1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $98.99

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $86.47
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $68.46
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,856.21
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $7,713.90
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $680.71

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $284.62

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $44.63

Gaskets

PN	Item
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $295.22
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $338.90
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,761.30
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $2,980.03
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $306.23

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,398.65
001609592	DISTRIBUTOR CAP CAP	Avail to order Our Price: $390.61
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,833.85
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,856.21

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 24 - Sospensione Posteriore

1972-1977 Lamborghini Urraco USA Sospensione Posteriore (24)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	005119407	SHOCK ABSORBER CHASSIS MOUNT	2 req	Avail to order Our Price: $236.00
2	008200804	NUT	6 req	Current Stock: 7 Our Price: $1.20
3	005207464	NLA (NO LONGER AVAILABLE)	2 req	*See Description
4	005206948	GREASE CAP	2 req	Avail to order Our Price: $48.95
5	008201405	M14X1.5 SPECIAL NUT	2 req	Avail to order Our Price: $6.90
6	005207465	SHOCK ABSORBER NUT STOP	2 req	Avail to order Our Price: $12.64
7	005208239	REAR SHOCK ABSORBER PAD	2 req	Avail to order Our Price: $228.88
8	005207451	SHOCK ABSORBER SPRING BRACKET	4 req	Avail to order Our Price: $66.03
9	008830107	CLAMP D.68/U	2 req	Avail to order Our Price: $23.92
10	005206929	REAR WHEEL HUB	2 req	Avail to order Our Price: $639.64
11	008578201	O-RING I 82 UNI 3654	2 req	Current Stock: 12 Our Price: $3.69
12	008407502	WASHER 75X82.5X0.05	0 req	Avail to order Our Price: $20.13
13	008407501	WASHER 75X82.5X0.5	2 req	Avail to order Our Price: $6.90
14	008504502	NLA (NO LONGER AVAILABLE)	2 req	*See Description
15	005206944	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
16	005208235	DRIVE SHAFT FLANGE	2 req	Avail to order Our Price: $502.44
17	005206915	REAR SPRING UPPER BRACKET	2 req	Avail to order Our Price: $28.88
18	005220589	NLA (NO LONGER AVAILABLE)	2 req	*See Description
19	005108120	SHOCK ABSORBER BELLOWS	2 req	Avail to order Our Price: $124.66
20	008201008	NUT	4 req	Current Stock: 2 Our Price: $0.90
21	008401006	WASHER 22X10.5X2.5 UNI 1734/5S	4 req	Current Stock: 1 Our Price: $0.60
22	008830119	NLA (NO LONGER AVAILABLE)	2 req	*See Description
23	008880601	HYDRAULIC 273 A GREASE DISPENS	2 req	Current Stock: 8 Our Price: $1.50
24	008100826	SCREW M8X16 UNI 5739/8G/Z	4 req	Avail to order Our Price: $0.50
25	005107110	BAR ATTACHMENT BRACKET	4 req	Avail to order Our Price: $51.67
26	008802203	BUSHING 22X25X30 MM	8 req	Avail to order Our Price: $12.31
27	005207696	REAR RH TORSION BAR	1 req	Avail to order Our Price: $357.07
28	005208662	LOWER REAR ARM SHIM	2 req	Avail to order Our Price: $402.79
29	WHT003082	CYLINDER PINS 1707 H11 3X5	4 req	Current Stock: 41 Our Price: $0.80
30	005208666	REAR SUSPENSION SPRING	2 req	Avail to order Our Price: $389.15
31	008101032	SPECIAL SCREW M10X55	4 req	Avail to order Our Price: $8.85
32	008402502	WASHER 25X39X4 UNI 1750 5S	2 req	Avail to order Our Price: $2.43
33	005209248	COVER	2 req	Avail to order Our Price: $7.20
34	008200804	NUT	4 req	Current Stock: 7 Our Price: $1.20
35	008921501	ROLL BAR MOUNT D15/U	4 req	Avail to order Our Price: $15.17
36	008101015	SCREW M10X40 UNI 5737/8G	4 req	Avail to order Our Price: $15.17
37	005107467	WHEEL CENTRING .PIN	2 req	Avail to order Our Price: $9.24
38	008202502	M25X1.5 UNI 4535-64 NUT	2 req	Avail to order Our Price: $92.29
39	005207821	SUSPENSION LINKAGE	2 req	Avail to order Our Price: $1,425.34
40	008402603	SELF-LUBRICATING WASHER WC 24	4 req	Avail to order Our Price: $16.09
41	005208663	LOWER ARM SHIM ADJUSTMENT WASH	4 req	Avail to order Our Price: $56.52
42	005208667	BLADE SET	4 req	Avail to order Our Price: $29.27
43	008201406	NUT	2 req	Current Stock: 8 Our Price: $1.00
44	008401413	FLAT WASHER 14.3 UNI1750/Z	2 req	Current Stock: 11 Our Price: $1.10
45	N0152785	WASHER	8 req	Current Stock: 71 Our Price: $0.50
46	008200806	M8 UNI 5588/8G/Z NUT	8 req	Current Stock: 25 Our Price: $0.40
47	005206677	REAR LH LOWER ARM	1 req	Avail to order Our Price: $269.16
48	005206676	RH REAR LOWER ARM	1 req	Avail to order Our Price: $269.16
49	008201603	NUT	2 req	Avail to order Our Price: $3.97
50	008401611	WASHER 17X29X3 5S UNI 16592	2 req	Avail to order Our Price: $16.43
51	008921602	ESTENBLOCK	2 req	Avail to order Our Price: $127.57
52	008101619	SPECIAL SCREW M16X1.5X80	2 req	Avail to order Our Price: $23.82
53	008101415	SPECIAL SCREW M14X190	2 req	Avail to order Our Price: $46.77
54	008201008	NUT	4 req	Current Stock: 2 Our Price: $0.90
55	005206679	LOWER ARM SHIM	4 req	Avail to order Our Price: $27.03
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
