1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $98.99

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $86.47
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $68.46
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,856.21
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $7,713.90
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $680.71

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $284.62

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $44.63

Gaskets

PN	Item
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $295.22
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $338.90
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,761.30
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $2,980.03
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $306.23

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,398.65
001609592	DISTRIBUTOR CAP CAP	Avail to order Our Price: $390.61
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,833.85
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,856.21

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 3A - Carburatori

1972-1977 Lamborghini Urraco USA Carburatori (3A)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001310512	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
2	001307613	CARBURETTOR HORN SEAL	8 req	Current Stock: 8 Our Price: $6.79
3	WHT001197A	WASHER	16 req	Current Stock: 2 Our Price: $0.30
4	N01100637	HEX.NUT	16 req	Current Stock: 18 Our Price: $0.40
5	001310511	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
6	001310170	CARBURETTOR/AIR CLEANER SEAL	4 req	Avail to order Our Price: $11.25
7	001310158	FRONT LH CARBURETTOR	1 req	Avail to order Our Price: $769.90
8	001108513	HEAD VACUUM THREE-WAY CONNECTO	1 req	Avail to order Our Price: $22.07
9	008830901	NLA (NO LONGER AVAILABLE)	4 req	*See Description
10	001308550	THREE-WAY VALVE RECIRCULATION	1 req	Avail to order Our Price: $15.85
11	001308549	HEAD UNION RECIRCULATION PIPE	1 req	Avail to order Our Price: $23.53
12	001106146	HEAD COOLANT OUTLET TUBE	2 req	Avail to order Our Price: $9.82
13	001306143	CARBURETTOR CONTROL CENTRING P	1 req	Avail to order Our Price: $17.11
14	001306153	ACCELERATOR RETURN SPRING	1 req	Avail to order Our Price: $27.72
15	008401007	WASHER 21.5X10.4X2 UNI 6592/5S	2 req	Avail to order Our Price: $0.10
16	001307610	This item is no longer available	8 req
17	001310159	REAR LH CARBURETTOR	1 req	Avail to order Our Price: $769.90
18	001310169	OIL VAPOUR VALVE	1 req	Avail to order Our Price: $74.68
19	001308547	This item is no longer available	1 req
20	008403003	WASHER 30X38X1 C 72	1 req	Avail to order Our Price: $6.90
21	008582701	O-RING E 30 UNI 7435-75	1 req	Current Stock: 9 Our Price: $2.33
22	008300808	STUD M8X35 UNI 5911 8G Z	16 req	Avail to order Our Price: $6.01
23	WHT001514	SPRING WASHER	16 req	Current Stock: 9 Our Price: $26.80
24	008200806	M8 UNI 5588/8G/Z NUT	16 req	Current Stock: 25 Our Price: $0.40
25	001310518	THREE-WAY FUEL PIPE	1 req	Avail to order Our Price: $46.87
26	400721214E	BALL JOINT HEAD (LEFT HAND THREAD)	3 req	Avail to order Our Price: $68.16
27	001308541	CARBURETTOR CENTRAL TIEROD	1 req	Avail to order Our Price: $35.01
28	001300804	HEAD UNIT	3 req	Avail to order Our Price: $13.71
29	001310160	FRONT RH CARBURETTOR	1 req	Avail to order Our Price: $769.90
30	004208718	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
31	001302645	CARBURETTOR PIPE LH UNION	1 req	Avail to order Our Price: $41.04
32	001308542	CARBURETTOR TIEROD CONTROL SHA	1 req	Avail to order Our Price: $12.64
33	008401217	WASHER12 ALLEN SCREW5S	1 req	Current Stock: 3 Our Price: $6.81
34	008581101	O-RING E 12 UNI 7435-75	1 req	Avail to order Our Price: $6.81
35	001305797	MANIFOLD CARBURETTORSEAL	16 req	Current Stock: 16 Our Price: $11.96
36	001305798	CARBURETTOR/MANIFOLDSHIM	8 req	Avail to order Our Price: $64.18
37	008100618	SCREW M6X20 UNI 5739/8G/ZD	2 req	Current Stock: 44 Our Price: $0.30
38	008410603	WASHER D.6.4 UNI 1751/ZD	2 req	Avail to order Our Price: $0.10
39	001308543	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
40	001300803	LEVER BALL JOINT	4 req	Current Stock: 5 Our Price: $38.51
41	001309418	CARBURETTOR CONTROL LEVER SHIM	1 req	Avail to order Our Price: $12.64
42	001310510	This item is no longer available	1 req
43	001310161	REAR RH CARBURETTOR	1 req	Avail to order Our Price: $769.90
44	001308538	CARBURETTOR CONTROL CENTRAL LE	1 req	Avail to order Our Price: $109.01
45	008801003	BUSHING 16X16 MM	1 req	Avail to order Our Price: $23.82
46	008200504	M5 LH. SPECIAL NUT	3 req	Avail to order Our Price: $18.57
47	001310171	CARBURETTOR TIEROD	2 req	Avail to order Our Price: $25.96
48	N10689901	HEX.NUT	3 req	Current Stock: 5 Our Price: $0.10
49	001310517	This item is no longer available	1 req
50	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $0.40
51	008100625	SCREW M6X16 UNI 5739/8G/Z	2 req	Avail to order Our Price: $140.03
52	004208719	HANDBRAKE PROTECTIONPIPE BUSHI	1 req	Avail to order Our Price: $304.94
53	004208716	THROTTLE BOWDEN WIRE	1 req	Avail to order Our Price: $36.74
54	004208933	CARBURETTOR CONTROL FORK PIN	1 req	Avail to order Our Price: $19.64
55	004208720	ACCELERATOR WIRE FORK	1 req	Avail to order Our Price: $44.83
56	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
57	008200101	This item is no longer available	1 req
58	001308544	CARBURETTOR DRIVING SHAFT LEVE	1 req	Avail to order Our Price: $62.82
59	008100503	SCREW M5X8 UNI 5739/8G	1 req	Avail to order Our Price: $0.10
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
