1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $89.23

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $93.28
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $61.66
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,673.17
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $8,315.78
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $733.84

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $306.83

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $40.26

Gaskets

PN	Item
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $266.12
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $365.29
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,898.69
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $3,212.52
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $330.08

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,507.76
001609591	URRACO ROTOR ARM URRACO ROTOR ARM MAGNETTI MARELLI	Avail to order Our Price: $259.00
001609592	URRACO DISTRIBUTOR CAP URRACO DISTRIBUTOR CAP	Avail to order Our Price: $352.11
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,653.00
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,673.17

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $161.79
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $123.23
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 14 - Cambio(fusion)

1972-1977 Lamborghini Urraco USA Cambio(fusion) (14)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002305118	DIFFERENTIAL BREATHER PIPE	1 req	Avail to order Our Price: $14.56
2	002302182	DIFFERENTIAL OIL BREATHER PIPE	1 req	Avail to order Our Price: $274.02
3	004108896	ENGINE-GEARBOX MOUNTADAPTER	3 req	Avail to order Our Price: $63.04
4	002409589	This item is no longer available	1 req
5	008100839	SCREW M8X10 UNI 5739/8G Z	4 req	Current Stock: 17 Our Price: $0.60
6	002407502	CLUTCH HOLE GUARD COVER	1 req	Avail to order Our Price: $12.61
7	008605601	OR RING	1 req	Avail to order Our Price: $54.91
8	008300604	STUD M6X13 UNI 5914/8G/ZD	3 req	Avail to order Our Price: $20.34
9	008410603	WASHER D.6.4 UNI 1751/ZD	3 req	Avail to order Our Price: $0.10
10	N01100637	HEX.NUT	3 req	Current Stock: 18 Our Price: $0.40
11	008613001	OIL SEAL	1 req	Avail to order Our Price: $16.11
12	002406364	THRUST SLEEVE BRACKET	1 req	Avail to order Our Price: $322.58
13	002407496	GASKET	1 req	Current Stock: 4 Our Price: $26.12
14	002407495	GEARBOX FRONT COVER	1 req	Avail to order Our Price: $23.26
15	008410605	CORRUGATED WASHER D 6	4 req	Avail to order Our Price: $2.60
16	008700603	SCREW M6X20 UNI 593312K/Z	4 req	Avail to order Our Price: $2.60
17	002406672	GEAR SELECTOR LEVER BRACKET	1 req	Avail to order Our Price: $37.74
18	WHT001197A	WASHER	5 req	Current Stock: 22 Our Price: $0.30
19	008100617	SCREW M6X18 UNI 57395S	5 req	Avail to order Our Price: $6.10
20	008604202	RING 43 MM OR	1 req	Current Stock: 3 Our Price: $12.85
21	01S409965	PLUG	1 req	Current Stock: 5 Our Price: $186.33
22	008611706	LIP SEAL	1 req	Avail to order Our Price: $10.62
23	002406654	GEAR ROD BRACKET	1 req	Avail to order Our Price: $79.71
24	008605001	OR RING	1 req	Current Stock: 104 Our Price: $1.50
25	008100822	SCREW M8X60 UNI 57378G/ZD	10 req	Avail to order Our Price: $6.18
26	008401414	COPPER WASHER 14X24X0,04513888	1 req	Current Stock: 27 Our Price: $2.77
27	008931201	PLUG D.12X1.25X9 OIL5S	1 req	Avail to order Our Price: $37.91
28	WHT003362	COPPER WASHER	1 req	Avail to order Our Price: $1.60
29	002408619	DIFFERENTIAL COVER SEAL	1 req	Avail to order Our Price: $42.67
30	002408620	DIFFERENTIAL COVER	1 req	Avail to order Our Price: $153.84
31	002406535	REAR GEARBOX	12 req	Avail to order Our Price: $333.97
32	008200806	NUT	12 req	Current Stock: 25 Our Price: $0.40
33	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.48
34	008851101	BUSHING 8.5X11X14 MM	9 req	Avail to order Our Price: $44.68
35	008200605	SIMMON NUT FOR URAMA	9 req	Current Stock: 50 Our Price: $3.25
36	WHT003041	SOFT COPPER WASHER 6.4X12X1.5	9 req	Current Stock: 14 Our Price: $1.10
37	N01100637	HEX.NUT	12 req	Current Stock: 18 Our Price: $0.40
38	WHT001197A	WASHER	9 req	Current Stock: 22 Our Price: $0.30
39	008300620	SPECIAL STUD M6X46	1 req	Avail to order Our Price: $1.50
40	002407515	GEARBOX REAR COVER SEAL	1 req	Avail to order Our Price: $21.47
41	002406502	FLANGE	1 req	Avail to order Our Price: $89.65
42	008850610	REFERENCE PIN 6H6X19.5 C40	2 req	Avail to order Our Price: $7.97
43	008850504	REFERENCE PIN 5H6X8.5 C 40	5 req	Avail to order Our Price: $19.28
44	WHT003165	TAP END STUD	2 req	Current Stock: 3 Our Price: $1.80
45	086301141A	MAGNETIC PLUG	2 req	Avail to order Our Price: $39.50
46	002408636	GEARBOX OIL FILTER UNION	1 req	Avail to order Our Price: $27.33
47	008401408	ANNEALED COPPER WASHER 21X14X1	2 req	Current Stock: 41 Our Price: $1.10
48	WHT001197A	WASHER	11 req	Current Stock: 22 Our Price: $0.30
49	008100603	SCREW M6X25 UNI 5739-8G ZG	11 req	Avail to order Our Price: $1.70
50	008930901	TAPER GAS PLUG 1/8	1 req	Avail to order Our Price: $10.73
51	008100603	SCREW M6X25 UNI 5739-8G ZG	3 req	Avail to order Our Price: $1.70
52	002408621	COVER & OIL PUMP	1 req	Avail to order Our Price: $264.73
53	008700606	SCREW	1 req	Current Stock: 37 Our Price: $0.80
54	008100839	SCREW M8X10 UNI 5739/8G Z	1 req	Current Stock: 17 Our Price: $0.60
55	008400802	COPPER WASHER 8.4X16X1.5	1 req	Avail to order Our Price: $1.90
56	002407480	GEARBOX LOWER COVER SEAL	1 req	Current Stock: 7 Our Price: $3.49
57	002407479	GEARBOX LOWER COVER	1 req	Avail to order Our Price: $38.72
58	WHT001197A	WASHER	5 req	Current Stock: 22 Our Price: $0.30
59	N01100637	HEX.NUT	5 req	Current Stock: 18 Our Price: $0.40
60	002408627	GEARBOX OIL INLET UNION PIPE	1 req	Avail to order Our Price: $16.02
61	002408634	NLA (NO LONGER AVAILABLE)	1 req	*See Description
62	008300808	STUD M8X35 UNI 5911 8G Z	2 req	Avail to order Our Price: $6.50
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
