1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $89.23

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $93.28
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $61.66
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,673.17
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $8,315.78
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $733.84

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $306.83

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $40.26

Gaskets

PN	Item
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $266.12
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $365.29
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,898.69
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $3,212.52
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $330.08

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,507.76
001609591	URRACO ROTOR ARM URRACO ROTOR ARM MAGNETTI MARELLI	Avail to order Our Price: $259.00
001609592	URRACO DISTRIBUTOR CAP URRACO DISTRIBUTOR CAP	Avail to order Our Price: $352.11
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,653.00
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,673.17

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $161.79
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $123.23
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 9 - Basamento

1972-1977 Lamborghini Urraco USA Basamento (9)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008300822	STUD	3 req	Avail to order Our Price: $26.04
2	001807864	OIL FLOW LIMITER RING	1 req	Avail to order Our Price: $7.08
3	001805853	CRANKCASE CENTRAL COVER	1 req	Avail to order Our Price: $1,650.32
4	008100849	SCREW M8X18 8G	1 req	Avail to order Our Price: $7.97
5	008300808	STUD M8X35 UNI 5911 8G Z	2 req	Avail to order Our Price: $6.50
6	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.48
7	N01100845	HEX.NUT	2 req	Current Stock: 17 Our Price: $2.04
8	008606205	O-RING	2 req	Current Stock: 6 Our Price: $4.47
9	001806762	COOLANT PUMP SHAFT JOURNAL	1 req	Avail to order Our Price: $328.60
10	001106146	HEAD COOLANT OUTLET TUBE	1 req	Avail to order Our Price: $8.78
11	WHT000768	SPRING WASHER	2 req	Current Stock: 16 Our Price: $2.04
12	N10155210	HEX.NUT	2 req	Current Stock: 38 Our Price: $2.12
13	008301006	STUD	2 req	Avail to order Our Price: $12.31
14	008200805	M8X1X8 8G/B NUT	10 req	Avail to order Our Price: $0.20
15	WHT001514	SPRING WASHER	10 req	Current Stock: 9 Our Price: $26.48
16	008300810	STUD M8X1X80 UNI 5916 10K	10 req	Avail to order Our Price: $13.66
17	008201201	M12X1.25 UNI 5587 8G NUT	10 req	Avail to order Our Price: $6.18
18	WHT003055	WASHER 13X24X1.2 DIN137/B C72	10 req	Current Stock: 10 Our Price: $0.70
19	008301208	SPECIAL STUD E M12X18	10 req	Avail to order Our Price: $16.11
20	008851101	BUSHING 8.5X11X14 MM	4 req	Avail to order Our Price: $44.68
21	001808611	CRANKSHAFT FRONT COVER SEAL	1 req	Avail to order Our Price: $32.22
22	001808610	CRANKSHAFT COVER	1 req	Avail to order Our Price: $157.26
23	WHT001197A	WASHER	8 req	Current Stock: 22 Our Price: $0.30
24	008100617	SCREW M6X18 UNI 57395S	8 req	Avail to order Our Price: $6.10
25	008615006	OIL SEAL	1 req	Current Stock: 2 Our Price: $4.55
26	001806009	OIL PRESSURE TRANSMISSION REDU	1 req	Avail to order Our Price: $28.06
27	001508565	OIL PRESSURE TRANSMITTER	1 req	Avail to order Our Price: $370.90
28	008801204	BUSHING 7X16X18 MM	2 req	Current Stock: 1 Our Price: $9.84
29	001812090	CRANKCASE CENTRAL COVER GASKET	1 req	Avail to order Our Price: $57.69
30	WHT003078	REFERENCE PIN 8H7X16C40	6 req	Avail to order Our Price: $46.49
31	008300831	STUD M8X20 UNI 5911 8G ZD	6 req	Avail to order Our Price: $14.80
32	WHT001514	SPRING WASHER	6 req	Current Stock: 9 Our Price: $26.48
33	008200806	NUT	6 req	Current Stock: 25 Our Price: $0.40
34	001808605	CRANKCASE UPPER	1 req	Avail to order Our Price: $22,757.76
35	001701906	TAP WASHER	2 req	Avail to order Our Price: $0.20
36	001701905	RADIATOR TAP	2 req	Avail to order Our Price: $124.95
37	001810802	CYLINDER LINER	8 req	Avail to order Our Price: $871.61
38	001808608	CRANKSHAFT JOURNAL	1 req	Avail to order Our Price: $4,676.76
39	001807429	OIL BREATHER PIPE SEAL	1 req	Current Stock: 1 Our Price: $5.37
40	001808613	URRACO OIL BREATHER	1 req	Avail to order Our Price: $2,210.69
41	N10155210	HEX.NUT	1 req	Current Stock: 38 Our Price: $2.12
42	WHT000768	SPRING WASHER	2 req	Current Stock: 16 Our Price: $2.04
43	WHT000768	SPRING WASHER	2 req	Current Stock: 16 Our Price: $2.04
44	008301008	STUD M10X90 UNI 59118GZ	2 req	Avail to order Our Price: $11.14
45	N10155210	HEX.NUT	2 req	Current Stock: 38 Our Price: $2.12
46	WHT000768	SPRING WASHER	2 req	Current Stock: 16 Our Price: $2.04
47	008301002	STUD M10X75 UNI 59118GZ	2 req	Avail to order Our Price: $34.73
48	008301210	STUD 12X1.25X128 10K	10 req	Avail to order Our Price: $18.14
49	008200806	NUT	4 req	Current Stock: 25 Our Price: $0.40
50	WHT001514	SPRING WASHER	4 req	Current Stock: 9 Our Price: $26.48
51	008300806	STUD M8X70 UNI 5911 9G Z	2 req	Avail to order Our Price: $5.85
52	008932201	PLUG D.22 MB CH 27 C40	1 req	Avail to order Our Price: $18.14
53	008602002	RING 21 MM OR	1 req	Current Stock: 8 Our Price: $27.36
54	001808618	OIL BREATHER BULKHEAD	1 req	Avail to order Our Price: $128.68
55	WHT003165	TAP END STUD	4 req	Current Stock: 3 Our Price: $1.80
56	WHT001197A	WASHER	4 req	Current Stock: 22 Our Price: $0.30
57	N01118312	HEX.HEAD CLAMPING NUT	4 req	Avail to order Our Price: $2.12
58	008300836	STUD 8X1.25X30 8G	2 req	Avail to order Our Price: $3.74
59	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.48
60	N01100845	HEX.NUT	2 req	Current Stock: 17 Our Price: $2.04
61	008301209	STUD 12X1.25X120 10K	10 req	Avail to order Our Price: $117.97
62	WHT003055	WASHER 13X24X1.2 DIN137/B C72	20 req	Current Stock: 10 Our Price: $0.70
63	008201202	M12X1.25NUT	20 req	Avail to order Our Price: $8.29
64	008300605	STUD M6X80 UNI 5914 8G/ZD	4 req	Avail to order Our Price: $12.43
65	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $0.40
66	WHT001197A	WASHER	4 req	Current Stock: 22 Our Price: $0.30
67	N01020717	HEXAGON HEAD BOLT	8 req	Current Stock: 4 Our Price: $0.80
68	008410502	WASHER	8 req	Current Stock: 33 Our Price: $0.10
69	001808612	OIL SUMP BULKHEAD	1 req	Avail to order Our Price: $136.43
70	001810274	This item is no longer available	1 req
71	086301141A	MAGNETIC PLUG	1 req	Avail to order Our Price: $39.50
72	001501333	This item is no longer available	1 req
73	008100603	SCREW M6X25 UNI 5739-8G ZG	13 req	Avail to order Our Price: $1.70
74	WHT001197A	WASHER	13 req	Current Stock: 22 Our Price: $0.30
75	008100816	SCREW M8X110 UNI 5737 8G	1 req	Avail to order Our Price: $6.18
76	WHT002944	TAP END STUD	1 req	Avail to order Our Price: $17.71
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
