1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $98.99

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $86.47
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $68.46
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,856.21
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $7,713.90
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $680.71

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $284.62

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $44.63

Gaskets

PN	Item
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $295.22
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $338.90
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,761.30
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $2,980.03
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $306.23

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,398.65
001609592	DISTRIBUTOR CAP CAP	Avail to order Our Price: $390.61
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,833.85
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,856.21

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 25 - Impianto Benzina

1972-1977 Lamborghini Urraco USA Impianto Benzina (25)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008200806	M8 UNI 5588/8G/Z NUT	2 req	Current Stock: 25 Our Price: $0.40
2	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.80
3	WHT001942	WASHER	2 req	Current Stock: 13 Our Price: $3.50
4	008100826	SCREW M8X16 UNI 5739/8G/Z	2 req	Avail to order Our Price: $0.50
5	006208723	This item is no longer available	1 req
6	006208730	TANK UNION PIPE	1 req	Avail to order Our Price: $341.91
7	008200401	M4 UNI 5587/5S/Z	6 req	Avail to order Our Price: $0.10
8	008410404	CORRUGATED WASHER D.4.1 UNI370	6 req	Avail to order Our Price: $0.10
9	006208722	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	006208724	FUEL SENDING UNIT	1 req	Avail to order Our Price: $850.46
11	006205360	FLOAT DIMMER SEAL	1 req	Current Stock: 13 Our Price: $114.94
12	008100809	SCREW M8X22 UNI 5739/8G/ZD	3 req	Current Stock: 8 Our Price: $3.01
13	006207321	FUEL TANK CAP	1 req	Avail to order Our Price: $43.08
14	006208726	FUEL TANK PIPE BOOT	1 req	Avail to order Our Price: $34.52
15	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.14
16	006210416	SEE PN: 6208731 AND 6208732	1 req	Avail to order Our Price: $88.09
17	006208729	RH TANK BREATHER PIPE	1 req	Avail to order Our Price: $26.06
18	008200804	NUT	3 req	Current Stock: 7 Our Price: $1.20
19	008830205	CLAMP	4 req	Avail to order Our Price: $7.88
20	006210246	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
21	008830203	CLAMP	2 req	Avail to order Our Price: $11.86
22	006208725	FUEL TANK FILLER	1 req	Avail to order Our Price: $398.10
23	006208728	LH TANK BREATHER PIPE	1 req	Avail to order Our Price: $6.03
24	008100827	SCREW M8X25 UNI 5739/8G/ZG	1 req	Current Stock: 14 Our Price: $0.40
25	008200804	NUT	1 req	Current Stock: 7 Our Price: $1.20
26	001304214	NLA (NO LONGER AVAILABLE)	2 req	*See Description
27	001301474	FIBRE SEAL 14X10X2	4 req	Current Stock: 4 Our Price: $4.38
28	006209554	FUEL PUMP UNION	2 req	Avail to order Our Price: $8.07
29	006208887	FUEL FILTER BRACKET	1 req	Avail to order Our Price: $22.07
30	008100630	SCREW M6X14 UNI 5739/8G/Z	2 req	Avail to order Our Price: $0.20
31	008410603	WASHER D.6.4 UNI 1751/ZD	2 req	Avail to order Our Price: $0.10
32	006210508	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
33	006210519	This item is no longer available	1 req
34	006208736	ENGINE FILTER PIPE GUARD	1 req	Avail to order Our Price: $13.32
35	006209555	TANK /FUEL PUMP HOSE	1 req	Avail to order Our Price: $57.37
36	008833501	CLAMP	2 req	Avail to order Our Price: $11.96
37	001303074	NLA	1 req	*See Description
38	008401804	ANNEALED COPPER WASHER 18.2X30	2 req	Avail to order Our Price: $4.67
39	006209551	FUEL INTAKE UNION	1 req	Avail to order Our Price: $251.27
40	001304213	RED HEAD FUEL PUMP	1 req	Avail to order Our Price: $530.65
41	008610601	GROMMET 6X10X1.5 MM	2 req	Avail to order Our Price: $5.62
42	WHT002961	WASHER	2 req	Current Stock: 38 Our Price: $0.40
43	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.14
44	N0211963	HEX.HEAD CLAMPING	3 req	Avail to order Our Price: $0.80
45	008100506	SCREW M5X14 UNI 5739	3 req	Avail to order Our Price: $11.96
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
