TAV: 017.00 - Transfer (Output Shaft)

1990 Lamborghini LM002 USA Spec USA Transfer (Output Shaft) (017.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002724933	This item is no longer available	1 req
2	002723246	Dust Boot	1 req	Avail to order Our Price: $198.43
3	002721555	This item is no longer available	1 req
4	008615504	Oil Seal 55x72x8 mm	2 req	Avail to order Our Price: $35.19
5	008514500	Bearing	1 req	Avail to order Our Price: $581.46
6	002721553	Drive Shaft on Secondary	1 req	Avail to order Our Price: $3,302.37
7	008253002	30x1.5x45 Self-Locking Ring Nu	1 req	Avail to order Our Price: $50.55
8	008413001	Washer Skf Mb6	1 req	Current Stock: 10 Our Price: $2.61
9	N01100637	HEX.NUT	6 req	Current Stock: 18 Our Price: $2.00
10	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
11	008300636	Special Stud M6x13	6 req	Avail to order Our Price: $16.40
12	008608601	Ring 85 mm Or	1 req	Avail to order Our Price: $42.05
13	008579004	O-Ring I 115 Uni 3654	1 req	Avail to order Our Price: $26.69
14	008505507	Bearing	1 req	Avail to order Our Price: $505.42
15	008579006	O-Ring I 120 Uni 3654	1 req	Avail to order Our Price: $26.69
16	002721723	Gear Z =20	1 req	Avail to order Our Price: $2,870.00
17	002721729	Spacer	1 req	Avail to order Our Price: $390.62
18	008579003	O-Ring I 100 Uni 3654	1 req	Avail to order Our Price: $21.40
19	008525504	Bearing	1 req	Avail to order Our Price: $1,597.78
20	008255502	55x2 Special Ring Nut	1 req	Avail to order Our Price: $111.97
21	008575501	O-Ring I 55 Uni 3654	1 req	Current Stock: 9 Our Price: $2.00
22	008503010	Bearing	1 req	Avail to order Our Price: $25.43
23	002723245	Wheel Drive Shaft	1 req	Avail to order Our Price: $3,846.54
24	002721746	Sleeve	1 req	Avail to order Our Price: $2,870.00
25	008524004	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
26	008507501	Bearing	1 req	Avail to order Our Price: $618.73
27	002721554	ZF Differential & Secondary Sh	1 req	Avail to order Our Price: $14,200.89
28	002721549	Drive Shaft on Secondary	1 req	Avail to order Our Price: $1,296.07
29	008609101	Ring 92 mm Or	1 req	Avail to order Our Price: $2.00
30	002721548	This item is no longer available	1 req
31	008514000	Bearing	1 req	Avail to order Our Price: $497.97
32	N0123501	RETAINER RING	1 req	Current Stock: 7 Our Price: $8.04
33	008615503	Oil Seal 55x80x8 mm	2 req	Avail to order Our Price: $18.56
34	002721730	Cover	1 req	Avail to order Our Price: $248.96
35	008614901	Oil Seal	1 req	Avail to order Our Price: $11.71
36	008101056	Special Screw M10x31	8 req	Avail to order Our Price: $2.91
37	002721550	Drive Shaft Flange	1 req	Avail to order Our Price: $1,813.30
38	002721744	Ring Nut Secondary Washer	1 req	Avail to order Our Price: $65.55
39	008253003	30x1.5 Shaft Fixing Ring Nut	1 req	Avail to order Our Price: $172.95
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
