1990 Lamborghini LM002 USA Spec USA Oil Sump (009.00)

Maintenance Parts:

Belts

PN	Item
001726951	PUMP BELT PUMP BELT NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $114.60
001626952	Pump Belt Pump Belt	Avail to order Our Price: $157.30
001609853	Alternator Drive Belt Alternator Drive Belt	Avail to order Our Price: $90.81

Brakes

PN	Item	Diagram
003126137	Brake Pad Front LM002 - SOLD Individually (1 Pad) Pads		Current Stock: 2 Our Price: $23.86

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
002128930	NLA (No Longer Available) Spare Part Lm Clutch Cylinder see pn 002136948	Avail to order Our Price: $193.97
002124587	NLA (No Longer Available) Cp 2789 Thrust Plate	Avail to order Our Price: $3,098.96
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,306.12
002126615	Flywheel/Engine Assembly Flywheel/Engine Assembly	Avail to order Our Price: $5,655.40
002127409	Clutch Plate Clutch Plate	Avail to order Our Price: $1,367.41

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Avail to order Our Price: $31.69
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.29
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.53
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $762.25
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $273.87

Gaskets

PN	Item
001526477	LM002 EURO - Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $1,545.77
001526478	Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $292.81
001526497	NLA (No Longer Available) Engine Gasket Kit see pn 001526477 for seal kit	Avail to order Our Price: $1,472.94
001526498	LM002 USA Engine Gasket Set Engine Gasket Kit see pn 001526478 for seals	Avail to order Our Price: $1,006.24

Ignition

PN	Item
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement	Current Stock: 2 Our Price: $289.00
001628406	Spark Plug Wire Assembly Spark Plug Wire Assembly	Avail to order Our Price: $1,634.94
001630009	Spark Plug - 12mm Spark Plug	Avail to order Our Price: $39.29
001625386	Spark Plug Wires & Bracket Spark Plug Wires & Bracket for LM002	Avail to order Our Price: $1,856.19
0072004164	Key Blank - Door - LM002 Raw Lm Door Key	Current Stock: 13 Our Price: $152.82

Misc

PN	Item
001235193	Chain Tightener Tappet Bracket Chain Tightener Tappet Bracket LM002	Current Stock: 1 Our Price: $481.57
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Avail to order Our Price: $308.18
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $295.00
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.09
002424598	Lm Reversing Switch Lm Reversing Switch	Avail to order Our Price: $117.79
0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	Current Stock: 4 Our Price: $393.04

Open All

Select Group and TAV

< Previous Next >

TAV: 009.00 - Oil Sump

1990 Lamborghini LM002 USA Spec USA Oil Sump (009.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001824269	Oil Priming AssemblyFrom Oil S	1 req	Avail to order Our Price: $225.18
2	N01100845	HEX.NUT	10 req	Current Stock: 17 Our Price: $2.09
3	N0152785	WASHER	10 req	Current Stock: 71 Our Price: $2.00
4	001824129	Primer Pipe Sump Seal	1 req	Current Stock: 5 Our Price: $5.57
5	008300822	Stud M8x18 Uni 5911 8g Z	2 req	Avail to order Our Price: $26.35
6	WHT003165	TAP END STUD	6 req	Current Stock: 3 Our Price: $2.00
7	001803094	Oil Dipstick Pipe Seal	1 req	Current Stock: 11 Our Price: $8.43
8	008410603	Washer D.6.4 Uni 1751/Zd	6 req	Avail to order Our Price: $2.00
9	N01118312	HEX.HEAD CLAMPING NUT	6 req	Avail to order Our Price: $2.17
10	001828408	Oil Dipstick Pipe Set	1 req	Avail to order Our Price: $30.94
11	001828399	Oil Dipstick Assembly	1 req	Avail to order Our Price: $143.28
12	009600701	This item is no longer available	1 req
13	008603503	Or Ring	1 req	Current Stock: 283 Our Price: $4.85
14	001528101	Oil Primer Pipe in Sump	1 req	Avail to order Our Price: $61.73
15	001824129	Primer Pipe Sump Seal	1 req	Current Stock: 5 Our Price: $5.57
16	001528084	Pipe From Primer To Low Pressu	1 req	Avail to order Our Price: $743.96
17	001527808	This item is no longer available	1 req
18	001522506	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
19	008603102	Ring 32 mm Or	1 req	Avail to order Our Price: $6.79
20	008402007	Annealed Copper Washer D.21x27	2 req	Current Stock: 8 Our Price: $2.00
21	001826432	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
22	008100620	Screw M6x12 Uni 5739/5s/Z	10 req	Avail to order Our Price: $6.79
23	008410603	Washer D.6.4 Uni 1751/Zd	10 req	Avail to order Our Price: $2.00
24	001824270	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
25	001824130	Oil Sump & Cover Seal	1 req	Avail to order Our Price: $46.08
26	001824131	Oil Sump Lower Cover	1 req	Avail to order Our Price: $1,136.07
27	008300602	Stud	18 req	Avail to order Our Price: $7.75
28	WHT001197A	WASHER	18 req	Current Stock: 2 Our Price: $2.00
29	N01118312	HEX.HEAD CLAMPING NUT	18 req	Avail to order Our Price: $2.17
30	N01100845	HEX.NUT	18 req	Current Stock: 17 Our Price: $2.09
31	WHT001514	SPRING WASHER	18 req	Current Stock: 9 Our Price: $26.80
32	008300820	Stud M8x25 Uni 5911 8g Zd	18 req	Avail to order Our Price: $2.45
33	008101634	Screw M16x2x110 Uni 5737-6	2 req	Avail to order Our Price: $26.69
34	008401615	Washer 16x34x1	2 req	Avail to order Our Price: $9.14
35	008201609	M16x2 8g/Z Nut	2 req	Avail to order Our Price: $19.61
36	N90630504	HEX. BOLT WITH	8 req	Current Stock: 10 Our Price: $3.43
37	008201010	M10Self Locking Nut	8 req	Avail to order Our Price: $2.00
38	00188559	This item is no longer available	2 req
39	001824365	Pad 786027 S5w	2 req	Avail to order 2 Used Available Our Price: $333.97
40	008300814	Stud M8x18 Uni 5914 8g Zd	8 req	Current Stock: 5 Our Price: $7.68
41	008401819	Annealed Copper Washer 18.5x24	1 req	Current Stock: 22 Our Price: $2.00
42	008931803	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
43	001836995	This item is no longer available	1 req
43	001826994	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
44	008101011	Screw M10x1.5x25 Uni5739/	6 req	Avail to order Our Price: $15.14
45	008411005	Washer D.10.5 Uni 1751/F	6 req	Avail to order Our Price: $2.00
46	008201008	Nut	4 req	Current Stock: 2 Our Price: $2.00
47	001828047	This item is no longer available	1 req
47	001828046	This item is no longer available	1 req
48	001823509	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
49	086301141A	Magnetic Plug 22x1.5	1 req	Avail to order Our Price: $39.91
50	001528093	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
51	008832003	Clamp	4 req	Avail to order Our Price: $51.52
52	001526690	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
53	008835302	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
54	001528094	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
