1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $91.93

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $27.99

Drivetrain

PN	Item
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $63.54
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,673.17
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $756.32
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $8,315.78
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 19 Our Price: $96.15

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $316.50

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $41.48

Gaskets

PN	Item
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $376.58
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $3,212.52
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,898.69
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $340.51
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $274.17

Ignition

PN	Item
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,673.17
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,653.00
001609592	URRACO DISTRIBUTOR CAP URRACO DISTRIBUTOR CAP	Avail to order Our Price: $362.85
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,507.76
001609591	URRACO ROTOR ARM URRACO ROTOR ARM MAGNETTI MARELLI	Avail to order Our Price: $251.01

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
001719309	COOLANT THERMOSTAT COOLANT THERMOSTAT FITS THE FOLLOWING: COUNTACH 5000 S, LP400 ESPADA JALPA 3.5 URRACO P30		Avail to order Our Price: $395.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $167.43

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 89 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 1 - Teste cilinder

1972-1977 Lamborghini Urraco USA Teste cilinder (1)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008700601	SCREW M6X30 UNI 59318G/Z	4 req	Avail to order Our Price: $6.34
2	WHT001197A	WASHER	8 req	Current Stock: 22 Our Price: $0.40
3	008700609	SCREW 6X45 UNI 5931/8G/ZD	4 req	Avail to order Our Price: $0.60
4	001105771	LH CAMSHAFT UPPER COVER	1 req	Avail to order Our Price: $329.25
5	001108505	CAMSHAFT SHIM COVER GASKET	2 req	Avail to order Our Price: $8.80
6	001108504	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
7	WHT001197A	WASHER	6 req	Current Stock: 22 Our Price: $0.40
8	008100617	SCREW M6X18 UNI 57395S	6 req	Avail to order Our Price: $6.34
9	001108513	HEAD VACUUM THREE-WAY CONNECTO	2 req	Avail to order Our Price: $20.49
10	001105812	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
11	008602301	RING 24 MM OR	4 req	Current Stock: 2 Our Price: $1.87
12	008700604	SCREW 6X1X10 12K	4 req	Avail to order Our Price: $8.21
13	001106132	HEAD COOLANT CLOSINGFLANGE	2 req	Avail to order Our Price: $24.08
14	001108502	RH CAMSHAFT COVER	1 req	Avail to order Our Price: $365.53
15	008602801	RING 28 MM OR	1 req	Avail to order Our Price: $4.21
16	001108512	OIL FILLER PLUG	1 req	Avail to order Our Price: $69.63
17	001105772	CAM COVER SEAL	2 req	Avail to order Our Price: $95.43
18	001105773	CAMSHAFT JOURNALS	2 req	Avail to order Our Price: $1,612.64
19	001107099	CAM HOLE LOCK PLUG	10 req	Avail to order Our Price: $91.18
20	WHT003028	TAP END STUD	8 req	Avail to order Our Price: $24.68
21	WHT001514	SPRING WASHER	16 req	Current Stock: 9 Our Price: $27.37
22	008200806	NUT	16 req	Current Stock: 25 Our Price: $0.40
23	001108506	This item is no longer available	2 req
24	008613202	OIL SEAL	4 req	Current Stock: 5 Our Price: $13.68
25	WHT003078	REFERENCE PIN 8H7X16C40	2 req	Avail to order Our Price: $47.91
26	001107679	NLA (NO LONGER AVAILABLE)	1 req	*See Description
27	001106146	HEAD COOLANT OUTLET TUBE	2 req	Avail to order Our Price: $9.11
28	008300840	STUD M8X32 UNI 5911 8G Z	8 req	Avail to order Our Price: $3.66
29	WHT001514	SPRING WASHER	8 req	Current Stock: 9 Our Price: $27.37
30	008200811	M8 UNI 5589/8G/ZDNUT	8 req	Avail to order Our Price: $6.34
31	008851101	BUSHING 8.5X11X14 MM	2 req	Avail to order Our Price: $46.02
32	008100617	SCREW M6X18 UNI 57395S	4 req	Avail to order Our Price: $6.34
33	WHT001197A	WASHER	4 req	Current Stock: 22 Our Price: $0.40
34	001108511	HEAD VAPOUR BREATHERPIPE	1 req	Avail to order Our Price: $11.47
35	001105951	COMPLETE OIL DIPSTICK	1 req	Avail to order Our Price: $63.53
36	008600901	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
37	001106151	HEAD COOLANT CONNECTION	1 req	Avail to order Our Price: $37.66
38	008300605	STUD M6X80 UNI 5914 8G/ZD	4 req	Avail to order Our Price: $12.72
39	N01152427	WASHER	4 req	Current Stock: 11 Our Price: $0.40
40	N01118312	HEX.HEAD CLAMPING NUT	4 req	Avail to order Our Price: $2.12
41	001801333	OIL & COOLANT TEMPERATURE THERMOMETER	1 req	Avail to order Our Price: $167.43
42	001107678	PIPE RIGHT HEAD	1 req	Avail to order Our Price: $24.30
43	008832401	CLAMP	2 req	Avail to order Our Price: $8.21
44	008612101	SEAL VITON 21X27.15X5 MM	12 req	Avail to order Our Price: $20.09
45	001110997	HEAD OIL DRAIN PIPE	6 req	Avail to order Our Price: $276.41
46	001108163	OIL DIPSTICK PIPE SEAL	2 req	Current Stock: 5 Our Price: $8.42
47	001108161	OIL DIPSTICK PIPE	1 req	Avail to order Our Price: $43.52
48	008410603	WASHER D.6.4 UNI 1751/ZD	4 req	Avail to order Our Price: $0.10
49	008100617	SCREW M6X18 UNI 57395S	4 req	Avail to order Our Price: $6.34
50	008830204	CLAMP	2 req	Avail to order Our Price: $9.35
51	001108162	HEAD HOLE CLOSING FLANGE	1 req	Avail to order Our Price: $20.09
52	008931801	CONCAVE PLUG 18X1.5	6 req	Avail to order Our Price: $2.76
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
