1990 Lamborghini LM002 USA Spec USA Rear Suspension (034.00)

Maintenance Parts:

Belts

PN	Item
001726951	PUMP BELT PUMP BELT NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $114.60
001626952	Pump Belt Pump Belt	Avail to order Our Price: $157.30
001609853	Alternator Drive Belt Alternator Drive Belt	Avail to order Our Price: $90.81

Brakes

PN	Item	Diagram
003126137	Brake Pad Front LM002 - SOLD Individually (1 Pad) Pads		Current Stock: 2 Our Price: $23.86

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
002128930	NLA (No Longer Available) Spare Part Lm Clutch Cylinder see pn 002136948	Avail to order Our Price: $193.97
002124587	NLA (No Longer Available) Cp 2789 Thrust Plate	Avail to order Our Price: $3,098.96
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,306.12
002126615	Flywheel/Engine Assembly Flywheel/Engine Assembly	Avail to order Our Price: $5,655.40
002127409	Clutch Plate Clutch Plate	Avail to order Our Price: $1,367.41

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Avail to order Our Price: $31.69
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.29
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.53
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $762.25
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $273.87

Gaskets

PN	Item
001526477	LM002 EURO - Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $1,545.77
001526478	Grommet & Oil Seals Set Grommet & Oil Seals Set	Avail to order Our Price: $292.81
001526497	NLA (No Longer Available) Engine Gasket Kit see pn 001526477 for seal kit	Avail to order Our Price: $1,472.94
001526498	LM002 USA Engine Gasket Set Engine Gasket Kit see pn 001526478 for seals	Avail to order Our Price: $1,006.24

Ignition

PN	Item
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement	Current Stock: 2 Our Price: $289.00
001628406	Spark Plug Wire Assembly Spark Plug Wire Assembly	Avail to order Our Price: $1,634.94
001630009	Spark Plug - 12mm Spark Plug	Avail to order Our Price: $39.29
001625386	Spark Plug Wires & Bracket Spark Plug Wires & Bracket for LM002	Avail to order Our Price: $1,856.19
0072004164	Key Blank - Door - LM002 Raw Lm Door Key	Current Stock: 13 Our Price: $152.82

Misc

PN	Item
001235193	Chain Tightener Tappet Bracket Chain Tightener Tappet Bracket LM002	Current Stock: 1 Our Price: $481.57
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Avail to order Our Price: $308.18
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $295.00
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.09
002424598	Lm Reversing Switch Lm Reversing Switch	Avail to order Our Price: $117.79
0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	Current Stock: 4 Our Price: $393.04

Open All

Select Group and TAV

< Previous Next >

TAV: 034.00 - Rear Suspension

1990 Lamborghini LM002 USA Spec USA Rear Suspension (034.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a LM002 Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N01100845	HEX.NUT	4 req	Current Stock: 17 Our Price: $2.09
2	005223843	This item is no longer available	2 req
3	005221916	Suspension Arm End Run Pad	2 req	Avail to order Our Price: $493.49
4	008202008	20x17.5 8g/Zp Nut	8 req	Avail to order Our Price: $14.02
5	005121458	Suspension Arm Bushing	12 req	Avail to order Our Price: $427.89
6	008102001	Special Screw M20x1.5x91	8 req	Avail to order Our Price: $29.01
7	005222302	Rear Suspension Upper Arm	2 req	Avail to order Our Price: $2,079.82
8	008101706	Special Screw M16x214	2 req	Avail to order Our Price: $146.71
9	005221450	Outer Side Hub Holder Blades	12 req	Avail to order Our Price: $16.55
10	008401619	Upper Arm to Hub Fastening Was	4 req	Avail to order Our Price: $21.69
11	005109529	Joint	4 req	Avail to order Our Price: $178.17
12	008221449	This item is no longer available	12 req
13	008401715	Upper Arm Washer	4 req	Avail to order Our Price: $68.53
14	008201608	M16x1.5x15 5s/Z Nut	2 req	Avail to order Our Price: $17.89
15	005223461	Cover	2 req	Avail to order Our Price: $28.25
16	008203502	M35x1.5 Special Nut	2 req	Avail to order Our Price: $92.01
17	008403602	Hub Nut Washer	2 req	Avail to order Our Price: $29.60
18	005221455	Brake Drum & Wheel Rim Hub	2 req	Avail to order Our Price: $846.84
19	008619006	Oil Seal 90x110x12 mm	4 req	Avail to order Our Price: $23.78
20	008619005	Oil Seal 90x110x12 mm	4 req	Avail to order Our Price: $25.35
21	005221437	Hub Holder	2 req	Avail to order Our Price: $1,580.36
22	008507502	Bearing	4 req	Avail to order Our Price: $247.50
23	008609910	Or 2500	2 req	Avail to order Our Price: $6.87
24	005221438	Laminum Otto Adjustable Shim	0 req	Avail to order Our Price: $164.01
25	005221441	Hub Carrier Cover	2 req	Avail to order Our Price: $450.26
26	005221885	Rear Drive Axle Hub	2 req	Avail to order Our Price: $742.48
27	008700617	Screw M6x18 Uni 5931/8g/Z	16 req	Current Stock: 3 Our Price: $2.00
29	005222397	Rear Suspension Lower Arm	2 req	Avail to order Our Price: $2,079.82
30	008880601	Hydraulic 273 A Grease Dispens	8 req	Current Stock: 8 Our Price: $2.00
31	008102002	Special Screw M20x1.5x300	2 req	Avail to order Our Price: $294.46
32	008402012	This item is no longer available	4 req
33	005126522	Suspension Lower Control Arm A	4 req	Avail to order Our Price: $92.74
34	005121626	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	0 req	*See Description
35	005121627	Front Suspension Lower Arm Shi	0 req	Avail to order Our Price: $41.38
36	WHT003355	clamping nut	16 req	Current Stock: 13 Our Price: $23.53
37	008102005	Screw 20x1.5x84 Special	4 req	Avail to order Our Price: $28.71
38	005224414	Washer	16 req	Avail to order Our Price: $27.29
39	005225884	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
40	005225882	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
41	005225879	This item is no longer available	4 req
42	008202008	20x17.5 8g/Zp Nut	8 req	Avail to order Our Price: $14.02
43	005207451	Shock Absorber Spring Bracket	8 req	Avail to order Our Price: $65.98
44	005223405	Rear Shock Absorber Springs	4 req	Avail to order Our Price: $645.57
45	005228615	This item is no longer available	4 req
46	005228616	This item is no longer available	16 req
47	005225880	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
48	005225883	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
49	005225885	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
50	005225882	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
51	008202408	24x2x21 8g/Zp Nut	4 req	Avail to order Our Price: $36.76
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
