our Price: $12.01
36	004427723	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
37	004426981	Rear Muffler Pipe	1 req	Avail to order Our Price: $173.70
38	004426980	Rear Muffler Pipe	1 req	Avail to order Our Price: $173.70
39	004427713	Stainless Steel Split Pin	1 req	Avail to order Our Price: $253.42
40	004427715	Stainless Steel Split Pin	1 req	Avail to order Our Price: $253.42
41	004427714	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
42	004427716	Stainless Steel Bracket	1 req	Avail to order Our Price: $9.69
43	004426988	Exhaust Manifold Plug	12 req	Avail to order Our Price: $14.25
44	004429594	CO Inlet Tube	2 req	Avail to order Our Price: $17.77
45	0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	2 req	Current Stock: 4 2 Used Available Our Price: $393.04
46	004428569	Exhaust Pipe Plug	12 req	Avail to order Our Price: $29.06
47	008200807	M8 Ot.58 Uni 2012Self-Locki	16 req	Avail to order Our Price: $26.69
48	008411012	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	12 req	*See Description
49	001625280	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
50	001625281	ELECTRONI CONTROL FOR EXHAUST	2 req	Avail to order Our Price: $527.03
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
