1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $89.23

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $93.28
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,673.17
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $61.66
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $8,315.78
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $733.84

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $306.83

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $40.26

Gaskets

PN	Item
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,898.69
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $3,212.52
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $365.29
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $266.12
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $330.08

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,507.76
001609592	URRACO DISTRIBUTOR CAP URRACO DISTRIBUTOR CAP	Avail to order Our Price: $352.11
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,673.17
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,653.00
001609591	URRACO ROTOR ARM URRACO ROTOR ARM MAGNETTI MARELLI	Avail to order Our Price: $259.00

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $123.23
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $161.79
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 16 - Freni Anteriori

1972-1977 Lamborghini Urraco USA Freni Anteriori (16)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003107781	This item is no longer available	1 req
2	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.12
3	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $0.30
4	003208693	HYDRAULIC BRAKE LIGHT SWITCH	1 req	Current Stock: 2 Our Price: $130.41
5	003208682	UNION	2 req	Current Stock: 1 Our Price: $57.83
6	003108678	This item is no longer available	1 req
7	008201014	M10X1X6 UNI 5589/5S/Z NUT	2 req	Current Stock: 1 Our Price: $6.42
8	003208683	HOSE	2 req	Avail to order Our Price: $108.31
9	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.12
10	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $0.30
11	003108672	BRAKE THREE-WAY UNION	2 req	Avail to order Our Price: $67.93
12	003108673	PIPE	1 req	Avail to order Our Price: $65.15
13	003108674	RH SHOE PIPE/THREE-WAY	1 req	Avail to order Our Price: $21.23
14	003108701	HOLE LOCK PLUG	1 req	Avail to order Our Price: $14.88
15	003108685	CYLINDER PIPE/SAFETYDEVICE.	1 req	Avail to order Our Price: $65.15
16	003208695	CYLINDER PIPE/SAFETYDEVICE	1 req	Avail to order Our Price: $65.15
17	N01118312	HEX.HEAD CLAMPING NUT	1 req	Avail to order Our Price: $2.12
18	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
19	003107709	NLA (NO LONGER AVAILABLE)	1 req	*See Description
20	003108679	SAFETY DEVICE PIPE/FRONT THREE	1 req	Avail to order Our Price: $65.15
21	003108677	LH FRONT BRAKE PIPE	1 req	Avail to order Our Price: $65.15
22	003208694	SAFETY DEVICE PIPE/REAR THREE-	1 req	Avail to order Our Price: $65.15
23	003208692	This item is no longer available	1 req
24	008100826	SCREW M8X16 UNI 5739/8G/Z	4 req	Avail to order Our Price: $0.50
25	003106919	VENTILATED FRONT/REAR BRAKE DI	2 req	Avail to order Our Price: $1,882.62
26	003108676	LH SHOE PIPE/THREE-WAY	1 req	Avail to order Our Price: $21.23
27	003108675	PIPE	1 req	Avail to order Our Price: $65.15
28	008401305	WASHER 13X22X* C 72	0 req	Avail to order Our Price: $32.05
29	008411303	SNAP RING 21X13X2.5 UNI 175 1	4 req	Current Stock: 6 Our Price: $2.93
30	008101223	SPECIAL SCREW M12X37	4 req	Current Stock: 2 Our Price: $13.66
31	003106921	LH FRONT SHOE	1 req	Avail to order Our Price: $821.13
32	003106920	NLA (NO LONGER AVAILABLE)	1 req	*See Description
33	003111053	FERODO PAD	4 req	Avail to order Our Price: $99.17
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
