1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $98.99

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $86.47
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $68.46
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,856.21
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $7,713.90
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $680.71

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $284.62

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $44.63

Gaskets

PN	Item
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $295.22
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $338.90
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,761.30
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $2,980.03
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $306.23

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,398.65
001609592	DISTRIBUTOR CAP CAP	Avail to order Our Price: $390.61
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,833.85
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,856.21

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 26 - Riscaidatore

1972-1977 Lamborghini Urraco USA Riscaidatore (26)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008410502	WASHER D.5.3 UNI 1751/ZD	4 req	Current Stock: 33 Our Price: $0.10
2	N01020717	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $0.80
3	004708855	This item is no longer available	1 req
4	004708862	This item is no longer available	1 req
5	004709324	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
6	008100401	SCREW M4X10 UNI 5739/5S/Z	2 req	Avail to order Our Price: $0.60
7	008410403	WASHER D.4.3 UNI 1751/Z	2 req	Avail to order Our Price: $7.58
8	006753080	SHEATH CLAMP	2 req	Avail to order Our Price: $2.63
9	004708863	This item is no longer available	1 req
10	004708860	This item is no longer available	1 req
11	004708861	This item is no longer available	1 req
12	004708856	HEATER DOOR RETURN SPRING	1 req	Avail to order Our Price: $42.01
13	001708599	This item is no longer available	1 req
14	004708859	MANIFOLD FLAP WIRE	1 req	Avail to order Our Price: $56.52
15	N10689901	HEX.NUT	3 req	Current Stock: 5 Our Price: $0.10
16	008410502	WASHER D.5.3 UNI 1751/ZD	3 req	Current Stock: 33 Our Price: $0.10
17	N01020717	HEXAGON HEAD BOLT	3 req	Current Stock: 4 Our Price: $0.80
18	008410502	WASHER D.5.3 UNI 1751/ZD	3 req	Current Stock: 33 Our Price: $0.10
19	004708838	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
20	004708842	MOTOR/SCROLL SEAL	1 req	Avail to order Our Price: $28.31
21	004708839	HEATER MOTOR	1 req	Avail to order Our Price: $735.04
22	004708840	NLA (NO LONGER AVAILABLE)	1 req	*See Description
23	004708837	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
24	008830206	CLAMP	6 req	Current Stock: 1 Our Price: $23.24
25	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.14
26	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $0.30
27	004708857	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
28	004709604	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
29	N01022217	HEXAGON HEAD BOLT	2 req	Avail to order Our Price: $7.67
30	001707752	COOLANT COCK FLANGE	1 req	Avail to order Our Price: $29.27
31	008601201	RING 13 MM OR	1 req	Avail to order Our Price: $0.10
32	004707762	This item is no longer available	1 req
33	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $0.30
34	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.14
35	008100622	SCREW M6X12 UNI 5739/8G	1 req	Avail to order Our Price: $6.81
36	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $0.30
37	008410503	WASHER DIN 137A 5.3X10 ZGD.	3 req	Avail to order Our Price: $0.20
38	N01020717	HEXAGON HEAD BOLT	3 req	Current Stock: 4 Our Price: $0.80
39	004708846	SCROLL/RADIATOR AIR MANIFOLD	1 req	Avail to order Our Price: $283.16
40	008410502	WASHER D.5.3 UNI 1751/ZD	4 req	Current Stock: 33 Our Price: $0.10
41	N01020717	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $0.80
42	004708847	HEATER RADIATOR	1 req	Avail to order Our Price: $2,905.78
43	004708858	This item is no longer available	2 req
44	004708845	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
